Maze Solver

A complete end-to-end system for recognizing maze images, extracting maze structure, and finding the optimal path from start to exit using computer vision and path-finding algorithms.

Overview

This project implements a complete maze solver system with the following capabilities:

1. Image Acquisition: Read maze images from files or camera input
2. Image Preprocessing: Enhance and clean the image to extract maze structure
3. Structure Extraction: Convert the maze into a graph representation with nodes and edges
4. Path Finding: Use A* algorithm to find the optimal path from start to exit
5. Visualization: Display the solved maze overlaid on the original image

Supported Input Formats

• Static Images: PNG, JPG, JPEG, BMP
• Camera Capture: With perspective correction

System Architecture

The system is divided into 4 main pipelines:

Input Image
    ↓
[Acquisition Pipeline] → Image Validation & Loading
    ↓
[Preprocessing Pipeline] → Image Enhancement & Binary Conversion
    ↓
[Structure Extraction Pipeline] → Graph Generation
    ↓
[Pathfinding Module] → A* Search Algorithm
    ↓
[Visualization] → Solution Output

Pipeline Details

1. Acquisition Pipeline (src/acquisition/)

• Loads images from file paths
• Validates image format and existence
• Returns image as numpy array

2. Preprocessing Pipeline (src/preprocessing/)

• Grayscale Conversion: Converts RGB to grayscale
• Perspective Correction: Corrects skewed images from camera capture
• Denoising: Median filtering to remove salt-and-pepper noise
• Thresholding: Otsu's method to create binary image
• Morphological Operations: Dilation and erosion for edge enhancement
• Background Removal: Isolates maze region from borders
• Endpoint Detection: Identifies maze start and exit points

3. Structure Extraction Pipeline (src/structure_extraction/)

• Skeletonization: Creates a 1-pixel wide representation of maze paths
• Cell Segmentation: Divides skeleton into grid cells
• Node Detection: Identifies junction points and endpoints
• Graph Construction: Builds adjacency list of connected nodes

4. Pathfinding Module (src/shortest-path/)

• A Algorithm*: Finds optimal path using Manhattan distance heuristic
• Returns ordered list of nodes from start to goal

Algorithms Used

1. Otsu's Thresholding

• Purpose: Convert grayscale image to binary (black/white)
• Method: Automatically finds optimal threshold value by minimizing within-class variance
• Implementation: src/preprocessing/thresholding.py
• Reference: Otsu, N. (1979). A threshold selection method from gray-level histograms

2. Morphological Operations

• Erosion: Shrinks white regions to remove thin noise
• Dilation: Expands white regions to fill small gaps
• Purpose: Clean binary image and connect broken paths
• Implementation: src/preprocessing/morphology.py

3. Skeletonization

• Purpose: Reduce maze paths to 1-pixel width while preserving connectivity
• Algorithm: Used from scikit-image (medial axis transform)
• Implementation: src/structure_extraction/sturcture_extraction_pipeline.py

4. Edge Detection (Canny)

• Purpose: Detect boundaries in perspective correction
• Implementation: src/preprocessing/edge_detection.py
• Parameters: Sigma=2.0 with adaptive thresholding

5. Cell Segmentation

• Purpose: Divide maze into regular grid cells
• Method: Fixed cell size (9x9 pixels) with threshold-based cell activation
• Implementation: src/structure_extraction/sturcture_extraction_pipeline.py

6. A Pathfinding Algorithm*

• Purpose: Find optimal path from start to goal node
• Heuristic: Manhattan distance (|x1-x2| + |y1-y2|)
• Time Complexity: O(b^d) where b is branching factor, d is depth
• Space Complexity: O(b^d)
• Implementation: src/shortest-path/AStar.py
• Key Advantage: Faster than Dijkstra with admissible heuristic

7. Perspective Correction (Homography)

• Purpose: Correct skewed images from camera capture
• Method: Detects paper corners and applies perspective transform
• Implementation: src/preprocessing/extract_paper.py

8. Endpoint Detection

• Purpose: Find maze start and exit points
• Method: Scans borders for gaps in skeleton, finds 2 farthest gaps
• Implementation: src/preprocessing/detect_endpoints.py

Libraries & Dependencies

Library	Version	Purpose
NumPy	>=1.20.0	Numerical computations and array operations
scikit-image	>=0.18.0	Image processing (thresholding, morphology, skeletonization, edge detection)
Matplotlib	>=3.3.0	Image visualization and result display
Python	>=3.8	Core language

Installation via pip

pip install numpy scikit-image matplotlib

Installation via conda

conda install numpy scikit-image matplotlib

Installation & Setup

Prerequisites

• Python 3.8 or higher
• pip or conda package manager

Step 1: Clone the Repository

git clone <repository-url>
cd maze-solver

Step 2: Create Virtual Environment (Recommended)

# Using venv
python -m venv venv
source venv/bin/activate  # On Windows: venv\Scripts\activate

# Using conda
conda create -n maze-solver python=3.9
conda activate maze-solver

Step 3: Install Dependencies

pip install numpy scikit-image matplotlib

Or create a requirements file:

pip freeze > requirements.txt
pip install -r requirements.txt

Step 4: Verify Installation

python -c "import numpy, skimage, matplotlib; print('All libraries installed successfully!')"

Command Line Parameters

For camera input, set the flag to y:

• Enables perspective correction for skewed images
• Use for images taken with phone cameras at angles

For static images, set the flag to n:

• Skips perspective correction
• Use for scanned or properly aligned images

Project Structure

maze-solver/
├── solve_maze.py                    # Main solver with visualization
├── README.md                        # This file
├── Phase 1 Proposal.pdf            # Original project proposal
│
├── src/
│   ├── acquisition/                 # Image input handling
│   │   ├── __init__.py
│   │   ├── acquisition_pipeline.py  # Main acquisition logic
│   │   └── validate_image.py        # Image validation
│   │
│   ├── preprocessing/               # Image enhancement & binary conversion
│   │   ├── __init__.py
│   │   ├── preporcess_pipeline.py   # Main preprocessing flow
│   │   ├── detect_endpoints.py      # Start/end point detection
│   │   ├── edge_detection.py        # Canny edge detection
│   │   ├── extract_paper.py         # Perspective correction
│   │   ├── filters.py               # Median filtering
│   │   ├── histogram.py             # Histogram equalization
│   │   ├── localization.py          # Maze localization
│   │   ├── morphology.py            # Erosion & dilation
│   │   ├── remove_background.py     # Background removal
│   │   └── thresholding.py          # Otsu thresholding
│   │
│   ├── structure_extraction/        # Maze graph generation
│   │   ├── __init__.py
│   │   ├── sturcture_extraction_pipeline.py  # Main extraction logic
│   │   └── find_nearest_node.py     # Node mapping utility
│   │
│   ├── shortest-path/               # Pathfinding algorithm
│   │   ├── AStar.py                 # A* implementation
│   │   └── test.py                  # Algorithm tests
│   │
│   ├── visualization/               # Result visualization
│   │   ├── visualize_on_image.py    # Overlay visualization
│   │   └── test.png                 # Test visualization output
│   │
│   └── utils/                       # Utility functions
│       ├── __init__.py
│       └── show.py                  # Image display utilities
│
├── samples/                         # Test images
    ├── easy/                        # Simple mazes
    │   ├── image.png
    │   ├── image2.png
    │   ├── image8.png
    │   ├── image10.png
    │   └── image12.png
    ├── mobile/                      # Mobile camera captures
    │   └── image15.png
    └── no_path/                     # Mazes with no solution
        └── image.png

Test Cases

Test Categories

1. Easy Mazes (samples/easy/)

• Description: Simple, well-defined maze structures
• Expected Behavior: Quick solution with clear paths
• Files: image.png, image2.png, image8.png, image10.png, image12.png
• Test Purpose: Verify basic functionality and correctness

Example Test:

python solve_maze.py
# Enter: easy/image.png
# Enter: n
# Expected: Solution found with few nodes

2. Mobile Captures (samples/mobile/)

• Description: Mazes photographed with mobile camera (perspective skew)
• Expected Behavior: Perspective correction handles skew
• Files: image15.png
• Test Purpose: Validate perspective correction and camera robustness

Example Test:

python solve_maze.py
# Enter: mobile/image15.png
# Enter: y
# Expected: Perspective corrected, solution found

3. No Path Cases (samples/no_path/)

• Description: Disconnected maze with no valid solution
• Expected Behavior: Return None or "No path found" message
• Files: image.png
• Test Purpose: Verify error handling and edge case management

Example Test:

python solve_maze.py
# Enter: no_path/image.png
# Enter: n
# Expected: "No path found" message

Results & Performance

Performance Metrics

Strength Points

• ✅ Robust preprocessing: Handles various image qualities
• ✅ Optimal path-finding: A* guarantees shortest path
• ✅ Flexible input: Works with both static images and camera captures
• ✅ Clear visualization: Easy to interpret results
• ✅ Modular design: Easy to modify individual components

Weakness & Limitations

• ⚠️ Perspective correction: Works best with clear paper boundaries
• ⚠️ Mobile images: Requires camera=y flag for best results
• ⚠️ Complex mazes: Processing time increases with larger images
• ⚠️ Endpoint detection: May fail with unusual maze configurations
• ⚠️ Fixed cell size: 9x9 pixel cells work best for 100-200 DPI images

Known Limitations

1. Image Resolution Dependent: Cell segmentation uses fixed 9x9 pixel cells

   • Solution: Adjust cell_size parameter in sturcture_extraction_pipeline.py

2. Perspective Correction: Requires clear paper boundaries and good lighting

   • Solution: Use well-lit images with visible paper edges

3. Endpoint Detection: Assumes exactly 2 endpoints (start and exit)

   • Failure Case: Multi-exit mazes or unclear borders

4. Fixed Grid Structure: Works best with regular maze layouts

   • Failure Case: Circular or hexagonal mazes

5. No Maze Validation: Doesn't verify maze structure before solving

   • Impact: Invalid mazes may produce unexpected results

Contributors

Alyaa Ali	Shady Mohamed	Hagar Abdelsalam	Saleh Ahmed
