APPM

Asymptotic-Preserving Plasma Modelling (APPM) is a project for simulating plasma under both non-neutral and quasi-neutral regimes. Spcecifically, the (rescaled) Euler-Maxwell system parametrized by scaled Deybe length is solved for both regimes in a unified code.

For details, check Master_thesis_TianweiYu.pdf

A quick visulization of the result (E-field lambda = 0.5)

Dependence

• Eigen 3.3.7
• hdf5 1.10.9

Compilation

• On Windows (with MinGW)

    mkdir build
    cd build
    cmake .. -G "MinGW Makefiles"
    cmake --build .


• On Linux (with gcc)

    mkdir build
    cd build
    cmake ..
    make


Usage

The simulation parameters are inputed through AppmSolverParams.txt where you can set the following:

• maxIterations: max iteration times
• maxTime: end time of simulation
• lambda: rescaled Debye length
• itersPerWrite: iteration interval to store snapshots

The mesh parameters are inputed through primalMeshParams.txt where you can set the following:

• axialLayers: cell number along z-axis (axial axis)
• refinements: refinement level of the cross section of the plasma region (mesh size is halved per +1)
• outerLayers: refinement level of the outer non-conducting region (mesh size is haved per +1)
• zMax: length of the cylindrical region (=5 by default)
• electrodeRadius: radius of the contact boundary, e.g. radius of the plasma region (=1 be default)

These two files locate at the source directory.

To run the code,

• on windows, use command:

    appm


• on Linux, use command:

    ./appm


Data Visualization

The solutions are stored in solutions_<meshType>_<entityType>.xdmf which rely on snapshot-<iteration>.h5 generated during the simulation.

For instance, solutions_dual_cell.xdmf represents the quantities associated on dual cells, i.e. fluid quantities (density, momentum, energy) and reconstructed E-field and B-field.

To visualize the solutions, use Paraview (5.10.0):

1. open solutions_dual_cell.xdmf
2. select Xdmf3ReaderT
3. apply and add filter Cell Data to Point Data
4. apply and add filer Glyph
5. select the variable to visualize
6. adjust visualization parameters and apply
