Nelua-Mini

A library for developing Pokemon Mini homebrew in Nelua, targeting the Epson S1C88 8-bit CPU. Nelua source compiles to C89 via an intermediate conversion step, then builds into a .min ROM using the TASKING E0C88 toolchain.

Prerequisites

• TASKING E0C88 Toolchain: Install via c88-pokemini:

  cd C:\Users\your-user\c88-pokemini
  .\install.ps1

• Nelua: nelua.io
• PokeMini Emulator

Getting Started

Build and run an example from its directory:

cd examples\demo
.\build.ps1                  # Build ROM
.\build.ps1 run              # Build and run in emulator

Or build any source file directly from the project root:

.\tools\build.ps1 -Source examples\text\main.nelua
.\tools\build.ps1 run -Source examples\sqaure\main.nelua

The output ROM is written to build\<name>.min.

Build targets:

Target	Description
all	Full build (default)
run	Build and launch in emulator
clean	Remove build artifacts
rebuild	Clean, then full build

Project Structure

src/
  pmhw.nelua              Hardware abstraction layer (the library)
examples/
  sqaure/
    main.nelua             Example application
tools/
  build.ps1               Build script
  c99_to_c89.ps1          C99 to C89 converter for TASKING cc88
toolchain/
  crt0.asm                Startup assembly (vectors, ROM header)
  pokemini.dsc            TASKING software description
  s1c88_pokemini.cpu      TASKING CPU description
  s1c88.mem               TASKING memory description
neluacfg.lua              Nelua compiler configuration

Build Pipeline

The build process chains several tools:

1. nelua -- Compile Nelua source to C99
2. c99_to_c89.ps1 -- Convert C99 to C89 (TASKING cc88 only supports C89)
3. as88 -- Assemble startup code (crt0.asm)
4. cc88 -- Compile C89 to object files
5. lk88 -- Link objects with the TASKING runtime library
6. lc88 -- Locate code/data at target memory addresses
7. srec_cat -- Convert S-record output to binary ROM

Library Usage

The hardware abstraction layer (src/pmhw.nelua) provides:

Display

Function	Description
init_hw()	Initialize hardware (clock, PRC, framebuffer)
clear_screen()	Clear the framebuffer
fill_screen(pattern)	Fill framebuffer with a byte pattern
set_pixel(x, y, color)	Set a single pixel (bounds-checked)
get_pixel(x, y)	Read a single pixel
flip_buffer()	Trigger LCD refresh from GDDRAM
wait_vsync()	Block until PRC frame complete

Drawing

Function	Description
draw_hline(x, y, w, color)	Horizontal line
draw_vline(x, y, h, color)	Vertical line
draw_rect(x, y, w, h, color)	Rectangle outline
fill_rect(x, y, w, h, color)	Filled rectangle

Input

Function	Description
poll_input()	Returns bitmask of pressed keys

Key constants: KEY_A, KEY_B, KEY_C, KEY_UP, KEY_DOWN, KEY_LEFT, KEY_RIGHT, KEY_POWER.

Fixed-Point Math

Two fixed-point types are provided for arithmetic without floating point:

• Fixed8_8 -- 8.8 format (8 integer bits, 8 fractional bits). Supports add, sub, mul, div, comparison.
• Fixed12_4 -- 12.4 format (12 integer bits, 4 fractional bits). Supports add, sub, mul.

Writing Your Own Program

Create a new .nelua file (or modify examples/demo/main.nelua):

## pragma{nogc = true, nochecks = true}

require 'pmhw'

local function main(): void <entrypoint>
  init_hw()
  clear_screen()
  fill_rect(10, 10, 20, 20, 1)

  while true do
    wait_vsync()
  end
end

Update the $NeluaSource path in tools/build.ps1 to point to your file, then run the build.

Development Constraints

• No garbage collector. All Nelua files must include ## pragma{nogc = true}.
• No static initializers. The __copytable routine is stubbed. Initialize data at runtime.
• C89 target. The TASKING cc88 compiler does not support C99. The converter script handles the translation automatically.
• 16-bit int. The S1C88 has 16-bit int and 32-bit long.

Memory Map

Address	Size	Description
0x0000--0x0FFF	4 KB	BIOS (reserved)
0x1000--0x12FF	768 B	GDDRAM (framebuffer, 96x64 1bpp)
0x1300--0x1FFF	3.25 KB	General-purpose RAM
0x2000--0x20FF	256 B	I/O registers
0x2100+	up to 2 MB	Cartridge ROM

TASKING Assembler Notes

The TASKING as88 assembler uses different mnemonics than standard S1C88 documentation:

TASKING	Standard S1C88	Description
LD	MOV	Load/move
CARL	CALL	Call (relative long)
JRL	JMP	Jump (relative long)
RETE	RETI	Return from interrupt

Resources

• Pokemon Mini Hardware Documentation
• S1C88 Instruction Set
• c88-pokemini Toolchain
• Nelua Language
