The active backup, scheduled-snapshot, and one-click restore extension for Docker.
Docker Rescue Kit (DRK) is the only Docker Desktop Extension for scheduled, policy-driven backup and restore of Docker containers, volumes, images, and networks. It runs as a single container, discovers your stacks through the Docker API, and snapshots them to 7 storage backends — local, SMB, SFTP, S3, Proxmox PBS, Restic, or 40+ clouds via Rclone.
As of mid-2026, DRK is the only published Docker Desktop Extension in the backup/restore category — Docker deprecated their own Volumes Backup & Share extension in September 2024.
| Feature | DRK | Docker Volumes tab | offen | Duplicati |
|---|---|---|---|---|
| Docker Desktop Extension | ✅ | Built-in (export only) | — | — |
| Scheduled policies | ✅ | — | — | ✅ |
| Multi-backend (7 targets) | ✅ | Local only | ~6 | 40+ |
| Restore verification (sandbox) | ✅ | — | — | — |
| Partial restore (file browser) | ✅ | — | — | — |
| Database exporters (7 types) | ✅ | — | — | — |
| Proxmox PBS backend | ✅ | — | — | — |
| Web UI + CLI + REST API | ✅ | Basic | — | ✅ |
New here? Two pages to read first:
- Backup Tools Buyer's Guide — honest comparison to
offen/docker-volume-backup,kopia,restic,Duplicati, andtiredofit/docker-db-backup.- Stack Recipes — copy-paste DRK policies for Home Assistant, Plex/Jellyfin, Immich, Nextcloud, Vaultwarden, and n8n.
git clone https://github.com/gozippy/DockerRescueKit.git
cd DockerRescueKit
docker compose up -dVerify the service is up:
curl http://localhost:42880/healthz
# → {"status":"ok","uptime":12.3}Open the web UI at http://localhost:42880.
The compose file at the repo root publishes the service on port 42880
and mounts the Docker socket so DRK can see your containers.
On the first start, DockerRescueKit generates a random API key and a
random encryption key, then persists both to $DRK_DATA_DIR/secrets.json
(inside the container that resolves to /data/secrets.json, which is
backed by the named volume drk-data).
Retrieve the API key:
docker exec drk cat /data/secrets.json
# → {"apiKey":"<your-generated-key>","encryptionKey":"<encryption-key>"}Then call any authenticated endpoint with that key:
KEY=$(docker exec drk cat /data/secrets.json | jq -r .apiKey)
curl -H "x-api-key: $KEY" http://localhost:42880/api/status
# → {"status":"online","version":"1.0.0","docker":true,...}To pre-seed your own keys instead of letting the service generate them,
set DRK_API_KEY and DRK_ENCRYPTION_KEY in docker-compose.yml
before the first start. The API key can also be regenerated at any time
from the Settings panel in the web UI — no restart required.
Warning: rotating
DRK_ENCRYPTION_KEYafter the fact will invalidate every credential stored in the vault. Only the API key rotates safely.
| Policies | Settings |
|---|---|
 |
 |
- Backups — containers, volumes, images, and networks captured as a
consistent unit. Pre- and post-backup hooks executed inside the target
container via
docker exec. - Storage adapters — Local, SMB/CIFS, SFTP, S3, Proxmox Backup Server, restic, rclone. All credentials AES-256-GCM encrypted at rest.
- Scheduling — cron-based policies with
node-cronsemantics. Pause and resume the global scheduler without losing schedule state. Per-run audit log of every policy invocation. - Retention — simple count, time-based, or tiered (daily/weekly/monthly) retention with safe deletion that runs after the write completes.
- Verify and restore — every backup can be restore-tested in a scratch container before you trust it. Full-stack restore or partial restore down to individual files (browse and extract).
- CLI —
drkcommand with policy, backup, connector, and rclone subcommands. Talks to the same REST API the UI uses. - Web UI — bundled React app served by the backend on the same port. Policy editor, backup history, restore wizard, connector setup, settings panel.
- Observability — unauthenticated
GET /healthzfor liveness probes andGET /metricsin Prometheus exposition format. Every request gets anX-Request-Idcorrelation header that flows through to logs and error responses.
The service is a single Node.js process serving a React UI, a REST API,
a cron scheduler, and the storage adapters from one container. See
docs/ARCHITECTURE.md for the component diagram
and data flow. For sizing across homelab, small business, and
enterprise deployments, see docs/DEPLOYMENT_BY_TIER.md.
DockerRescueKit ships as both a standalone container and a native Docker Desktop Extension that embeds the UI directly inside Docker Desktop.
Install the extension from Docker Desktop (Extensions Marketplace) or via CLI:
docker extension install gozippy/dockerrescuekit:latestThe extension and the standalone container share the same backend
codebase. The only runtime difference is transport mode: the standalone
container serves the UI on http://localhost:42880 over TCP; the
Docker Desktop Extension routes API calls through the Docker Desktop
socket (DRK_TRANSPORT=socket). Both are available from the same
published image.
Before any upgrade, reinstall, or docker extension rm, export
your config (Settings → Export config) and save the JSON outside the
extension's data volume. Hub tag-to-tag upgrades on
gozippy/dockerrescuekit are safe; image-ID changes (sideload → Hub,
fork, repo rename) orphan the old volume. See
docs/UPGRADE.md for the canonical playbook,
manual migration commands, and the list of broken v1.2.x Hub tags.
| Feature | Free | Pro (coming) |
|---|---|---|
| Backup scheduling + retention | ✅ Unlimited | ✅ |
| Local, SMB/CIFS, SFTP storage | ✅ | ✅ |
| S3-compatible object storage | ✅ | ✅ |
| Proxmox Backup Server | ✅ | ✅ |
| Rclone (~40 providers incl. GDrive, OneDrive) | ✅ | ✅ |
| Point-in-time restore + partial file extract | ✅ | ✅ |
| Backup verify (scratch container test) | ✅ | ✅ |
CLI (drk) + REST API |
✅ | ✅ |
| Prometheus metrics | ✅ | ✅ |
| Docker Desktop Extension | ✅ | ✅ |
| Concurrent policy limit | 5 | Unlimited |
| Slack / email / webhook notifications | — | ✅ |
| Managed offsite backup (hosted S3) | — | ✅ |
| Backup encryption (AES-256, bring your own key) | — | ✅ |
| Extended audit log retention | 30 days | 90 days |
| Priority support | Community | 24-hour |
| Multi-user / RBAC | — | Enterprise |
| SSO (SAML/OIDC) | — | Enterprise |
| Managed HA infrastructure (AWS/GCP) | — | Enterprise |
See docs/ROADMAP.md for the full implementation
status and planned feature timeline.
The DRK container talks to your Docker daemon through
/var/run/docker.sock. The non-root user inside the container can only
read the socket if it shares the host's docker group GID.
- Most Linux distros use gid 999 — the compose file defaults to this.
- Synology / QNAP typically use gid 100.
- Some Debian variants use gid 998.
- macOS / Docker Desktop expose the socket differently and usually do not require this setting.
Find your host's docker group GID:
getent group docker | cut -d: -f3
# → 999Pass the correct value when starting the service:
DOCKER_GID=100 docker compose up -dIf the GID is wrong, the /api/docker endpoints return offline and
container discovery silently produces an empty list.
All configuration is via environment variables read by the backend on startup.
| Variable | Default | Notes |
|---|---|---|
DRK_DATA_DIR |
/data |
Path inside the container holding the SQLite DB, secrets, and staging. |
PORT |
42880 |
HTTP listen port for the API + UI. |
DRK_API_KEY |
auto-generated | Pre-seed an API key. Otherwise one is generated and written to secrets.json on first start. |
DRK_ENCRYPTION_KEY |
auto-generated | Master AES-256-GCM key for the credential vault. Do not rotate after first start. |
DOCKER_GID |
999 (compose group_add) |
Host docker-group GID granted to the in-container drk user. |
DB_PATH |
$DRK_DATA_DIR/docker_rescue.db |
Override the SQLite DB location (rarely needed). |
NODE_ENV |
production |
Standard Node.js mode flag. |
RESTIC_BIN |
restic |
Override path to the restic binary. The image ships one preinstalled. |
RCLONE_BIN |
rclone |
Override path to the rclone binary. The image ships one preinstalled. |
PBS_BIN |
proxmox-backup-client |
Override path to the PBS client. |
Rate limits are currently fixed in code: 100 requests per 15 minutes
per IP against /api/*, plus a 10 failed-auth requests per minute
brute-force throttle. Both layers emit standard RateLimit-* headers.
The drk CLI lives in packages/cli and is installed
as a bin entry by that package. It talks to the same REST API as the UI
and reads DRK_URL (default http://localhost:42880) and DRK_API_KEY
from the environment.
drk — Docker Rescue Kit CLI
Usage: drk <command> [arguments] [--flags]
Environment:
DRK_URL API base URL (default: http://localhost:42880)
DRK_API_KEY API key (required)
Service
status Show service, scheduler, and Docker connection status
scheduler:pause Stop firing scheduled policy runs
scheduler:resume Resume the scheduler
Policies
policy:list List all backup policies
policy:show Show a single policy
policy:run Trigger a policy run now
policy:delete Delete a policy
policy:history List recent runs for a policy
Backups
backup:list List backups (optionally filtered by policy)
backup:show Show a single backup
backup:restore Restore a backup (full or partial)
backup:verify Verify a backup in a scratch container
backup:delete Delete a backup
backup:files List or extract files inside a backup
Docker
stacks List compose stacks visible to the daemon
volumes List Docker volumes
images List Docker images
networks List Docker networks
stack:protect Add a compose stack to a backup policy
Connectors
connectors:list List configured storage connectors
connectors:definitions Show available connector types
connectors:test Test a connector's credentials
connectors:delete Remove a connector
Rclone
rclone:providers List supported rclone provider types
rclone:list List configured rclone remotes
rclone:add Add a new rclone remote
rclone:delete Remove an rclone remote
rclone:test Test an rclone remote
Audit & Settings
audit Show recent audit log entries
settings:show Show current settings
verify:history Show recent verify-run results
See docs/DEVELOPMENT.md for the monorepo layout,
build commands, and how to run the backend and extension UI with hot
reload. Contributions welcome — see CONTRIBUTING.md.
Docker Rescue Kit is source-available under the Zippy Technologies Source-Available Commercial License — see LICENSE.
- Free for Personal Use and Educational Use (homelab, hobbyists, students, classroom, non-commercial research) within the documented free-tier limits.
- Personal Pro Upgrade — USD $29 one-time, lifetime updates within the current Major Version, unlocks unlimited policies, notifications, 90-day audit log, and bring-your-own-key encryption. Personal/educational use only.
- Commercial Pro — USD $149 per Seat per year (3-Seat minimum). Launch pricing: USD $99/Seat/year locked in for life for continuous subscribers through the first 1,000 Seats or 2026-12-31, whichever comes first.
- Enterprise — custom, USD $5,000 minimum annually. RBAC, SSO, WORM, compliance docs, managed cloud backup. Contact Support@GoZippy.com.
- Priority Queue Add-on — optional USD $750/year for a 48-hour best-effort response window, capped at 25 active subscribers per quarter.
Community help is provided on a best-effort basis through public GitHub Discussions. No tier includes a service level agreement or committed support response time — see Section 5.7 of the LICENSE.
Component classification (Open Materials vs Restricted Materials) is recorded in COMPONENTS.md. Versions of Docker Rescue Kit released before the LICENSE Effective Date (2026-05-24) remain available under the MIT License as to copies obtained before that date — see Section 23 of the LICENSE.
Older PowerShell tooling for WSL2 distro patching and Docker Desktop
image maintenance still ships in tools/ and at the repo root
(backup-docker-snapshot.ps1). It predates the backup service and is
unrelated to the container running on port 42880. See
docs/WSL_TOOLS.md for usage and parameter reference.
| Document | What |
|---|---|
| Architecture | Component diagram, data flows, security model |
| Deployment by Tier | Docker Compose, K8s, Terraform examples |
| Homelab Quickstart | Proxmox, TrueNAS, Unraid setup guides |
| Backup Tools Comparison | Honest comparison to offen, restic, Duplicati, kopia |
| Stack Recipes | Copy-paste policies for 6 homelab stacks |
| Competitive Analysis | SWOT, gap analysis, strategic recommendations |
| Roadmap | Implementation status and planned features |
| Observability | Prometheus metrics, Grafana, alerting |
| FAQ | Frequently asked questions |
| Troubleshooting | Common issues and fixes |
