Raspberry Pi: Doorbell Ring to Telegram Message

This project allows you to connect a physical doorbell to a Raspberry Pi and send a notification to a Telegram chat when the doorbell is pressed. It's a simple and effective way to integrate your doorbell with a messaging platform for real-time notifications.

Requirements

• Raspberry Pi (with GPIO support)
• Python 3
• Internet connection
• Telegram account

Installation

1. Install Python on your Raspberry Pi:

   sudo apt-get update
   sudo apt-get install python3 python3-pip

2. Install required Python packages by creating a virtual environment (optional but recommended):

   python3 -m venv myenv
   source myenv/bin/activate  # activate the virtual environment
   pip install -r requirements.txt

   If you don’t want to use a virtual environment, simply run:

   pip3 install -r requirements.txt

Setup

1. Create a Telegram Bot:

   • Open Telegram and search for @BotFather.
   • Start a chat with @BotFather and use the /newbot command to create a new bot.
   • Follow the instructions and get your API Token.

2. Configure config.yml:

   • Copy the API Token you received from @BotFather into the config.yml file under the telegram.api_token field.
   • Send a message to the bot you just created to initialize the chat.
   • Retrieve your Chat ID:
     • Open a browser and visit the following URL (replace API_KEY_HERE with your bot's API key):

       https://api.telegram.org/botAPI_KEY_HERE/getUpdates


     • Look for your message and copy the chat.id value.
   • Add this Chat ID to your config.yml file under telegram.chat_id.

3. Connect your Doorbell to the Raspberry Pi:

   • Connect a button or sensor (doorbell) to one of the Raspberry Pi's GPIO pins (e.g., GPIO pin 17).
   • Ensure proper wiring (one side to a GPIO pin, the other side to GND).

4. Edit Configurable Messages:

   • You can modify the messages that are sent when the system starts, when the doorbell is pressed, or when the system is stopped. These are located in the config.yml file under messages:

      telegram_messages:
        system_start: "The doorbell notification system is online."
        doorbell_ring: "Someone is at the door!"
        system_shutdown: "The doorbell notification system is being turned off."
        gpio_cleanup: "The system has been shut down and cleaned up."

Running the Script

1. Start the Python script to listen for the doorbell:

   python3 your_script.py

2. The system will now monitor the GPIO pin for a doorbell press and send a Telegram notification to the configured chat.

Example Config (config.yml)

settings:
  enable_cmd_prints: false  # Toggle to enable/disable console prints
  log_telegram_send: false  # Toggle to enable/disable logging Telegram message send status
  gpio_pin: 17  # Define the GPIO pin number here

telegram:
  api_token: 'YOUR_BOT_API_KEY'
  chat_id: 'YOUR_CHAT_ID'

print_messages:
  system_start: "System started and waiting for the doorbell signal."
  doorbell_ring: "Doorbell was pressed!"
  system_shutdown: "System is shutting down..."
  gpio_cleanup: "GPIO cleanup done and system is stopped."

telegram_messages:
  system_start: "ℹ️ Important Information\n\nThe doorbell system has started!"
  doorbell_ring: "💥 Important Information 💥\n\nThe doorbell has rung!"
  system_shutdown: "ℹ️ Important Information\n\nThe system is shutting down!"
  gpio_cleanup: "ℹ️ Important Information\n\nThe system has been powered off."

TO DO:

• W.I.P Branch there is the TO DO list

Future Updates:

• TBC

License

This project is licensed under the GNU General Public License v3.0 - see the LICENSE file for details.
