PAH23: Making connections open, easier and scalable

Welcome to ProbinAlo Hackathon 2023 project repository. Good luck everyone!

Table of Contents

1. Introduction
2. Tools
3. Project Requirements
   1. User Profile

Solution Project: A Node Simulator

At a glance:

• A Web App
• Visualized Data
• User Control to Create
• Expandable Ideas

Suggested tools:

Demo image of a graph visualizer

Project Requirements

1. User account creation.

   Fields:

   • Username
   • Email
   • Password
   • Number of projects/models user has created

   Possible login methods:

   • Passwords
   • Two-Factor Authentication (not mandatory)

2. Must save user progress. Should contain undo, redo and etc. options.

3. Must have buttons that let user create nodes and edges with data.

4. Shows visual representation of nodes and edges with data. Easily visible data is priority in the representation.

5. Try creating most things as an API, so that it is reusable.

Representing Graphs

Let $nodes$ be an array containing the each nodes. Here, each node has a string value.

Let $edges$ be an array containing the edges between each nodes. This array contains arrays containing the index denoting an edge between node. $i$-th array in this $edges$ array represents the edge list of the node in the same index of $nodes$ array.

Example:

This graph can be represented like this:

nodes = [Node {a}, Node {b}, Node {c}, Node {d}, Node {e}]

edges = [[1, 2, 3, 4], [0, 4], [0, 3, 4], [0, 2], [0, 1, 2]]

Note that bidirectional edges can also be represented in this format.

Serializing the graph to binary format

Name	Description	Position	Type
n_size	Total size in bytes of $nodes$ array	0x0	u64
n_array	List of null terminated strings.	0x8	bytes
e_size	Total size in bytes of $edges$ array	$8 + n\_size$	u64
e_array	Array of edge list.	$16 + n\_size$	bytes

Representation of e_array

Name	Description	Position	Type
e_list_size	Size of the edges list	To be determined at runtime	u64
e_list	List containing indexes to nodes in $nodes$	To be determined at runtime	u64[]

Each item in e_array are put one after another. So that means, it'll look like this:

0x0 0x0 0x0 0x0 0x0 0x0 0x0 0xF  -
0x0 0x0 0x0 0x0 0x0 0x0 0x0 0xA   | -> First e_list
0x0 0x0 0x0 0x0 0x0 0x0 0x0 0xB  -
0x0 0x0 0x0 0x0 0x0 0x0 0x0 0x8  -
0x0 0x0 0x0 0x0 0x0 0x0 0x0 0xA  -| -> Second e_list

The bytes represent the following e_array:

[[10, 11], [10]]

Here, the position of the first e_list is $e\_array\_pos + 8$. The position of the second e_list is $e\_array\_pos + 8 + 16 + 8$.
