Multi-asset concentrated liquidity AMM on Algorand, powered by sphere & torus geometry.
-CEF17B?style=flat){kind=icon}
-084734?style=flat){kind=icon}
Existing DEX designs force a painful tradeoff:
| Uniswap V3 | Curve | TaurusSwap | |
|---|---|---|---|
| Tokens per pool | 2 | n | n |
| Concentrated liquidity | Yes | No | Yes |
| On-chain verification | O(1) | O(n) | O(1) |
| Capital efficiency at $0.99 depeg (n=5) | N/A (2-token only) | 1x | ~150x |
Uniswap V3 gives you concentrated liquidity but only for pairs. Five stablecoins need 10 separate pools, fragmenting liquidity across all of them.
Curve supports multi-asset pools but forces every LP into the same uniform profile. No LP can say "I only want exposure near the $1 peg."
TaurusSwap solves both. Using the geometry of n-dimensional spheres, it enables concentrated liquidity positions (ticks) across arbitrarily many tokens in a single pool, with O(1) on-chain verification regardless of pool size.
For the full mathematical derivation, architecture deep-dive, and visual explanations, see the Documentation.
flowchart TD
A["<b>Sphere AMM</b><br/>Reserves live on an n-dimensional sphere<br/><code>‖r⃗ - x‖² = r²</code>"] --> B["<b>Ticks = Spherical Caps</b><br/>LPs pick depeg tolerance (k)<br/>Ticks are nested, not disjoint"]
B --> C["<b>Consolidation</b><br/>Interior ticks → 1 sphere (r_int = Σrᵢ)<br/>Boundary ticks → 1 sphere (s_bound = Σsᵢ)"]
C --> D["<b>Torus Invariant</b><br/>sphere + sphere = torus<br/>Needs only Σxᵢ and Σxᵢ²"]
D --> E["<b>O(1) Verification</b><br/>~55 opcodes for n=5<br/>Same cost for n=10,000"]
style A fill:#084734,color:#CEF17B,stroke:#CEF17B
style B fill:#084734,color:#CEF17B,stroke:#CEF17B
style C fill:#084734,color:#CEF17B,stroke:#CEF17B
style D fill:#084734,color:#CEF17B,stroke:#CEF17B
style E fill:#084734,color:#CEF17B,stroke:#CEF17B
- Sphere AMM -- Pool reserves sit on the surface of an n-dimensional sphere centered at (r, r, ..., r)
- Ticks as spherical caps -- LPs define how far from the $1 peg they provide liquidity (parameter k). Ticks are nested, not disjoint
- Consolidation -- All interior ticks collapse into one sphere (radius = sum of radii). All boundary ticks collapse into another. Two spheres form a torus
- O(1) verification -- The torus equation uses only
sum(reserves)andsum(reserves²). Updating these for a 2-token swap is constant-time, regardless of pool size - Compute off-chain, verify on-chain -- The SDK solves the quartic trade equation. The smart contract only checks the torus invariant holds
The TaurusSwap SDK is now publicly available on npm. Integrate TaurusSwap swaps, quotes, and pool data directly into your application — no contract interaction required.
npm install @taurus-swap/sdk algosdk
# or
yarn add @taurus-swap/sdk algosdkimport { TaurusClient } from "@taurus-swap/sdk";
const client = new TaurusClient();
const quote = await client.quote({
fromIndex: 0, // USDC
toIndex: 1, // USDT
amountIn: 100_000_000n, // 100 USDC (6 decimals)
});
console.log(`You receive: ${Number(quote.amountOut) / 1e6} USDT`);
console.log(`Price impact: ${(quote.priceImpact * 100).toFixed(4)}%`);// Build an unsigned transaction group — your wallet signs it
const txns = await client.buildSwapTxns({
sender: "YOUR_ALGORAND_ADDRESS",
fromIndex: 0,
toIndex: 1,
amountIn: 100_000_000n,
slippageBps: 50, // 0.5% slippage tolerance
});
// Sign with any Algorand wallet (Pera, Defly, Kibisis…) and submit
const signedTxns = await wallet.signTransactions(txns);
await algod.sendRawTransaction(signedTxns).do();const pool = await client.getPoolState();
// { n, ticks, reserves, rInt, feeBps, tokenAsaIds, ... }The SDK handles all quartic-equation solving and tick-crossing logic off-chain. Your application calls one method; the Algorand contract does O(1) on-chain verification.
Full API reference → packages/sdk/README.md
graph TB
subgraph Frontend["Frontend — React 18 + Vite + Tailwind"]
FE_SWAP["SwapCard"]
FE_POOL["Pool / Explore / Portfolio"]
end
subgraph SDK["TypeScript SDK — @orbital-amm/sdk"]
MATH["BigInt Math Engine<br/>sphere, torus, Newton solver"]
CROSS["Tick Crossing &<br/>Trade Segmentation"]
TX["Transaction Builders<br/>& State Reader"]
end
subgraph Contract["Algorand Smart Contract — ARC-4"]
VERIFY["Torus Invariant<br/>Verifier"]
BOXES["Box Storage<br/>reserves, ticks, positions"]
FEES["Fee-Growth<br/>Accumulator"]
INNER["Inner Txn<br/>Payouts"]
end
subgraph Ref["Python Reference Simulator"]
REF_MATH["orbital_math/<br/>Fixed-point ground truth"]
end
Frontend -->|"swap request"| SDK
SDK -->|"atomic txn group"| Contract
Contract -->|"tokens out"| Frontend
REF_MATH -.->|"validates"| SDK
REF_MATH -.->|"validates"| Contract
style Frontend fill:#1a1a2e,color:#CEF17B,stroke:#CEF17B
style SDK fill:#16213e,color:#CEF17B,stroke:#3b82f6
style Contract fill:#084734,color:#CEF17B,stroke:#22c55e
style Ref fill:#1a1a1a,color:#888,stroke:#555
The principle: The SDK computes; the contract verifies. The contract never solves the quartic — it only checks that the proposed post-trade state satisfies the torus equation within tolerance.
taurusSwap/
├── contracts/ # Algorand smart contract + reference math
│ ├── orbital_math/ # Python fixed-point math simulator
│ │ ├── sphere.py # Sphere invariant, pricing, equal-price point
│ │ ├── polar.py # Polar reserve decomposition (α, w)
│ │ ├── torus.py # Torus residual & verification
│ │ ├── ticks.py # Tick bounds, virtual reserves, capital efficiency
│ │ ├── consolidation.py # Interior/boundary tick consolidation
│ │ ├── newton.py # Newton + bisection trade solver
│ │ ├── crossings.py # Tick crossing detection & segmentation
│ │ └── models.py # Tick, TradeSegment, ConsolidatedState
│ ├── smart_contracts/
│ │ └── orbital_pool/
│ │ └── contract.py # The on-chain OrbitalPool (ARC-4)
│ ├── scripts/
│ │ ├── deploy_testnet.py # Testnet deployment
│ │ ├── deploy_localnet.py # Localnet deployment
│ │ └── seed_testnet_pool.py# Post-deploy liquidity seeding
│ └── tests/ # 45 passed, 3 skipped
│
├── sdk/ # TypeScript SDK (@orbital-amm/sdk)
│ ├── src/math/ # BigInt sphere, torus, Newton, crossings
│ ├── src/pool/ # swap, liquidity, quote, state-reader
│ ├── src/algorand/ # Tx builders, box encoding, ABI
│ └── tests/
│
├── frontend/ # React + Vite + Tailwind + shadcn/ui
│ └── src/
│ ├── components/swap/ # SwapCard, TokenSelectorModal
│ ├── components/landing/ # Hero, Features, BentoGrid, FAQ
│ └── pages/ # Index, Explore, Pool, Portfolio
│
├── animations/ # Manim scripts for math visualizations
│ ├── 01_sphere_amm.py # Sphere surface & reserve dynamics
│ ├── 02_polar_decomposition.py # α and w decomposition
│ ├── 03_ticks_and_caps.py # Spherical caps & concentrated liquidity
│ ├── 04_consolidation.py # Interior + boundary → torus
│ └── 05_trade_execution.py # Complete swap walkthrough
│
└── docs/ # Full documentation
└── README.md # Start here
- Python 3.12+, Node.js 18+, AlgoKit CLI v2+, Docker (for localnet)
git clone <repo-url> && cd taurusSwap
# Contracts + math simulator
cd contracts
source ~/python/bin/activate
pip install -e ".[dev]"
# SDK
cd ../sdk
npm install
# Frontend
cd ../frontend
npm install# Contract
cd contracts
source ~/python/bin/activate
algokit project run build
algokit project run test # 45 passed
# SDK
cd ../sdk
npm test
# Frontend
cd ../frontend
npm run devcd contracts
source ~/python/bin/activate
algokit localnet start
algokit project deploy localnetcd contracts
source ~/python/bin/activate
export ORBITAL_MNEMONIC="your 25-word testnet mnemonic"
export ORBITAL_CREATE_MOCK_ASSETS=1
algokit project deploy testnetexport ORBITAL_APP_ID=<app-id-from-deploy>
export ORBITAL_TRADER_ADDRESSES="ADDR1,ADDR2"
python scripts/seed_testnet_pool.pysource ~/python/bin/activate
cd animations
manim -pql 01_sphere_amm.py SphereAMM # 480p preview
manim -pqh 04_consolidation.py TorusFormation # 1080p render| Metric | Value |
|---|---|
| Capital efficiency (n=5, $0.99 depeg) | ~150x vs Curve |
| Capital efficiency (n=5, $0.95 depeg) | ~30x vs Curve |
| On-chain verification cost | ~55 opcodes (n=5) |
| Finality | 3.3 seconds |
| Max tokens per pool | Unlimited (tested to n=5) |
| Trade invariant complexity | O(1) regardless of n |
The full documentation lives in docs/ and covers:
| Document | What You'll Learn |
|---|---|
| Problem Statement | Why existing AMMs fail at multi-asset concentrated liquidity |
| Mathematical Foundations | Sphere AMM, pricing, equal-price point, polar decomposition |
| The Torus Invariant | Tick consolidation, the torus equation, O(1) verification |
| Tick Mechanics | Spherical caps, k-bounds, virtual reserves, capital efficiency |
| Trade Execution | Quartic equation, Newton solver, tick crossings, segmentation |
| Smart Contract | On-chain architecture, box storage, fee accounting, ABI |
| TypeScript SDK | Math engine, transaction builders, public API |
| Deployment Guide | Localnet, testnet, seeding, environment variables |
| Seeding Process | How pools go from empty to live with initial liquidity |
Inspired by Paradigm's Orbital paper, we built manim animation scripts that visually explain the core mathematics. These produce videos suitable for presentations, demos, and educational content.
| Animation | What It Shows |
|---|---|
01_sphere_amm.py |
3D sphere surface, reserve point moving along it during trades |
02_polar_decomposition.py |
Splitting reserves into parallel (alpha) and orthogonal (w) components |
03_ticks_and_caps.py |
Spherical caps as concentrated liquidity regions |
04_consolidation.py |
Multiple ticks collapsing into a single torus |
05_trade_execution.py |
End-to-end swap: input, Newton solve, invariant check, output |
06_seeding_process.py |
Pool seeding: validation, funding, ASA distribution, add_tick |
This implementation is based on the Orbital paper by Dave White, Dan Robinson, and Ciamac Moallemi (Paradigm, June 2025).
Paper: paradigm.xyz/2025/06/orbital
The key insight from the paper: by using sphere geometry for AMM invariants, multi-asset concentrated liquidity becomes possible with constant-time on-chain verification through a torus equation.
 Manobendra Mandal |
 Kaushik Samadder |
 Mitudru Dutta |
 Debanshu Paul |
 Rajarshi Datta |
Compute off-chain. Verify on-chain. Trade without limits.
