feat: DEV-4081: Implements Magic Wand tool for image segmentation

[BradNeuberg]

This pull request implements a Magic Wand, making it possible to click in a region of an image a user is doing segmentation labeling on, drag the mouse to dynamically change flood filling tolerance, then release the mouse button to get a new labeled area. It is particularly effective at labeling broad, diffuse, complex edged objects, such as clouds, cloud shadows, snow, etc. in earth observation applications or organic shapes in biomedical applications.

A short video of the tool in action can be seen here: https://www.youtube.com/watch?v=XxjqBx_0-wk

Detailed notes on its implementation can be seen at the top of src/tools/MagicWand.js.

[BradNeuberg]

Opened another PR to track this one more time, making a cleaner git history off of master using git cherry-pick to just pull over my changes, now that I've managed conflicts going from 1.6.0 to 1.7.0 release.

[BradNeuberg]

Note that examples/image_magic_wand/annotations/1.json points to a Google Cloud bucket for serving up some example images; before landing this we will want to copy these to your public bucket and change the path. Note that some CORS headers will also have to be set on that bucket in order for the Magic Wand to work from demo images served from it; those changes are documented in the START.md file.

[makseq]

Related feature request: #1118

[BradNeuberg]

There was a bug related to drawing several magic wand regions, hitting undo, then attempting to magic wand again -- the offscreen performance cache was incorrectly keeping the old undone region around. I've now fixed this bug with the latest commit to this PR.

[BradNeuberg]

I've pushed changes to put the Magic Wand behind a feature flag, though I'm still trying to figure out how to configure the Label Studio server to pick up this new flag. Conversation in Slack here: https://label-studio.slack.com/archives/CQ8LYPPJS/p1673472983241769?thread_ts=1671057042.347029&cid=CQ8LYPPJS

[BradNeuberg]

I've taken the QA teams input and made the Magic Wand threshold more robust with better UX. Magic Basically, we now calculate the Magic Wand thresholding from the entire screen, not just relative to the image. We also correctly allow you to drag in any direction to get positive or negative thresholding.

[hlomzik]

And urls on our bucket:

• https://htx-pub.s3.amazonaws.com/samples/magicwand/magic_wand_thumbnail_20200902_015806_26_2235_1B_AnalyticMS_00750_00750.jpg
• https://htx-pub.s3.amazonaws.com/samples/magicwand/magic_wand_scale_1_20200902_015806_26_2235_1B_AnalyticMS_00750_00750.jpg
• https://htx-pub.s3.amazonaws.com/samples/magicwand/magic_wand_scale_3_20200902_015806_26_2235_1B_AnalyticMS_00750_00750.jpg
• https://htx-pub.s3.amazonaws.com/samples/magicwand/magic_wand_false_color_20200902_015806_26_2235_1B_AnalyticMS_00750_00750.jpg
• https://htx-pub.s3.amazonaws.com/samples/magicwand/magic_wand_scale_2_20200902_015806_26_2235_1B_AnalyticMS_00750_00750.jpg

[BradNeuberg]

I've changed the paths of example/test images introduced in this PR to point to the Heartex bucket instead of my own.

Brandon already explained that all issue either addressed or existed before you PR

[BradNeuberg]

@hlomzik @bmartel Thanks for the review and approval. I'm still working on:

• Some integration tests for the brush & magic wand unselection bug I fixed in this PR (where if you are using the brush or magic wand tools, then use the eraser, then go back to the brush tool, you will end up with a new region, rather than having your new brush region get added to the existing one, due to the previous region incorrectly getting unselected). I especially want e2e integration tests for this to prevent it from regressing again (it worked 5 months ago but broke with a change that happened then).
• Pulling the latest label-studio server code and testing the Magic Wand against that with both the feature flag on and off a final time to ensure things are fine.
• Re-running all the integration tests to double check everything.

Once that is done, early next week, I'll report back here on this PR and it sounds like we might be able to land it on main?

[hlomzik]

Hi, Brad!
The last thing left is e2e failing because of CORS error (you can see this in screenshots attached as artifact to test runs). The problem here is that browser sometimes doesn't send CORS headers (or almost any headers) at all. Easily reproduced case is that one in test — when you select any other image from the gallery (thumbnails under the main image) it'll break with error. Should be checked with our urls, because unlike your GCS with static serving our AWS (and part of our clients') will serve only CORS requests, even if they are wide open/anonymous it still requires CORS headers. And browser doesn't send them on image switch.
My guess is there are some issues with updating image src or drawing context during image substitution, but I haven't been able to find it so far. If you have any ideas, it would be great!
Currently we decided to disable this part in test and merge it in current state. It was tested, there is a huge block of new code, you have no issues with your cloud, it's covered by feature flag and tests (except for this issue) — so it's safe to merge current state and deal with the rest in new PRs.

[BradNeuberg]

@hlomzik How are you running the integration tests? I think it might be sensitive to how its run. For my setup, I first start the Label Studio frontend debug setup with npm run start, then in another window I run the integration tests as npm run test:local. This means everything is coming from the same domain, localhost on some port, so I don't have CORS issues and the Magic Wand works fine.

In a true deployment scenario of the integration tests, how are they run? That can give me a pointer to ensure things work for the Magic Wand e2e tests.

[BradNeuberg]

FYI I've fixed the S3/CORS integration issue in this PR: #1191

[BradNeuberg]

FYI e2e tests for the selection fixes here: #1192
