Mini Deployment Platform 🚀

A lightweight Platform-as-a-Service (PaaS) that automatically deploys applications from GitHub repositories using Docker and Kubernetes (K3s).

🎥 Platform Demo

Users submit a GitHub repository, and the platform automatically:

• Clones the repository

• Builds a Docker image

• Pushes the image to Docker Hub

• Deploys the container to Kubernetes

• Exposes the application publicly

This project demonstrates DevOps, container orchestration, and platform engineering concepts.

Author

Anantha Sridhar

DevOps • Platform Engineering • Cloud Infrastructure

Prerequisites

Before setting up the platform, ensure you have:

• AWS account
• Docker Hub account
• A purchased domain
• SSH client
• Git installed

Basic knowledge of:

• Docker
• Kubernetes
• Linux commands

Architecture

                                User
                                │
                                │ Submit GitHub Repo
                                ▼
                                FastAPI Deployment API
                                │
                                ▼
                                GitHub Repository
                                │
                                ▼
                                Docker Build
                                │
                                ▼
                                Docker Hub Registry
                                │
                                ▼
                                Kubernetes (K3s)
                                │
                                ▼
                                Traefik Ingress
                                │
                                ▼
                                Public URL

Tech Stack

Component	Usage
FastAPI	Backend deployment API
Docker	Containerization
Docker Hub	Image registry
Kubernetes (K3s)	Container orchestration
Traefik	Ingress controller
AWS EC2	Infrastructure

Step 0

• Before deploying the platform, you must update the configuration variables in the code.

• Open the configuration file (usually in the backend where deployments are handled) and replace the placeholder values:

DOCKER_USERNAME = "DOCKER_USERNAME"
DOMAIN = "YOUR_DOMAIN"
DOCKER_REPO = "YOUR_DOCKER_HUB_REPO"

Example:

DOCKER_USERNAME = "Anantha Sridhar"
DOMAIN = "deploywithanantha.xyz"
DOCKER_REPO = "mini-platform"

These values are required for the platform to correctly build, push, and expose deployed applications.

1️⃣ Create a Docker Hub Repository

Go to:

https://hub.docker.com

Create a new repository.

Example:

Repository Name: mini-platform-images

Why this is required:

• Kubernetes does not build images.
• It pulls images from a container registry.

Without a Docker repository, Kubernetes cannot deploy the application containers.

2️⃣ Buy a Domain

You must purchase a domain for exposing deployed applications.

Recommended providers:

Namecheap
Cloudflare
Google Domains

Example domain:

deploywithanantha.xyz

This domain will be used to route traffic to applications deployed in Kubernetes.

3️⃣ Configure DNS

Add an A record pointing to your Elastic IP.

Example:

Type	Name	Value
A	@	EC2 Elastic IP

Example result:

deploywithanantha.xyz → 54.xx.xx.xx

Step 1 — Create an AWS EC2 Instance

Go to AWS Console → EC2 → Launch Instance

Configuration:

Setting	Value
OS	Ubuntu 22.04
Instance Type	t2.micro / t3.micro
Storage	20GB
Key Pair	Create .pem key

Download the key file.

Example:

Demo_Docker.pem

Step 2 — Configure Security Group

Add the following inbound rules.

Type	Port
SSH	22
HTTP	80
HTTPS	443
Custom TCP	8000

Why these ports?

Port	Purpose
22	SSH access
80	HTTP traffic
443	HTTPS
8000	FastAPI server

Step 3 — Allocate Elastic IP

AWS public IPs change when the instance restarts.

• Elastic IP ensures:

• Stable domain mapping

• Stable HTTPS certificates

• Permanent public endpoint

Go to:

EC2 → Elastic IPs → Allocate

Then associate it with your instance.

Step 4 — Connect to EC2

ssh -i "<your_pem_file.pem>" ubuntu@<elastic-ip>

Example:

ssh -i "<your_pem_file.pem>" ubuntu@54.210.xx.xx

Step 5 — Install Docker

sudo apt update
sudo apt install docker.io -y

sudo systemctl enable docker
sudo systemctl start docker

sudo usermod -aG docker ubuntu

logout

docker ps

Step 6 — Install Kubernetes (K3s)

K3s is a lightweight Kubernetes distribution.

Install it:

curl -sfL https://get.k3s.io | sh -

Check installation:

sudo kubectl get nodes

Expected output:

Ready control-plane

Step 7 — Configure kubectl

Copy kubeconfig to your user.

sudo mkdir -p ~/.kube
sudo cp /etc/rancher/k3s/k3s.yaml ~/.kube/config
sudo chown ubuntu:ubuntu ~/.kube/config

Set environment variable:

export KUBECONFIG=/home/ubuntu/.kube/config

Verify:

kubectl get nodes

Step 8 — Install Python Environment

sudo apt install python3 python3-pip python3-venv -y

Clone the project.

git clone https://github.com/YOUR_USERNAME/mini_deployment_platform
cd mini_deployment_platform

Create virtual environment.

python3 -m venv env
source env/bin/activate

Install dependencies.

pip install -r requirements.

Step 9 — Docker Hub Login

Login to Docker Hub.

docker login

Why is a Docker registry needed?

- Kubernetes does not build images.

- It only pulls images from registries.

Deployment flow:

Code → Docker Build → Docker Hub → Kubernetes pulls image

Without a registry Kubernetes cannot deploy containers.

Step 10 — Run the Deployment API

Start the backend.

uvicorn app.main:app --host 0.0.0.0 --port 8000

Access the API documentation.

http://<elastic-ip>:8000/

Step 13 — HTTPS Setup

If Kubernetes commands fail because of config issues:

export KUBECONFIG=/home/ubuntu/.kube/config

Traefik can automatically generate HTTPS certificates using Let's Encrypt.

Repository Structure Required for Deployment

Applications must contain a Dockerfile.

Example structure:

my-app
│
├── Dockerfile
├── requirements.txt
├── main.py
│
├── app
│   └── main.py
│
└── README.md

Example Dockerfile

FROM python:3.10-slim

WORKDIR /app

COPY requirements.txt .

RUN pip install -r requirements.txt

COPY . .

CMD ["uvicorn","main:app","--host","0.0.0.0","--port","8000"]

Important Deployment Rules

Applications must:

• Include a Dockerfile

• Expose port 8000

• Bind to 0.0.0.0

Example:

uvicorn main:app --host 0.0.0.0 --port 8000

Deployment Flow

When a user submits a repository:

POST /deploy

Example request:

{
 "github_url": "https://github.com/user/app"
}

Internal process:

1. Clone repository
2. Build Docker image
3. Push image to Docker Hub
4. Generate Kubernetes YAML
5. Deploy container
6. Create service
7. Expose application

Debugging Errors

No Server Available Error

Sometimes old deployments consume resources.

Delete previous deployments.

kubectl get deployments

Then remove unused apps.

kubectl delete deployment <deployment-name>

Example:

kubectl delete deployment testapp

Kubernetes Commands Not Working

Run:

export KUBECONFIG=/home/ubuntu/.kube/config

Docker Permission Error

Fix permissions.

sudo usermod -aG docker ubuntu

Then reconnect to the server.

SSH Host Key Changed

Run:

ssh-keygen -R <ec2-host>

Future Improvements

• Dynamic subdomains for deployed apps

• GitHub webhook auto-deploy

• Horizontal Pod Autoscaling

• Multi-node Kubernetes cluster

• Deployment Dashboard

• Auto-detect project type
