Umineko City of Books

_{Artwork by Meru}

A community platform for fans of Umineko no Naku Koro ni, Higurashi, Ciconia, and the wider When They Cry series. The original goal was a place to declare fan theories as blue truth, attach quotes from the game as evidence, and have them debated on two sides: "With love, it can be seen" and "Without love, it cannot be seen". It has since grown into a full social platform: theory debates across all three series, a Twitter-style game board, mystery boards, fan art galleries, ship and OC declarations, fanfiction, live reading journals, chat rooms with shared-browser watch parties, DMs, secret unlock hunts, multiplayer games (chess, checkers, othello, minesweeper, snakes & ladders, and real-time pong) with vanity titles for the top players, site-wide search, live notifications, and themed role-based moderation.

• Features
• Tech Stack
• Architecture
• Getting Started
• Database and Migrations
• Development Workflow
• Deployment
• Adding a New Page
• Documentation
• Provenance
• License

• Theory Debates: the original heart of the site: submit a fan theory as a blue truth, attach quote evidence, and let others refute or support it.
• Mysteries: a gamified puzzle mode where a Game Master poses a mystery with graduated clues and other players submit attempts.
• Gallery and Art: fan art uploads with full social features, bundled into galleries and blurred behind a spoiler cover where a piece needs one.
• Ships: declare character pairings, mixed-series or featuring your own OCs, and rally votes for them.
• Original Characters: a dedicated home for player-created OCs, separate from the canon-character ship list.
• Game Board: a Twitter-style social feed for off-topic posts and discussion, with its own corner for each series.
• Fanfiction: write and publish multi-chapter fan stories, with FFN-style metadata and a remembered reading position.
• Reading Journals: live-blog your read-throughs of Ryukishi07's works, posting reactions, theories, and predictions as you go.
• Chat Rooms and DMs: real-time chat in two flavours: one-to-one direct messages and named group rooms.
• Chatbots: character accounts that answer in their own voice, backed by an OpenAI model, summoned by a mention, a reply, or a DM.
• Watch Parties: shared-viewing sessions launched from inside a group chat room: a remote browser everyone takes turns driving, or your own screen broadcast to the room.
• Voice Chat: real-time voice in group rooms, DMs, and watch parties, backed by a self-hosted LiveKit SFU rather than a peer-to-peer mesh.
• Live Streaming: a public broadcast directory at /live: any member can go live from OBS or Streamlabs over WHIP, and anyone, logged in or not, can watch.
• Games: multiplayer mini-games hosted entirely inside the site, from correspondence chess to a real-time pong duel, each with live games, past games, and spectators.
• Secrets and Unlock Hunts: hidden puzzles scattered across the UI, collected piece by piece and surfaced on a public hub at /secrets, where the first solve closes the hunt for everyone.
• Announcements: site-wide announcements with pinning, full markdown, and the same threaded comment system as everywhere else.
• Suggestions: a dedicated feedback channel for site improvements and bug reports, tracked as Open, Done, or Archived.
• Search: a single search bar covers the whole site, backed by Postgres tsvector columns on every searchable entity.
• Quote Browser: a standalone interface for browsing the full quote corpus across all three series, sourced from the Umineko Quote Finder API.
• Profiles and Social Graph: avatar, banner, bio, pronouns and favourite character, plus per-user theme and font, an activity feed, follows, blocks, and reading progress recorded per series.
• Notifications: every notification is both a database row for the notifications page and a live event for the bell, fanning out to the socket, the stream overlay, mobile push, and email.
• Stream Overlay: site events can drive on-stream alert popups through SAMMI, from a personal connector file you download and import.
• Moderation and Admin: themed roles (Reality Author, Voyager Witch, Witch) over a permission-based authorisation layer, with vanity roles, reports, an audit log, and hot-reloading site settings.
• Platform Features: fourteen themes grouped by series, two font families, Discord-style formatting wherever text is typed, OG embeds, an auto-generated sitemap, background media processing, and a Capacitor mobile app.

Every one of those is written out in full, with its rules, limits and edge cases, in docs/FEATURES.md.

Backend. Go 1.27, Fiber v3, PostgreSQL via jackc/pgx/v5 behind the pgx/v5/stdlib adapter, goose for migrations, testcontainers-go for DAO tests against a real Postgres, gofiber/contrib/v3/websocket for the hub, zerolog, wneessen/go-mail, disintegration/imaging, bluemonday, openai/openai-go v3, valkey-io/valkey-go, prometheus/client_golang, the OpenTelemetry Go SDK with XSAM/otelsql, grafana/pyroscope-go, hellofresh/health-go, firebase.google.com/go, livekit/server-sdk-go, corentings/chess, and mockery plus staticcheck pinned in the go.mod tool block.

Frontend. React 19, TypeScript 6, Vite 8, React Router v8 (the react-router package, never react-router-dom), TanStack Query v5, CSS Modules, DOMPurify with marked and highlight.js, TipTap 3, livekit-client with @livekit/components-react, hls.js, @hyperbeam/web, chess.js with react-chessboard, emoji-picker-react, @marsidev/react-turnstile, firebase, Capacitor 8 with @capgo/capacitor-updater, and Vitest 4 with Testing Library, ESLint 10 and Prettier.

Infrastructure. A Docker multi-stage build (Node build stage, Go build stage, Alpine runtime carrying FFmpeg and libwebp-tools), two Valkey instances (one coordinating LiveKit ingress and egress, one LRU-capped app cache), Caddy or another reverse proxy in front, session auth on httpOnly cookies with no JWTs, mockery v3 from .mockery.yml for every Go interface mock, and a docker-compose.prod.yml carrying prometheus-* scrape labels beside a postgres-exporter sidecar.

External. The Umineko Quote Finder API for quote search and evidence, the GIPHY API, Hyperbeam for virtual-browser watch parties, self-hosted LiveKit for voice, screen share and streaming, OpenAI for the chatbot character accounts, and Firebase Cloud Messaging for native push. Optionally and entirely externally: a Prometheus scraper, an OTLP trace collector, a Pyroscope server, and Loki with a Grafana Alloy collector. None of those four is bundled in the compose files.

Why each of those was chosen, checked against go.mod and frontend/package.json, is in ARCHITECTURE.md.

The server is a single Go binary that embeds the compiled Vite bundle and serves both the SPA and the JSON API from one process. Every layer has a single responsibility: controllers parse HTTP, services orchestrate business logic, repositories own SQL, the hub owns live events, and the media processor owns encoding off the hot path.

   ┌────────────────────┐        ┌────────────────────┐
   │  Browser (React)   │        │  Capacitor app     │
   └──────────┬─────────┘        └─────────┬──────────┘
              └─────────────┬──────────────┘
                            ▼  HTTP / WS
   ┌──────────────────────────────────────────────────┐   ┌──────────────────┐
   │                   Fiber v3 app                   │──▶│  WebSocket hub   │
   └─────┬────────────────────────────────────────────┘   └──────────────────┘
         ▼
   Controllers ─▶ Services ─▶ Repositories ─▶ DAOs ─▶ PostgreSQL
                     │
                     ▼
            ┌──────────────────┐
            │ Media processor  │
            └──────────────────┘

Voice, watch parties, and live streaming run on a separate media plane: audio and video travel from the browser to the LiveKit SFU (or to the Hyperbeam VM) directly, and the Go process only mints signed tokens and tracks presence, so none of that traffic passes through the layers above.

ARCHITECTURE.md has the rest: the full component map, the request lifecycle, the rule each layer boundary enforces, and a chapter per subsystem (data layer, cache, auth, permissions, content filter, WebSocket hub, notifications, media pipeline, background jobs, OG and SEO, observability).

• Go 1.27 or newer
• Node.js LTS
• Docker (for the Postgres and Valkey containers, plus repo-layer tests via testcontainers-go)
• FFmpeg, both ffmpeg and ffprobe, for video transcoding and thumbnails
• libwebp-tools for WebP work: cwebp for conversion, dwebp and webpmux for the OG JPEG path
• The goose CLI, if you need to author a migration (see Database and Migrations)
• psql CLI (optional, handy for poking at the DB)

Two env files live next to each other:

• postgres.env, the Postgres bootstrap credentials. Read by the postgres container at init and by the app at connect time. Copy from postgres.env.example:

  cp postgres.env.example postgres.env

  Variable	Description
  POSTGRES_USER	DB role for the app (umineko by convention)
  POSTGRES_PASSWORD	DB password
  POSTGRES_DB	Database name (umineko_city_of_books by convention)

• .env, everything else the app reads. Copy from .env.example:

  cp .env.example .env

Only a short list of variables is read from the environment for its own sake. Everything else in .env is a first-boot seed for a row in site_settings.

Read from the environment

First-boot seeds for site settings

At startup the app uppercases every site-setting key and, when an env var of that name exists, uses its value as that setting's default. Missing settings are then written into the database with those defaults the first time the app boots. From then on the stored row wins and the env var is ignored, so these variables only bite on a fresh database and editing one later changes nothing.

Any site-setting key works this way, not just the rows above, but these are the ones worth setting before the first boot.

Hyperbeam moved. HYPERBEAM_API_KEY and HYPERBEAM_REGION are now the hyperbeam_api_key and hyperbeam_region site settings, edited under Admin → Settings → Watch Parties, Voice & Streaming, and the env vars survive only as first-boot seeds.

LOG_FORMAT is the one observability knob that is a plain env var rather than a site setting. Set LOG_FORMAT=json and the logger writes structured JSON to stdout for a collector to parse; leave it unset and you get the human-readable ConsoleWriter output. docker-compose.prod.yml sets it, the dev compose does not. It is deliberately not hot-reloadable, because changing the stdout format underneath a running collector would break its parse stages mid-stream.

.env.example ships a deliberate subset: GIPHY_API_KEY, POSTGRES_PORT, and VALKEY_URL are all read by the app but are not in the template, so add them by hand when you need them.

Everything else (registration mode, maintenance mode, turnstile keys, upload limits, rate limits, log level, email provider and SMTP settings, LiveKit and streaming credentials, chatbot configuration, default theme) is stored in the database via the site_settings table and editable from the admin panel at runtime with hot reload. The env file is only for things that must exist before the DB is reachable, and for the handful of secrets that never round-trip through the DB.

The Go binary embeds the built frontend (//go:embed static/* in server.go) and reads static/index.html at startup, and static/ is gitignored. On a fresh clone nothing Go-side will even compile until that directory exists, so build the frontend once first:

cd frontend
npm ci
npm run build     # writes ../static/

If you only care about compiling and testing the backend, a placeholder is enough: mkdir -p static && touch static/.gitkeep, which is exactly what CI does.

The app also needs Postgres reachable before it'll boot. Two paths:

Option A: Run only Postgres in Docker, the app on the host

# start just the postgres service from compose
docker compose up -d postgres

# backend (from repo root), connects to Postgres on host port 5007
POSTGRES_HOST=localhost POSTGRES_PORT=5007 go run .

# frontend (separate terminal)
cd frontend
npm run dev

Work against http://localhost:5173, the Vite dev server. It proxies /api, /api/v1/ws, /uploads, and /sitemap through to the Go server on :4323. Hitting :4323 directly serves the last npm run build output from static/, not your live edits.

Option B: Run the full stack in Docker

A bare docker compose up -d --build starts every service in the file, including livekit, livekit-ingress, and livekit-egress, which bind-mount the gitignored livekit.yaml, ingress.yaml, and egress.yaml. Unless you have already done the Voice Chat and Live Streaming setup, Docker creates empty directories in their place and those three containers crash-loop. Name the app service instead, and compose brings up the two it depends on (postgres and valkey-cache) with it:

docker compose up -d --build umineko-city-of-books

Visit http://localhost:2312. The container picks up POSTGRES_HOST=postgres from .env, which compose loads via env_file, which is why .env.example ships postgres rather than localhost as the host.

The backend serves on :4323 (mapped to :2312 from the host under docker-compose).

The first user to register is automatically assigned the super admin role, so start there to unlock the admin panel.

All migrations live in internal/db/migrations/ and are embedded into the binary via go:embed. They run automatically on startup via goose against the configured Postgres database (db.Migrate in internal/db/db.go).

The schema started as a single consolidated initial migration squashed during the SQLite-to-Postgres cutover. Everything since is a fresh migration stacked on top of it, around fifty of them now.

Always create migrations with the goose CLI, never by hand, so the timestamp format stays consistent:

goose -dir internal/db/migrations create <name> sql

goose is a library dependency here, not a tool directive in go.mod (only mockery and staticcheck are), so install the CLI separately if you do not already have it:

go install github.com/pressly/goose/v3/cmd/goose@latest

Then edit the generated file to fill in the -- +goose Up and -- +goose Down sections. On next go run . the migration applies automatically.

The Down half is not optional. internal/dao/migration_roundtrip_test.go migrates a throwaway database all the way up, rolls it back to 20260726205627 with db.MigrateDownTo, then migrates up again. A missing or broken -- +goose Down in any migration newer than that fails the test suite, so write the rollback at the same time as the forward change rather than leaving it empty.

To inspect the database directly (host-side, via the mapped port):

psql -h localhost -p 5007 -U umineko -d umineko_city_of_books
\dt
\d theories

Or from inside the running postgres container:

docker compose exec postgres psql -U umineko -d umineko_city_of_books

go build ./...            # compile
go vet ./...              # static analysis
go tool staticcheck ./... # linter, pinned by the tool directive in go.mod
go test ./...             # run tests
./scripts/test.sh         # regenerate mocks, then vet, staticcheck, test
./scripts/regen_mocks.sh  # regenerate mockery mocks only

All of those need static/ to exist first, because the root package embeds it. See Running Locally. The repository and DAO tests boot a real Postgres through testcontainers-go, so Docker has to be running for go test ./... to pass.

Interfaces listed in .mockery.yml get a mock generated next to the interface and named after it, so Service becomes service_mock.go. internal/repository is configured with all: true, so every interface in that package is mocked without being listed individually. Regenerate whenever you add or change an interface signature.

CI (.github/workflows/ci.yml) creates a static/.gitkeep placeholder, then runs go vet ./..., go tool staticcheck ./..., go test ./... -count=1, and go build ./... in that order. Putting [skip tests] in the commit message skips the test step only.

cd frontend
npm run dev         # dev server with HMR on :5173
npm run build       # tsc + vite build into ../static/
npm run typecheck   # tsc -b only, no bundle
npm test            # vitest run
npm run test:watch  # vitest in watch mode
npm run test:coverage
npm run lint        # eslint, --max-warnings=0
npm run lint:fix    # eslint with autofix
npm run prettier    # prettier check
npm run prettier:fix

Tests are vitest and React Testing Library under jsdom, colocated with the code (Foo.tsx next to Foo.test.tsx), with the shared render helpers, fixtures and jsdom setup in frontend/src/test-utils/. tsconfig.json includes the test files, so npm run typecheck (and therefore npm run build) typechecks them too.

CI runs npm run prettier, npm run lint, npm test, then npm run build. Run the same four before committing frontend changes; all of them need to pass cleanly.

The same React frontend is packaged as a native iOS/Android app via Capacitor, with the project living in frontend/. The build commands, local iteration against a live dev server, OTA bundle signing, the app's baked-in API base URL, and native push are all in docs/MOBILE.md.

docker compose up -d --build

This builds the multi-stage image locally (frontend -> static assets -> Go binary -> Alpine runtime with FFmpeg and libwebp-tools) and runs it on port 2312 by default, forwarding to the container's :4323.

docker-compose.yml defines seven services, not just the app and its database: postgres, umineko-city-of-books, valkey-cache (the app cache), valkey (the LiveKit coordination bus), livekit, livekit-ingress, and livekit-egress. The three LiveKit services bind-mount livekit.yaml, ingress.yaml and egress.yaml, all of which are gitignored, so on a fresh clone they restart-loop until you copy the templates (see docs/DEPLOYMENT.md). The same applies to the ./fcm-service-account.json mount: create the file, or drop the mount, unless you are using native push, otherwise Docker creates a directory in its place.

If you do not want voice, streaming or HLS, bring up the core only and let compose pull in its own dependencies:

docker compose up -d --build umineko-city-of-books

That starts postgres and valkey-cache (both declared under depends_on) and nothing else.

Two stores hold real site data and need to survive container rebuilds:

• Postgres data, the named docker volume postgres_data mounted at /var/lib/postgresql inside the postgres container. Survives docker compose up -d and image upgrades.
• Uploaded media, the umineko-city-of-books service bind-mounts ./data:/app/data so data/uploads/ lives on the host. Set UPLOAD_DIR=data/uploads in your .env so the app reads from this mount. Note that UPLOAD_DIR only seeds the initial default of the upload_dir site setting; once it has been saved from the admin panel, the stored value wins.

The container runs as a non-root user (uid 10001, cap_drop: ALL, no-new-privileges), so the host ./data directory has to be writable by that uid. Live HLS segments land under the same mount at data/hls/, and the app does the cleanup itself, removing each per-stream directory when the broadcast ends and sweeping orphans on the reconcile pass, so it needs write access there and not only read.

./fcm-service-account.json is bind-mounted read-only into the container by both compose files and is gitignored. Create it (or remove the mount) before the first up, otherwise Docker creates a directory in its place.

docker-compose.prod.yml adds a third named volume, valkey_data, for the host-networked LiveKit coordination valkey it runs with --appendonly yes. That holds ephemeral SFU coordination state rather than site data, so it does not need backing up.

For backups: a daily pg_dump | gzip cron is the recommended path for the database, plus a periodic tarball of ./data/uploads/ for media. Restore via gunzip -c <dump>.sql.gz | docker compose exec -T postgres psql -U umineko -d umineko_city_of_books.

Running the published ghcr.io image, the Caddy reverse-proxy configuration, and the three LiveKit deployments (voice SFU, streaming ingress, HLS egress) are all in docs/DEPLOYMENT.md. They are one document rather than four because anyone enabling voice is also configuring the proxy and opening the firewall.

A new page or section has to be wired into ten places: OG tags, the admin content rules, the sidebar, the profile home-page dropdown, the lazy page exports, the frontend routes, the backend routes, the sitemap, the content filter, and search. Missing any one of them fails quietly rather than loudly, so the full checklist lives on one screen in docs/ADDING_A_PAGE.md.

• ARCHITECTURE.md: how the code is arranged and why. The backend layering, the request lifecycle, a chapter per subsystem, and the reasoning behind the stack above.
• PROVENANCE.md: authorship, the project timeline, and third-party code.
• docs/FEATURES.md: the full catalogue behind the twenty-four entries above, with the rules and limits of each.
• docs/DEPLOYMENT.md: the prebuilt image, reverse proxy, and LiveKit voice, ingress and HLS egress setup.
• docs/MOBILE.md: the Capacitor app. Builds, local iteration, OTA bundles, API base URL, native push.
• docs/ADDING_A_PAGE.md: the ten places a new page has to be registered.
• design/updates.md: the public changelog, alongside the other working trackers. design/ holds documents with a lifecycle, meant to be worked through and eventually closed, and is excluded by .gitignore, which is why this entry is a path rather than a link. docs/ is the other half and holds durable reference that stays true until the code changes.

The source in this repository is written by hand. Authorship, the project timeline, commit-message tooling, and third-party code are set out in PROVENANCE.md.

Released under the MIT License. Umineko no Naku Koro ni and the wider When They Cry series are © 07th Expansion; this project is an unofficial fan platform with no affiliation.
