Paxeer Network

Project: Matrix Built by PaxLabs License: Matrix-Protocol Status: Active

Chain: HyperPaxeer Chain ID: 125 Block Time: 400ms Finality: 400ms

ci lint docker Go 1.22 9 Go modules


What is Matrix?

Matrix is the cognition and UX layer on top of Paxeer Network. It turns natural-language requests from non-developers into a typed, inspectable, correctable Intent IR that an agent can actually execute — without the four classic failure modes that break non-dev ↔ agent workflows today:

  1. Prompt fragility — small rewordings yield wildly different outputs.
  2. Intent loss — natural language doesn't survive multi-step execution.
  3. No shared ontology — user and agent disagree about which entity is being referred to.
  4. No structured correction — drift forces the user to rewrite from scratch.

Matrix ships two agent rails over one shared memory + execution substrate:

  • Neo — the default conversational tool-calling agent: familiar, robust, fully permissive on reversible work (shell, code, fetch, web). It delegates anything monetary or irreversible to the rigorous rail.
  • MCL pipeline — the rigorous rail: natural language → typed Intent IR → plan → replayable walk, for high-stakes / on-chain / irreversible work.

The stack is layered:

Layer Role
MCL Protocol turning NL → typed Intent IR. Verbs are closed (10), objects are closed (8 kinds).
cortex Per-actor typed memory graph on Pebble. Append-only journal, Merkle-anchored snapshots.
bridge Glue wiring the MCL compiler's Cortex interface to a live cortex instance.
executor Plan walker, lifecycle machine, MCP tool dispatch, per-user daemon, Liaison narrator, e2e harness.
neo The default conversational agent — tool-calling loop with paged cortex memory.
gateway Metered LLM proxy + PAX credit ledger (free-tier whitelist + rate card).
router Per-user Fly Machine provisioning + wake-then-reverse-proxy front door.
deus Agent-service marketplace: registry, discovery, metered invoke, EIP-712 receipts, hosting.
uwac Universal Web Agent Connector — OAuth vault → per-user MCP tools.
tachyon Agent-native Solidity/EVM engine — compile / test / simulate / deploy.
agents DID-bound manifests. Protocol, not personality.
tools MCP servers the agents call (the chain-touching ones included).

Repository layout

matrix/
├── cortex/        Typed per-actor memory graph (Pebble) + replay invariant + Merkle snapshots
├── MCL/           MatrixScript compiler — lexer/parser/validator/canonical/interpreter + Intent IR + envelopes + LLM client
├── bridge/        MCL ↔ cortex adapter (separate Go module; replace-directive linked)
├── executor/      Lifecycle machine, runtime walker, MCP client + tool registry, per-user daemon (+ Liaison narrator), e2e harness
├── neo/           Neo — the default conversational tool-calling agent (delegates monetary/irreversible work to MCL)
├── gateway/       Metered LLM proxy + PAX credit ledger (free-tier whitelist + rate card)
├── router/        Per-user Fly Machine provisioning + wake-then-reverse-proxy front door
├── deus/          Agent-service marketplace: registry, discovery, metered invoke, EIP-712 receipts, hosted execution
├── uwac/          Universal Web Agent Connector — OAuth vault → per-user MCP tools (building)
├── tachyon/       Agent-native Solidity/EVM engine — compile/test/simulate/deploy (git submodule)
├── chronos/       Centralized agent scheduler / wake-up system (design frozen)
├── agents/        DID-bound agent manifests (default.json, neo.json) + MCP server templates
├── tools/         MCP servers — paxeer, browser, tachyon, deus, uwac, web-search, media, cortex
├── skills/        SKILL.mtx capability manifests + SKILL.md prose bodies
├── client/        Matrix consumer app (Next.js / React)
├── marketplace/   Deus marketplace + developer dashboard (React Router on Cloudflare Workers)
├── deploy/        Daemon image, Fly Machine deploy, shared-service images, box install scripts
├── rules/         Identity + per-language coding rules
├── knowledge/     Canonical refs (matrix.kvx project state, models)
└── runs/          Transient harness output (gitignored)

The Go modules

The root Makefile drives nine sibling Go modules — MCL, bridge, executor, gateway, router, cortex, tachyon, deus, neo — alongside uwac (and chronos, in progress). Each is independently go build/go testable with its own go.mod; cross-module imports use replace directives during development and explicit versions on publish.

cortex   → matrix/cortex                    typed memory graph, replay invariant, snapshots/Merkle
MCL      → matrix/mcl                       compiler + Intent IR + envelopes + LLM client
bridge   → matrix/bridge                    MCL ↔ cortex adapter
executor → matrix/executor                  plan walker, lifecycle, MCP dispatch, daemon, Liaison
neo      → matrix/neo                       default conversational agent
gateway  → matrix/gateway                   metered LLM proxy + PAX credit ledger
router   → matrix/router                    per-user Fly Machine routing
deus     → github.com/paxlabs-inc/deus      agent-service marketplace
uwac     → github.com/paxlabs-inc/uwac      external app connectors
tachyon  → github.com/paxlabs-inc/tachyon-tools   Solidity/EVM engine (submodule)

Quickstart

Prerequisites

  • Go 1.22+ (toolchain pinned across every module).
  • make (GNU make 4.x).
  • For the MCP-server-driven flows: node ≥ 20, npx, python3 ≥ 3.11, uv.
  • For the daemon image: docker with buildx.

Clone and build

git clone https://github.com/paxlabs-inc/matrix-core.git
cd matrix-core
make build           # builds all nine Go modules
make install         # drops the runnable CLIs into ./bin
make test            # `go test -count=1 -race ./...` per module
make vet             # `go vet ./...` per module
make ci              # gofmt-check + vet + tests (mirrors GitHub Actions)

Need golangci-lint locally:

make lint-install    # pinned to v1.61.0
make lint

Configure secrets

cp .env.example .env
# fill in FIREWORKS_API_KEY / TOGETHER_API_KEY for any non-dry-run compile
# fill in MATRIX_DAEMON_TOKEN if running the daemon with auth

.env is gitignored; .env.example documents every variable Matrix reads.

Compile your first intent

./bin/mclc compile \
  -skill skills/writing-plans/SKILL.mtx \
  -prose "Build a deployment pipeline for my Node.js app" \
  -verb  build

With FIREWORKS_API_KEY set the compiler emits a real Intent Frame (verb, typed objects, blocking unknowns). Without keys it falls back to dry-run mode and prints the fully-interpolated prompt structure.

Drive an end-to-end walk

./bin/mcl-execute walk \
  -prose       "Summarise the README and write it to /tmp/summary.md" \
  -manifest    agents/default.json \
  -cortex-root ./runs/dev-cortex \
  -skills-root ./skills

This loads the agent manifest, spawns the MCP servers it declares, compiles the prose into an Intent + PlanTree, walks the plan, journals every step as a cortex Event, and ends with cortex.Attest writing KindAttest + KindLearnWeights atomically.

Run the daemon

./bin/mcl-execute daemon \
  -addr        :8080 \
  -cortex-root ./runs/dev-cortex \
  -manifest    agents/default.json \
  -skills-root ./skills

Routes:

Method Path Purpose
GET /healthz Liveness + SSE broker stats
POST /chat Converse with the agent (Neo front door)
GET /events Server-Sent Events tail (transcript)
POST /messages Submit a prose message (rigorous rail)
GET /intents/{id} Read intent envelope chain by ID
GET /me Per-user settings + identity
POST /shutdown Graceful drain

Status

Matrix runs as a hosted v1: each user gets an isolated per-user runtime (a Fly Machine) provisioned and woken on demand by the router, with every LLM call metered through the gateway's PAX credit ledger.

  • cortex — v1 complete: typed memory, append-only journal, replay invariant, Merkle snapshots, salience, real embedder.
  • MCL — compiler complete (lexer/parser/validator/canonical/interpreter/IR/envelopes); real LLM via OpenAI-compat (Fireworks/Together).
  • bridge — live MCL ↔ cortex adapter (compile-time Find/Resolve/Context).
  • executor — plan walker, MCP client + tool registry, materiality classifier (D9), per-user daemon (HTTP + SSE), Liaison narrator.
  • neo — the default conversational agent: tool-calling loop, paged cortex memory, delegates monetary/irreversible work to MCL.
  • gateway — metered LLM proxy + PAX credit ledger (free-tier whitelist + rate card), live.
  • router — per-user Fly Machine provisioning + wake-then-proxy front door, live.
  • tachyon — agent-native Solidity/EVM engine; proven live on Paxeer chain 125.
  • uwac — universal web app connectors (OAuth vault → MCP tools).
  • chronos — centralized agent scheduler / wake-up system: design frozen.

Documentation


License

Source-available under the Matrix-Protocol License — see LICENSE.md.

Short version: read, use, deploy, integrate freely. If you modify and redistribute, release your changes under the same license. A commercial licence is required once you cross the commercial trigger thresholds (Charged Fees > USD 100k / 12 months or Liquidity Under Control > USD 10M). The non-binding summary in LICENSE.md is for convenience; the license body is authoritative.


Built by Paxlabs Inc. · SPDX-License-Identifier: LicenseRef-Paxlabs-Matrix-Protocol
