QPot Wallpaper

QPot

Advanced Honeypot Platform
Developed by Yuril Security Team

Release Go Version Docker License

Overview

QPot is an enterprise-grade honeypot platform developed by YurilLAB. Built on the solid foundation of T-Pot CE, QPot adds modern security features, enhanced sandboxing, and seamless integration with the Yuril Security ecosystem.

Part of the Yuril Security Suite
QPot works alongside YurilAntivirus and YurilTracking to provide comprehensive threat detection and response capabilities.

Why QPot?

Comparison with T-Pot

Feature T-Pot QPot
Attack Map Yes Yes - Enhanced with QPot ID
Kibana Dashboard Yes Yes - With ClickHouse support
20+ Honeypots Yes Yes - Same proven images
Per-Honeypot Resources No Yes - CPU/Mem/PID limits
gVisor/Kata Sandboxing No Yes - Container isolation
ClickHouse Database No Yes - High-performance analytics
QPot ID Tracking No Yes - Instance identification
Stealth Mode No Yes - Anti-fingerprinting
Yuril Integration No Yes - Native ecosystem support
Database Migrations No Yes - Versioned schema management
Data Retention Policies No Yes - Automated S3 archival
Read Replicas No Yes - High availability
Cluster Management No Yes - Multi-instance with password auth
Threat Intel (ATT&CK) No Yes - Auto MITRE ATT&CK classification
IOC Tracking No Yes - Automated IOC extraction & dedup
TTP Session Analysis No Yes - Behavioral campaign fingerprinting
Alert Webhooks No Yes - Slack/Discord/generic thresholds
IOC Export No Yes - Attacker blocklist API
GeoIP Enrichment No Yes - MaxMind via Vector pipeline

Key Advantages

Defense in Depth
Every honeypot runs in its own sandbox with gVisor, Kata, or Firecracker isolation. Resource limits prevent container escape and resource exhaustion attacks.

Modern Data Architecture
Optional ClickHouse backend provides columnar storage for fast analytics, while the ClickHouse-Kibana connector maintains compatibility with existing Kibana dashboards.

Unique Instance Tracking
Every QPot deployment receives a unique QPot ID (qp_*) for multi-instance management, threat correlation, and integration with YurilTracking.

Stealth Operations
Built-in anti-fingerprinting features including fake hostnames, randomized response delays, and MAC address randomization make honeypots harder to detect.

Architecture

+-------------------------------------------------------------+
|                        QPot Platform                        |
|                                                             |
|  +------------------------------------------------------+   |
|  |            Nginx Reverse Proxy (64297)               |   |
|  |  +----------+----------+----------+-------------+    |   |
|  |  | Landing  |  Attack  |  Kibana  |  QPot API   |    |   |
|  |  |  Page    |   Map    | Analytics|   Server    |    |   |
|  |  +----------+----------+----------+-------------+    |   |
|  +------------------------------------------------------+   |
|                            |                                |
|  +-------------------------+-----------------------------+  |
|  |                         |                             |  |
|  v                         v                             v  |
|  ClickHouse           Honeypots                     Web UI  |
|  (Analytics)        (Docker Containers)            (React)  |
|                                                             |
|  +------------------------------------------------------+   |
|  |                   Security Features                  |   |
|  |  - gVisor/Kata sandboxing  - Read-only filesystems   |   |
|  |  - Resource limits         - Custom seccomp profiles |   |
|  |  - Network isolation       - MAC randomization       |   |
|  |  - Stealth/deception       - No privileged containers|   |
|  +------------------------------------------------------+   |
+-------------------------------------------------------------+

Quick Start

Installation

# Clone the repository
git clone https://github.com/YurilLAB/QPot.git
cd QPot

# Build the QPot CLI
go build -o qpot ./cmd/qpot

# Or use Make
make build

Create and Start Instance

# Create a new instance (generates unique QPot ID)
./qpot instance create production
# Output: [OK] Created QPot instance 'production'
#         QPot ID: qp_e2imzc43lisklwokb7vlspi7

# Start the instance
./qpot up --instance production

Access Dashboard

Service URL Description
Landing Page https://localhost:64297 QPot branded entry point
Attack Map https://localhost:64297/map Real-time attack visualization
Kibana https://localhost:64297/kibana Log analytics
QPot API https://localhost:64297/api Management API

QPot ID System

Every QPot instance receives a unique identifier for tracking and integration:

# View QPot ID
./qpot id --instance production
# QPot ID: qp_e2imzc43lisklwokb7vlspi7

# The QPot ID is displayed in:
# - GUI popup on startup
# - Web UI header (click to copy)
# - Attack map interface
# - API responses

Integration with YurilTracking

QPot instances can feed threat data directly into YurilTracking for centralized analysis:

# qpot.yml
integrations:
  yuril_tracking:
    enabled: true
    endpoint: https://tracking.yuril.local/api/v1/events
    api_key: ${YURIL_API_KEY}
    qpot_id: ${QPOT_ID}

Configuration

Per-Honeypot Resource Limits

honeypots:
  cowrie:
    enabled: true
    resources:
      use_custom_limits: true
      max_cpu_percent: 30
      max_memory_mb: 256
      max_pids: 50
      max_file_descriptors: 1024

Database Backend Options

ClickHouse (Recommended)

database:
  type: clickhouse
  host: localhost
  port: 9000
  database: qpot

TimescaleDB

database:
  type: timescaledb
  host: localhost
  port: 5432

Elasticsearch (Legacy)

database:
  type: elasticsearch
  host: localhost
  port: 9200

Stealth Mode

stealth:
  enabled: true
  fake_hostname: webserver-prod-01
  fake_os: "Ubuntu 22.04.3 LTS"
  fake_kernel: "5.15.0-91-generic"
  randomize_response_time: true
  add_artificial_delay: true
  delay_range_ms: 50-200
  block_scanner_probes: true

Database Migrations

QPot supports versioned schema migrations for ClickHouse and TimescaleDB:

database:
  type: clickhouse
  auto_migrate: true  # Automatically apply migrations on startup
  target_version: 0   # 0 = latest, or specify specific version

View migration status:

./qpot db migrate status
./qpot db migrate up      # Apply pending migrations
./qpot db migrate down    # Rollback one migration

Data Retention Policies

Automated data lifecycle management with hot/warm/cold tiers:

database:
  retention_policies:
    - id: default
      name: "90-Day Retention"
      enabled: true
      hot_retention: 2160h      # Keep in hot storage for 90 days
      warm_retention: 4320h     # Move to warm storage for 180 days
      cold_retention: 8760h     # Archive for 365 days
      archive_type: s3          # s3, gcs, or filesystem
      archive_config:
        endpoint: s3.amazonaws.com
        region: us-east-1
        bucket: qpot-archives
        prefix: honeypot-data/
        access_key_id: ${AWS_ACCESS_KEY_ID}
        secret_access_key: ${AWS_SECRET_ACCESS_KEY}
      compression: gzip
      schedule: "0 2 * * *"     # Run daily at 2 AM

Connection Pooling & Read Replicas

Advanced database connection management:

database:
  pool:
    max_open_conns: 25
    max_idle_conns: 10
    conn_max_lifetime: 1h
    conn_max_idle_time: 30m
    health_check_interval: 5m
    acquire_timeout: 30s

  read_replicas:
    - name: replica-1
      host: 10.0.0.5
      port: 9000
      priority: 1
      weight: 50
      region: us-east-1
    - name: replica-2
      host: 10.0.0.6
      port: 9000
      priority: 2
      weight: 50
      region: us-west-2

Threat Intelligence

QPot includes a built-in threat intelligence engine that automatically classifies attacks against the MITRE ATT&CK framework, extracts IOCs, and builds behavioral TTP sessions.

MITRE ATT&CK Auto-Classification

Every honeypot event is automatically mapped to an ATT&CK technique the moment it arrives. QPot fetches the latest ATT&CK Enterprise knowledge base from MITRE on startup, caches it locally, and falls back to an embedded technique set if offline.

Dynamic Rule Generation - QPot analyzes the full ATT&CK dataset to automatically generate classification rules based on:

  • Detection strategies from MITRE's x_mitre_detection field
  • Data sources and platforms
  • Keyword extraction from technique names and descriptions
  • Cross-platform applicability filtering (non-Windows techniques prioritized)

Rules are merged intelligently via a deduplication system: static built-in rules take precedence by technique ID, and dynamic rules automatically fill gaps for techniques not explicitly covered. This means new ATT&CK techniques are handled without any code changes as long as QPot can reach MITRE's dataset.

Confidence Scoring - Every classification includes a confidence score (0.0–1.0) based on rule specificity and data richness:

  • 1.0 — Static built-in rules with hand-curated patterns
  • 0.6 — Dynamically generated rules derived from ATT&CK data
  • Rules are evaluated by priority; first match wins
SSH brute force     → T1110.001 - Password Guessing      (Credential Access)
Password spraying   → T1110.003 - Password Spraying      (Credential Access)
wget/curl in shell  → T1105    - Ingress Tool Transfer   (Command & Control)
uname / id / whoami → T1082    - System Info Discovery   (Discovery)
crontab / systemctl → T1053    - Scheduled Task/Job      (Persistence)
sudo / chmod 777    → T1548    - Abuse Elevation Control (Priv. Escalation)
Conpot Modbus probe → T0840    - Network Scanning        (ICS Discovery)

Classification runs in real-time on incoming events. A background worker runs every 15 minutes to backfill any events that were stored before classification was active.

IOC Extraction

QPot automatically extracts and deduplicates indicators of compromise from every event:

  • IP addresses — public source IPs (RFC1918/loopback filtered)
  • Credential pairs — username:password combinations attempted
  • URLs — download URLs from wget/curl commands
  • File hashes — MD5, SHA1, SHA256 from captured payloads
  • Commands — shell commands executed in honeypot sessions
  • User agents — HTTP client fingerprints
  • Domains — extracted from URLs in commands

TTP Session Tracking

QPot builds attack campaign sessions using behavioral fingerprinting, not naive IP+time-window grouping. Sessions are defined by:

  • Credential set similarity — same username lists across different IPs = same campaign
  • Tool signatures — identical download domains, user agents, payload hashes
  • Command pattern overlap — same shell command sequences
  • Port/service targeting — same sequence of services probed

Sessions stay open until 30 minutes of inactivity. Shared infrastructure (AWS, GCP, Azure, Tor) is flagged but never assumed to represent a single attacker.

Intelligence API

Endpoint Description
GET /api/techniques ATT&CK techniques observed, with event counts
GET /api/iocs Extracted IOCs, filterable by type and honeypot
GET /api/ttps Active and completed TTP campaign sessions
GET /api/intelligence Intelligence summary (techniques, IOC counts, active sessions)
GET /api/ioc Unique attacker IP list for firewall blocklist generation

Intelligence Configuration

intelligence:
  enabled: true
  fetch_attck: true              # Fetch latest from MITRE GitHub on startup
  attck_data_path: "./data"      # Local cache path for ATT&CK data
  worker_interval: 15m           # Backfill worker interval
  worker_batch_size: 500         # Events per backfill run
  inactivity_window: 30m         # TTP session inactivity before closing

Alert Webhooks

QPot can fire webhook alerts to Slack, Discord, or any HTTP endpoint when attack volume crosses a threshold.

alerts:
  enabled: true
  webhook_url: https://hooks.slack.com/services/...
  threshold: 100       # Events per minute to trigger alert
  honeypots:           # Leave empty to alert on all
    - cowrie
    - dionaea

Security Features

Feature Implementation
Sandboxing gVisor, Kata, Firecracker
Resource Limits CPU, Memory, PIDs, FDs
Filesystem Read-only root, tmpfs overlays
Capabilities Drop ALL, minimal add
Seccomp Custom profiles per honeypot
Network Isolated per-honeypot networks
MAC Address Randomized per container
Hostname Unique per instance

CLI Reference

# Instance management
qpot instance create <name>      # Create new instance with QPot ID
qpot instance list               # List all instances
qpot instance remove <name>      # Remove instance

# Lifecycle
qpot up [--instance <name>]      # Start instance
qpot down [--instance <name>]    # Stop instance
qpot status [--instance <name>]  # Show status

# Honeypot management
qpot honeypot list               # List available honeypots
qpot honeypot enable <name>      # Enable honeypot
qpot honeypot disable <name>     # Disable honeypot

# Docker container management
qpot docker ps                   # List all QPot Docker containers with status
qpot docker logs <container>     # Tail logs for a container (default: 50 lines)
qpot docker restart <container>  # Restart a specific QPot container

# Utilities
qpot logs [honeypot]             # View logs
qpot id [--instance <name>]      # Show QPot ID
qpot config [--instance <name>]  # Edit configuration

Cluster Management

QPot supports multi-instance clustering with password authentication for distributed honeypot deployments.

Initialize a Cluster

Create a new cluster on your central server:

./qpot cluster init --name production --password "SecurePass123!"

# Output:
# [OK] Cluster initialized successfully
#      Cluster ID:   qc_a1b2c3d4e5f6...
#      Cluster Name: production
#      Node ID:      qn_1234567890ab...
#      Bind Address: 0.0.0.0:7946
#
# [IMPORTANT] Save your Cluster ID and Password!
#             Other nodes will need both to join.

Join a Cluster

Add sensor nodes to the cluster:

./qpot cluster join \
  --id qc_a1b2c3d4e5f6... \
  --password "SecurePass123!" \
  --seed 192.168.1.10:7946 \
  --node-name sensor-01 \
  --node-addr 192.168.1.20

# Multiple seeds for redundancy:
./qpot cluster join \
  --id qc_a1b2c3d4e5f6... \
  --password "SecurePass123!" \
  --seed 192.168.1.10:7946 \
  --seed 192.168.1.11:7946 \
  --node-name sensor-02

Cluster Operations

# View cluster status
./qpot cluster status

# Output:
# Cluster ID:    qc_a1b2c3d4e5f6...
# Cluster Name:  production
# Status:        running
#
# Nodes:
#   Total:       5
#   Healthy:     5
#   Suspect:     0
#   Failed:      0
#
# Events:        1,234,567 total

# List all nodes
./qpot cluster nodes

# Output:
# NODE ID      NAME            ADDRESS          STATUS     EVENTS
# -----------  --------------  ---------------  ---------  --------
# qn_123456..  leader          192.168.1.10:79  healthy    567890
# qn_789abc..  sensor-01       192.168.1.20:79  healthy    333777
# qn_def012..  sensor-02       192.168.1.21:79  healthy    333000

# Leave cluster (run on the node leaving)
./qpot cluster leave

Cluster Features

Feature Description
Password Auth All nodes require cluster ID + password to join
Automatic Discovery Nodes discover each other via gossip protocol
Health Monitoring Automatic detection of failed nodes
Event Aggregation Centralized view of attacks across all nodes
Encrypted Communication TLS encryption between cluster members
Read Replicas Database reads distributed across replicas

Integration with Yuril Security

QPot is designed to work seamlessly with the Yuril Security ecosystem:

YurilAntivirus Integration

When YurilAntivirus detects a threat on an endpoint, it can:

  • Query QPot for related attack patterns
  • Trigger honeypot redeployment with updated signatures
  • Share IOCs with the honeypot deception layer

YurilTracking Integration

QPot feeds real-time attack data to YurilTracking:

  • Source IP geolocation and reputation
  • Attack patterns and TTPs
  • Correlated threat intelligence

Lockdown Integration

Automatic system hardening when attacks are detected:

response:
  on_attack_detected:
    - notify_yuril_tracking
    - trigger_lockdown_hardening
    - isolate_attacker_ip

Deployment Modes

HIVE (Central Server)

Full installation with web UI, analytics, and sensor management:

./install.sh -t h -u admin -p 'SecurePass123!'

SENSOR (Distributed)

Lightweight sensor for remote deployment:

./install.sh -t s

MINI (Resource-Constrained)

Minimal footprint for edge deployments:

./install.sh -t i -u admin -p 'SecurePass123!'

Development

# Build from source
make build

# Run tests
make test

# Build for all platforms
make build-all

# Create release
make release

# Run locally
make dev

Project Structure

QPot/
├── cmd/qpot/              # CLI entry point
├── internal/
│   ├── cluster/          # Multi-instance cluster management
│   ├── config/           # Configuration management
│   ├── database/         # Database drivers (CH, TSDB, ES)
│   │   ├── migration.go         # Schema migrations
│   │   ├── retention.go         # Data retention & archival
│   │   └── pool.go              # Connection pooling
│   ├── intelligence/     # Threat intelligence engine
│   │   ├── attck.go             # MITRE ATT&CK loader (fetch + embedded fallback)
│   │   ├── rules.go             # Classification rules (16 built-in)
│   │   ├── classifier.go        # Real-time event classifier
│   │   ├── ioc.go               # IOC extractor
│   │   ├── ttp.go               # Behavioral TTP session builder
│   │   └── worker.go            # Background backfill worker
│   ├── security/         # Sandboxing and isolation
│   ├── instance/         # Instance lifecycle
│   └── server/           # API server
├── docker/
│   ├── attack-map/       # QPot-branded attack map
│   ├── clickhouse-kibana/# ES-compatible CH connector
│   └── nginx/            # Reverse proxy config
├── web/                  # Web UI
├── docs/                 # Documentation
└── scripts/              # Install/update scripts

License

MIT License - See LICENSE

Acknowledgments

QPot builds upon the excellent work of:

  • T-Pot CE by Deutsche Telekom Security - The foundation honeypot platform
  • The Honeynet Project - Honeypot research and development

QPot adds enterprise features, enhanced security, and integration with the Yuril Security ecosystem.

Support

Contributors

  • Yuril - Project lead and primary developer

Built by Yuril Security
Australian-made cybersecurity

About

Open Source Honeypot Framework

Resources

Readme
Activity

Stars

1 star

Watchers

0 watching

Forks

0 forks
Report repository

Releases

No releases published

Packages





Contributors

Languages
