MurmurRelay

Encrypt locally. Send anywhere.

MurmurRelay is a lightweight encrypted messaging relay SDK that separates secure message handling from the service used to deliver messages.

It is designed so apps can encrypt messages locally, send them through a configurable transport layer, and decrypt them only in clients that have the shared channel key. The transport can be Firebase, WebSockets, a custom backend, or another service.

What it does

MurmurRelay handles:

• message wrapping
• message IDs
• timestamps
• client-side encryption
• client-side decryption
• transport abstraction
• simple send and observe APIs

The relay service only moves encrypted payloads. It does not need to understand the message contents.

Current status

MurmurRelay is currently an Android/Kotlin SDK.

MurmurRelay is being developed alongside Murmur, where it is being integrated as the encrypted messaging layer.

Future versions may explore support for iOS, web, and additional transport adapters.

Project structure

MurmurRelay
├── sample
├── murmurrelay_core
└── murmurrelay_firebase

Basic usage

val relay = MurmurRelay(
    transport = InMemoryRelayTransport()
)

val channelId = "demo-channel"
val channelKey = MurmurRelay.createChannelKey()

relay.observe(
    channelId = channelId,
    channelKey = channelKey
) { message ->
    println(message.payload)
}

relay.send(
    channelId = channelId,
    channelKey = channelKey,
    payload = "Hello from MurmurRelay"
) { result ->
    when (result) {
        is MurmurRelayResult.Success -> println("Message sent")
        is MurmurRelayResult.Error -> println(result.message)
    }
}

Transport model

MurmurRelay uses a simple transport interface. A transport is responsible for moving encrypted payloads between devices or clients.

interface RelayTransport {
    fun sendMessage(
        channelId: String,
        encryptedPayload: String,
        onComplete: (MurmurRelayResult) -> Unit
    )

    fun observeMessages(
        channelId: String,
        onMessage: (String) -> Unit
    )
}

This allows the SDK to support different delivery systems without changing the encryption or message model.

Included modules

murmurrelay_core

Core SDK logic:

• MurmurRelay
• MurmurMessage
• encryption and decryption
• message encoding
• transport interface
• in-memory sample transport

murmurrelay_firebase

Firebase Realtime Database transport adapter for moving encrypted payloads.

Apps using this module should provide their own Firebase project configuration.

sample

A small demo app showing how MurmurRelay works using the in-memory sample transport.

The sample does not require Firebase.

Encryption

🟨 MurmurRelay does not currently handle key exchange. Apps are responsible for securely sharing or deriving channel keys.

MurmurRelay currently uses:

• AES-GCM
• PBKDF2WithHmacSHA256
• per-message random salt
• per-message random IV
• authenticated encryption

Messages are encrypted before they are passed to the transport layer.

Roadmap

Possible future work:

• digital signatures
• sender verification
• ECDH key exchange
• key rotation
• replay protection
• WebSocket transport
• Kotlin Multiplatform, iOS, or web support
• improved background delivery guidance for Android
• WebSocket transport adapter
• local network transport adapter
• custom backend transport examples
• community-contributed transport adapters

License

MIT

Author

Andy Friedl

Product designer / developer exploring secure communication tooling.

GitHub: https://github.com/andyfriedl Website: https://andyfriedl.com
