FlowCoder

Create and execute custom automated workflows for Claude Code and Codex, via a visual flowchart builder.

Requirements

• Python 3.12+
• uv
• Node.js 18+

Install & Run

uv sync
npm install
uv run python -m src.main

Quickstart

This repo contains a number of example flowcharts to help users understand the system. It is recommended you understand how they work by reviewing them in the Commands tab later, but right now let's try using them.

1. Go to the Sessions tab, click New Session, enter the name notepad-clone, and choose a fresh working directory. Hit Create Session.

2. In the Chat pane, under where it says "Input:", type /ex0-design-doc "Make a plain text editor Electron app. It should have all the features that Notepad on Windows 10 has." and hit enter. This is a very simple flowchart that prompts the agent to make a design doc for the given task, using argument substitution to fill in the prompt. (You can replace the plain text editor task with any other task of your choosing, it's just an example.)

3. The flowchart for that slash command will begin executing. When it finishes, you'll see "Execution completed: ex0-design-do" in the Output section.

4. Next, try /ex1-do-until-done DESIGN_DOC.md. This flowchart repeatedly prompts the agent to fully implement the specified design document until the agent is finished. Then the flowchart resets the agent's context, and prompts it to audit the implementation, further looping if the audit uncovers issues.

5. Note that the next couple examples are more time-consuming, as they involve flowcharts built for longer autonomous behavior. Try /ex2-testing-loop DESIGN_DOC.md. This is the flowchart from the preceding image: it writes a test suite that fits the design document, then loops between running tests via bash and prompting the agent to diagnose/fix test failures.

6. The final example is /ex3-improve-project [N] (replace [N] with any number, e.g. /ex3-improve-project 2). This example demonstrates for-loop behavior in a flowchart. The flowchart performs N iterations; in each iteration, the flowchart prompts the agent to design a new major feature for the codebase, then runs /ex1 and /ex2 for the new feature.

You can also run /all-examples to see all four examples executed sequentially.

Creating Commands

Commands are reusable workflows built from connected blocks in a flowchart. To create a command:

1. Click New Command in the Commands tab
2. Give your command a name (alphanumeric, hyphens, and underscores only)
3. Drag blocks from the Block Palette onto the canvas
4. Connect blocks by dragging from one block's output port to another's input port (branching special case below)
5. Configure each block by clicking on it and editing its properties

Block Types

Block	Purpose
Start	Entry point (required)
Prompt	Send a prompt to Claude and capture structured output
Bash	Execute shell commands
Variable	Set a variable to a value
Branch	Conditional branching based on variable values
Command	Invoke another command
Refresh	Restart the Claude session
Cast	Convert variable types
End	Exit point

Branch Blocks

Branch blocks evaluate a condition and follow either the True path (black arrow) or False path (blue arrow).

Creating connections:

• True path: Drag from a port to create a black arrow
• False path: Ctrl+Drag from a port to create a blue arrow

Condition syntax:

Format	Example	Description
field == value	status == "done"	Equality check
field != value	count != 0	Inequality check
field > value	score > 80	Greater than
field < value	attempts < 3	Less than
field >= value	progress >= 100	Greater than or equal
field <= value	errors <= 5	Less than or equal
field	isComplete	Boolean field (truthy check)
!field	!hasErrors	Negated boolean field

Variable Substitution

Blocks can reference variables from previous blocks:

• $1, $2, etc. - Positional arguments passed to the command
• {{variable_name}} - Variables set by previous blocks

Sessions

Sessions are isolated execution environments with their own working directory and Claude instance. (Multiple sessions at once is currently disabled due to an architectural issue leading to memory leaks.)

Creating a Session

1. Go to the Agents tab
2. Click New Session
3. Enter a session name and working directory
4. Optionally configure git remote settings

How Sessions Work

• Each session has its own working directory where Bash blocks execute
• Sessions maintain separate chat and execution history
• Commands run in the context of the active session
• Session data persists to ~/.flowcoder/sessions.json

Executing Commands

1. Select a session to make it active
2. Go to the Commands tab
3. Select a command and click Run (or use the play button)
4. Watch execution progress in the flowchart canvas
5. View results in the chat panel

Git Integration

FlowCoder initializes a git repository in each session's working directory and automatically commits changes after each Prompt or Bash block finishes executing. Commits are labeled with the block type and name.

Sessions can optionally be configured with:

• Git Remote URL: Configures an origin remote for the repository
• Branch: Checks out (or creates) a specific branch
• Auto Push: Automatically pushes to the remote after each commit

Agents Tab Buttons

Button	Description
⏸ Halt	Pauses execution after the current block finishes. The session enters a halted state and can be resumed later
▶ Resume	Continues execution from where it was halted
⏹ Stop	Stops execution after the current block finishes, then terminates the agent process
⏹ Force Stop	Immediately terminates the agent without waiting for the current block to finish. Use with caution as this may leave work incomplete
🔄 Refresh	Stops the agent and starts a fresh instance. Useful for resetting the agent's state

Troubleshooting

App crashes with UnknownLocaleError: unknown locale 'c'

This occurs on systems where the locale is set to C (common in minimal Linux environments, WSL, or Docker). Set a proper locale before running:

LANG=en_US.UTF-8 uv run python -m src.main

To make it permanent, add export LANG=en_US.UTF-8 to your ~/.bashrc.
