Examable — AI Assessment Platform

Upload your study materials. Get AI-generated exams in seconds.

🎯 About

Examable is a full-stack educational platform that uses Retrieval-Augmented Generation (RAG) to transform study materials into context-aware assessments. Upload a PDF or PowerPoint, specify your topics, and the AI generates exams grounded in your actual content — not hallucinated facts.

Key Features

📄 Multi-format Upload — PDF and PPTX support with automatic text extraction, chunking, and vector embedding
🧠 RAG-Powered Generation — Questions are generated from your actual documents using semantic retrieval + Gemini 2.5 Flash
📝 Three Question Types — Multiple Choice, True/False, and Short Answer with configurable difficulty
✅ Smart Grading — MCQ/TF graded instantly; Short answers graded via semantic similarity with difficulty-scaled thresholds
📊 Grading Reports — Detailed results with source citations traced back to page numbers
✏️ Editing Studio — Edit generated assessments: modify questions, reorder, add/remove before publishing
🔁 Retake Support — Re-attempt assessments with attempt tracking and score history
🗑️ Trash & Restore — Soft-delete with 30-day retention and one-click restore
🌙 Dark Mode — Full light/dark theme support
🔐 Secure Access — Per-user document ownership with Supabase Auth (PKCE flow)
♻️ Deduplication — SHA-256 hashing ensures identical files share embeddings while maintaining strict access control

📸 Screenshots

Dashboard	Exam Studio	Exam Mode

Grading Report	Library	Editing Studio

🏗️ Architecture

graph TB
    subgraph Frontend["Frontend — React + Vite"]
        UI[User Interface]
    end

    subgraph Backend["Backend — FastAPI"]
        API["REST API /api/v1"]
        Auth["JWT Auth"]
        Upload["Upload Service"]
        RAG["RAG Pipeline"]
        Grading["Grading Engine"]
    end

    subgraph AI["AI Services"]
        Gemini["Gemini 2.5 Flash"]
        Nomic["Nomic Embed v1.5"]
    end

    subgraph Data["Data Layer — Supabase"]
        PG["PostgreSQL"]
        PGV["pgvector"]
        Storage["File Storage"]
        SAuth["Supabase Auth"]
    end

    UI -->|"Bearer Token"| API
    API --> Auth
    Auth -->|JWKS| SAuth
    API --> Upload & RAG & Grading
    Upload --> Nomic
    Upload --> PGV & Storage & PG
    RAG --> Nomic
    RAG --> PGV
    RAG --> Gemini
    RAG --> PG
    Grading --> Nomic
    Grading --> PG

How the RAG Pipeline Works

Ingest — Documents are parsed (PyMuPDF / python-pptx), split into chunks, and embedded using Nomic Embed Text v1.5 (768 dimensions)
Retrieve — When generating an exam, each topic query is embedded and used for similarity search against pgvector, filtered to the user's selected documents
Generate — Retrieved context chunks are assembled with source metadata and sent to Gemini 2.5 Flash with a structured prompt enforcing Bloom's Taxonomy, self-containment, and JSON output
Grade — MCQ/TF are graded by index match; Short answers use cosine similarity between Nomic embeddings with difficulty-based thresholds (Easy: 0.75, Medium: 0.85, Hard: 0.92)

🛠️ Tech Stack

Layer	Technology
Frontend	React 18, TypeScript, Vite 5, TailwindCSS 3, React Router 7, Lucide Icons
Backend	Python 3.10, FastAPI, Pydantic v2, Uvicorn
Database	Supabase (PostgreSQL + pgvector)
Authentication	Supabase Auth (PKCE) + PyJWT (JWKS validation)
LLM	Google Gemini 2.5 Flash
Embeddings	Nomic Embed Text v1.5 (768-dim, via LangChain)
Vector Store	pgvector on Supabase (via `vecs` library)
File Storage	Supabase Storage
File Parsing	PyMuPDF (PDF), python-pptx (PPTX), tiktoken (token counting)
Deployment	Vercel (frontend), Docker Compose (backend)

📂 Project Structure

CapstoneProject/
├── src/                          # Frontend (React + TypeScript)
│   ├── App.tsx                   # Router and route definitions
│   ├── AppContext.tsx             # Global state management
│   ├── ToastContext.tsx           # Toast notification system
│   ├── Layout.tsx                # Dashboard shell (sidebar + content)
│   ├── api.ts                    # HTTP client (GET, POST, PUT, PATCH, DELETE)
│   ├── supabase.tsx              # Supabase client initialization
│   ├── types.ts                  # TypeScript interfaces
│   └── components/
│       ├── LandingPage.tsx       # Public landing page
│       ├── AuthPage.tsx          # Login / signup
│       ├── Dashboard.tsx         # Home dashboard with stats & activity
│       ├── Library.tsx           # Document upload & management
│       ├── ExamStudio.tsx        # Exam creation entry point
│       ├── CreationStudio.tsx    # Assessment configuration form
│       ├── AssessmentsHub.tsx    # Assessment list & management
│       ├── EditingStudio.tsx     # Edit existing assessments
│       ├── ExamMode.tsx          # Take an exam (question-by-question)
│       ├── GradingReport.tsx     # View results & source citations
│       ├── Profile.tsx           # User profile settings
│       ├── Trash.tsx             # Soft-deleted items management
│       ├── Navigation.tsx        # Sidebar navigation
│       ├── NotificationBell.tsx  # In-app notifications
│       └── Toast.tsx             # Toast notification component
│
├── backend/                      # Backend (Python + FastAPI)
│   ├── app/
│   │   ├── main.py              # FastAPI app, lifespan, CORS config
│   │   ├── auth.py              # JWT/JWKS authentication
│   │   ├── tasks.py             # Document processing pipeline
│   │   ├── api/v1/
│   │   │   ├── api.py           # Router aggregator
│   │   │   └── endpoints/       # Route handlers
│   │   │       ├── documents.py
│   │   │       ├── assessments.py
│   │   │       ├── trash.py
│   │   │       ├── activity.py
│   │   │       ├── notifications.py
│   │   │       └── user.py
│   │   ├── schemas/             # Pydantic models
│   │   ├── services/            # Business logic
│   │   │   ├── assessment_service.py   # Exam generation + grading
│   │   │   ├── upload_service.py       # File upload + deduplication
│   │   │   ├── document_service.py     # Document CRUD
│   │   │   ├── llm_service.py          # Gemini API integration
│   │   │   ├── embedding_service.py    # Nomic embeddings
│   │   │   └── vector_db_service.py    # pgvector operations
│   │   └── utils/               # File parsers (PDF, PPTX)
│   ├── requirements.txt
│   └── Dockerfile
│
├── docker-compose.yml
├── .env                          # Environment variables (not committed)
└── package.json

🚀 Getting Started

Prerequisites

Node.js 18+ and npm
Python 3.10+
Docker (optional, for containerized backend)
A Supabase project with pgvector enabled
API keys for Google Gemini and Nomic AI

Environment Variables

Create a .env file in the project root with the following:

Variable	Description
`SUPABASE_URL`	Your Supabase project URL
`SUPABASE_ANON_KEY`	Supabase anonymous / publishable key
`SUPABASE_SERVICE_KEY`	Supabase service role key
`DATABASE_URL`	Direct PostgreSQL connection string (for pgvector)
`JWT_SECRET`	Supabase JWT secret
`GEMINI_API_KEY`	Google Gemini API key
`NOMIC_API_KEY`	Nomic AI embedding API key
`VITE_API_URL`	Backend URL (default: `http://localhost:8000`)
`PORT`	Backend port (default: `8000`)
`MAX_PDF_PAGES`	Max pages per upload (default: `2000`)
`MAX_DOCUMENT_TOKENS`	Max tokens per document (default: `1000000`)

Running the Frontend

npm install
npm run dev

The frontend will be available at http://localhost:5173.

Running the Backend

Option A: Docker (Recommended)

docker-compose up --build

Option B: Python (Direct)

cd backend
python -m venv .venv

# Activate the virtual environment
# Windows:
.venv\Scripts\Activate
# macOS/Linux:
source .venv/bin/activate

pip install -r requirements.txt
uvicorn app.main:app --host 0.0.0.0 --port 8000 --reload

The API will be available at http://localhost:8000. Interactive docs at http://localhost:8000/docs.

📡 API Reference

All endpoints are prefixed with /api/v1 and require a Bearer token (Supabase JWT).

Documents

Method	Endpoint	Description
`POST`	`/documents`	Upload a PDF or PPTX file
`GET`	`/documents`	List all documents in user's library
`GET`	`/documents/{id}/view`	Get a signed URL to view/download a document
`DELETE`	`/documents/{id}`	Soft-delete a document (move to trash)

Assessments

Method	Endpoint	Description
`POST`	`/assessments`	Create and generate a new assessment
`GET`	`/assessments`	List all assessments
`GET`	`/assessments/{id}`	Get assessment details with questions
`PUT`	`/assessments/{id}`	Update/edit an assessment
`DELETE`	`/assessments/{id}`	Soft-delete an assessment
`PATCH`	`/assessments/{id}/attempt`	Submit an exam attempt for grading

Trash

Method	Endpoint	Description
`GET`	`/trash`	List all trashed documents and assessments
`POST`	`/trash/documents/{id}/restore`	Restore a trashed document
`POST`	`/trash/assessments/{id}/restore`	Restore a trashed assessment
`DELETE`	`/trash/documents/{id}/permanent`	Permanently delete a document
`DELETE`	`/trash/assessments/{id}/permanent`	Permanently delete an assessment

Other

Method	Endpoint	Description
`GET`	`/recent-activity`	Get user's recent activity feed
`GET`	`/notifications`	Get user's notifications

🗄️ Database Schema

Table	Purpose
`documents`	File metadata — hash, name, path, size, page count, token count, processing status
`user_library`	Junction table linking users to documents (supports soft-delete via `deleted_at`)
`assessments`	Assessment metadata — title, topic, difficulty, status, document references, attempt data (JSONB)
`questions`	Individual questions — text, type (MCQ/TF/SA), explanation with page reference, source document
`question_options`	Answer options per question — option text and correctness flag
`vecs.document_chunks`	pgvector collection — 768-dim embeddings with metadata (document_id, text, page_number)

Key Design Decisions

SHA-256 Deduplication: Identical files uploaded by different users share a single set of vector embeddings, saving storage and compute
1:1 Ownership Model: Despite shared embeddings, the user_library junction table enforces strict per-user access control
MCQ Option Shuffling: Multiple choice options are randomly shuffled before storage to mitigate LLM answer-position bias
Soft-Delete Pattern: Both documents and assessments support 30-day soft-delete with restore capability

👥 Contributors

_{Chanuth Jayatissa}

_{In Young Song}

_{Lucas Lange}

_{Patrick Martus}

_{Randy Kamindo}

_{Saad A.}

Built as a capstone project for COSC 481 — Software Engineering at Eastern Michigan University (Winter 2026)
