Akai APC Mini Mk2

An easy-to-use and feature-rich Node.js package for interacting with one or multiple Apc Mini's (Mk2) from Akai Professional. It features Full RGB LED color support, button/slider events, input polling, startup animations & so much more! Perfect for scripts, Electron apps, automation, smart home, music production, games, event lightning, ...

Need help? Feel free to join our support server and we will help you fruther!

Installation using npm ⬇️

npm install apc-mini-mk2

❤️ Sponsors

We're still searching for sponsors! Would you like to sponsor us?

📌 Features

• ⚖️ Lightweight — Minimal footprint, maximum performance.
• 🚨 Built with TypeScript — Enjoy full type safety and intelligent autocompletion.
• 🎨 Full RGB Color Support — Display awesome RGB lights with full (0-255) RGB.
• 🔢 Multiple Controllers — Use multiple controllers at the same time.
• ⚙️ Highly Customizable — Choose your own coordinate system, limits & more.
• 🪩 Built-in Effects — Choose between 20+ built-in pulse, flicker & fade effects.
• 📌 Coordinates — Use a location index or (x,y) coordinates for inputs & outputs.
• 🪦 Preserves State — Preserve the state of the LEDs when disconnected.
• 📢 Event Driven — Listen to events and define your own custom reactions.
• 🎯 Input Polling — Fetch the current state of sliders & buttons without events.
• 🎬 Startup Animations — Display RGB animations while the device is connecting.
• ✅ Multi Platform — Tested on MacOS & Windows. Linux is untested but should work.

📸 Examples

Images will be added to the README soon!

🛠️ Quick Usage

TIP: Detailed examples are available in the ./examples/ directory in the Github repository.

const {APCMiniController,rgbToHex,hexToRgb} = require("apc-mini-mk2")
//import {APCMiniController,rgbToHex,hexToRgb} from "apc-mini-mk2"

const apcMini = new APCMiniController(2) //max 2 controllers

//list all connected controllers
apcMini.listAvailableControllers()

//listen for errors
apcMini.on("error",(err) => {
    console.error(err)
})

//listen for connected & disconnected controllers
apcMini.on("connect",(id,midiName) => {
    console.log("Apc with id "+id+" and name "+midiName+" connected succesfully!")
})
apcMini.on("disconnect",(id,midiName) => {
    console.log("Apc with id "+id+" and name "+midiName+" disconnected!")
})

//automatically connecting APC Mini Mk2 controllers
apcMini.startAutoConnect()

// RGB LIGHT EXAMPLES:
//(1) first light: static cyan
//(2) light 2 & 3: static red
//(3) last light & (3,3): blinking white
//(4) first 3 lights on second controller: fading-out blue

apcMini.setRgbLights(0,0,"brightness_100","static","#00ffff")
apcMini.setRgbLights(0,[1,2],"brightness_100","static","#ff0000")
apcMini.setRgbLights(0,[63,{x:3,y:3}],"brightness_10","blinking_1/2","#ffffff")
apcMini.setRgbLights(1,[0,1,2],"brightness_100","fade_out_1/2","#0000ff")

//set & configure horizontal/vertical sidebar lights
apcMini.setHorizontalLights(0,[0,2,3,6],"blink")
apcMini.setVerticalLights(1,[0,1,2,3,4,7],"on")

//listen for button events
apcMini.on("padButtonChanged",(id,location,coords,pressed,shift) => {
    console.log("pad button event:",pressed,location,coords,"withShift: "+shift,"controller: "+id)
})
apcMini.on("horizontalButtonChanged",(id,location,pressed,shift) => {
    console.log("horizontal button event:",pressed,location,"withShift: "+shift,"controller: "+id)
})
apcMini.on("verticalButtonChanged",(id,location,pressed,shift) => {
    console.log("vertical button event:",pressed,location,"withShift: "+shift,"controller: "+id)
})
apcMini.on("sliderChanged",(id,location,value) => {
    console.log("slider changed:",location,value)
})

//poll current state of buttons & sliders
console.log("horizontal buttons:",apcMini.getHorizontalStates(0))
console.log("rgb pads:",apcMini.getPadStates(0))
console.log("sliders:",apcMini.getSliderValues(0))

🧩 API Reference

View full examples in Github Repository

---

📦 Main Class: APCMiniController

This is the main class used to connect, manage and control APC Mini Mk2 devices.
Almost all described functions are a method of this class.

Construction Parameters:

• maxControllerAmount? (number): Maximum simultaneously connected controllers. Default: 1
• manualIdAssignmentsEnabled? (boolean): Require manually selecting device IDs by pressing a horizontal button.
• coordinates? (APCMiniCoordinateSystem): Custom coordinate orientation of the 8×8 RGB grid.
• lightBpm? (number): BPM used for blinking/pulsing modes. Default: 60

✅ Properties

• (lightBpm: number) The BPM used for pulsing/blinking light effects.
• (maxControllerAmount: number) Maximum allowed connected APC Mini devices.
• (manualIdAssignmentsEnabled: boolean) Enables manual device ID assignment via pad press during connection.
• (coordinates: APCMiniCoordinateSystem) The coordinate system mapping used for pad grid orientation.

---

🔌 Connection Management

function startAutoConnect(): void

Begins automatically detecting and connecting APC Mini controllers until the max limit is reached.

function stopAutoConnect(): void

Stops auto-connecting new controllers.

function manualConnect(midiName, customId?): boolean

Connects to a specific controller by MIDI name.
Returns false on failure.

Parameters:

• midiName (string): Name from listAvailableControllers().
• customId? (number): Optional forced ID number.

function manualDisconnect(midiNameOrId): boolean

Disconnect a controller by MIDI name or ID.
Returns false on failure.

Parameters:

• midiNameOrId (string | number): The controller name or ID.

function manualDisconnectAll(): boolean

Disconnects all currently connected controllers.
Returns false on failure.

function listAvailableControllers(): string[]

Returns all unused / available APC Mini Mk2 device names.

function listConnectedControllers(): string[]

Returns all currently connected controller names.

function listUsedIds(): number[]

Returns all assigned controller IDs.

function getConnectedAmount(): number

Returns how many controllers are currently connected.

function setBpm(bpm): void

Sets the blinking/pulsing BPM for all RGB LED effects.

Parameters:

• bpm (number): New BPM value.

---

🎛️ Event Handling

Each .on(event, callback) registers a listener for one of the following events:

event connect

Triggered when a controller successfully connects.

Callback: (controllerId: number, midiName: string) => void

event disconnect

Triggered when a controller disconnects.

Callback: (controllerId: number, midiName: string) => void

event error

Triggered upon connection errors or failures with lights or buttons.
If the error is specific to a controller, it will include the ID.

Callback: (err: string, controllerId?: number) => void

---

🎛️ Pad Button Events

event padButtonPressed

Triggered when one of the 64 pad buttons has been pressed.
The location & coordinates correspond to the selected coordinate system.

Callback: (controllerId: number, location: number, coordinates: APCMiniCoordinates, usingShift: boolean) => void
Location Values: (0-63)

event padButtonReleased

Triggered when one of the 64 pad buttons has been released.
The location & coordinates correspond to the selected coordinate system.

Callback: (controllerId: number, location: number, coordinates: APCMiniCoordinates, usingShift: boolean) => void
Location Values: (0-63)

event padButtonChanged

Triggered when one of the 64 pad buttons has changed states (pressed/released).
The current state of the button is available in the pressed parameter.

Callback: (controllerId: number, location: number, coordinates: APCMiniCoordinates, pressed: boolean, usingShift: boolean) => void
Location Values: (0-63)

---

🎛️ Horizontal/Vertical Button Events

event horizontalButtonPressed / verticalButtonPressed

Triggered when one of the 8 horizontal or vertical buttons has been pressed.

Callback: (controllerId: number, location: number, usingShift: boolean) => void
Location Values: (0-7)

event horizontalButtonReleased / verticalButtonReleased

Triggered when one of the 8 horizontal or vertical buttons has been released.

Callback: (controllerId: number, location: number, usingShift: boolean) => void
Location Values: (0-7)

event horizontalButtonChanged / verticalButtonChanged

Triggered when one of the 8 horizontal or vertical buttons has changed states (pressed/released).
The current state of the button is available in the pressed parameter.

Callback: (controllerId: number, location: number, pressed: boolean, usingShift: boolean) => void
Location Values: (0-7)

---

🎛️ Shift Button Events

event shiftButtonPressed

Triggered when one of the shift buttons on any controller has been pressed.

Callback: (controllerId: number) => void): void

event shiftButtonReleased

Triggered when one of the shift buttons on any controller has been released.

Callback: (controllerId: number) => void): void

event shiftButtonChanged

Triggered when one of the shift buttons on any controller has changed states (pressed/released).
The current state of the button is available in the pressed parameter.

Callback: (controllerId: number, pressed: boolean) => void

---

🎛️ Slider Events

event sliderChanged

Triggered when one of slider values changes.
The current state of the slider is available in the value parameter.

Callback: (controllerId: number, location: number, value: number) => void
Location: (0-8), Value: (0-127)

---

🌈 RGB & Light Control

function setRgbLights(controllerId, positions, brightness, mode, color): boolean

Set RGB pad color, brightness and animation (mode) for one or many pads.

Parameters:

• controllerId (number): The Controller ID
• positions (number|APCMiniCoordinates|Array<...>): Pads to change.
• brightness (APCMiniBrightnessMode): Brightness of the LEDs.
• mode (APCMiniLightMode): static or one of the available LED Effects.
• color (string): Hex color (e.g. #f8ba00)

function setHorizontalLights(controllerId, positions, mode): boolean

Changes the horizontal (red) button LEDs.

Parameters:

• positions (number|number[]): A position from 0–7.
• mode ("off"|"on"|"blink"): The LED effect to apply.

function setVerticalLights(controllerId, positions, mode): boolean

Changes the vertical (green) button LEDs.

Parameters:

• positions (number|number[]): A position from 0–7.
• mode ("off"|"on"|"blink"): The LED effect to apply.

function resetLights(controllerId): boolean

Turns off all lights for a specific controller.

function resetAllLights(): boolean

Turns off all lights for all controllers.

function fillRgbLights(controllerId, startPos, width, height, brightness, mode, color): boolean

Fills a rectangular region of pads with an RGB color/mode.

Parameters:

• controllerId (number): The Controller ID
• startPos (number|APCMiniCoordinates): Start position.
• width (number): Width of the rectangle (follows the coordinate system).
• height (number): Height of the rectangle (follows the coordinate system).
• brightness (APCMiniBrightnessMode): Brightness of the LEDs.
• mode (APCMiniLightMode): static or one of the available LED Effects.
• color (string): Hex color (e.g. #f8ba00)

---

📊 State Polling

function getShiftState(): boolean

Returns whether any controller has its Shift button pressed.

function getPadStates(controllerId): boolean[]

Returns pressed state of all 64 RGB pads.

Parameters:

• controllerId (number): The Controller ID

function getHorizontalStates(controllerId): boolean[]

Returns state of horizontal buttons.

Parameters:

• controllerId (number): The Controller ID

function getVerticalStates(controllerId): boolean[]

Returns state of vertical buttons.

Parameters:

• controllerId (number): The Controller ID

function getSliderValues(controllerId): number[]

Returns slider values (0–127) for the specified controller.

Parameters:

• controllerId (number): The Controller ID

---

🎬 Startup / Connection Animations

All 3 animation methods accept the following callback:
(time: number, currentFrame: Map<padLoc, hexColor>) => void

Parameters:

• time (number): The time since the start of the animation in milliseconds.
• currentFrame (Map<padLoc,hexColor>): The current (8x8) animation frame, changes made to this map will update the next frame.

function setIntroAnimation(animation, durationMs): void

Sets the animation displayed before the user selects the controller ID.

Parameters:

• animation (APCMiniPreconnectAnimation | null)
• durationMs (number): The duration of the intro animation.

function setWaitAnimation(animation): void

Animation played while selecting the controller ID.

Parameters:

• animation (APCMiniPreconnectAnimation | null)

function setOutroAnimation(animation, durationMs): void

Animation played after controller ID selection is completed.

Parameters:

• animation (APCMiniPreconnectAnimation | null)
• durationMs (number): The duration of the outro animation.

---

🎨 Utility Functions

Utility functions are available directly, outside the APCMiniController class.

function isHexColor(hexColor): hexColor is APCMiniHexColor

Checks if a string is a valid hex color.

function hexToRgb(hexColor): { red, green, blue }

Converts a hex color to 0–255 RGB values.

function rgbToHex(r, g, b): APCMiniHexColor

Converts RGB values into a hex color string.

function brightness(multiplier, hexColor): #xxxxxx

Modifies brightness of a hex color using a (0–1) multiplier.

function locationToCoordinates(location): APCMiniCoordinates

Converts a pad index (0–63) to X-Y coordinates.

function coordinatesToLocation(coordinates): number

Converts X-Y coordinates to a pad index (0–63).

🛠️ Contributors

All contributions are welcome! Feel free to create a pull-request or issue in the Github repository.

💻 DJj123dj

⭐️ Star History

Thank you for using our package! — support us by sharing it! 😁

---

v1.0.3 - README.md
© 2026 - DJdj Development - Discord - Terms - Privacy Policy - Support Us - License
