pictorialBar象形图设置symbolRepeat时，symbol之间间隔不一致

[Colin3191]

Version

5.3.2

Link to Minimal Reproduction

https://codesandbox.io/s/bold-breeze-w07h9h?file=/src/index.js

Steps to Reproduce

<rect y="12" width="16" height="2" fill="black"/>
<rect y="8" width="16" height="2" fill="black"/>
<rect y="4" width="16" height="2" fill="black"/>
<rect width="16" height="2" fill="black"/>
</svg>

{
  xAxis: {
    type: 'category',
    data: ['Mon', 'Tue', 'Wed', 'Thu', 'Fri', 'Sat', 'Sun']
  },
  yAxis: {
    type: 'value'
  },
  series: [
    {
      data: [120, 200, 150, 80, 70, 110, 130],
      type: 'pictorialBar',
      symbolMargin: 0,
      symbolRepeat: true,
      symbolSize:'100%',
      barWidth: '60%',
      symbol:
    }
  ]
}

option中设置的symbol是上面svg的base64格式

Current Behavior

symbol与symbol之间的间隙会随柱宽变化而变化

Expected Behavior

每个symbol之间有相同的间隙

Environment

- OS:
- Browser:
- Framework:

Any additional comments?

No response

[echarts-bot]

@Colin3191 It seems you are not using English, I've helped translate the content automatically. To make your issue understood by more people and get helped, we'd like to suggest using English next time. 🤗

TRANSLATED

TITLE

When the pictorialBar pictogram is set to symbolRepeat, the intervals between symbols are inconsistent

[Ovilia]

This bug seems to be more obvious when the canvas height is small.

[echarts-bot]

This issue is labeled with difficulty: easy.
@Colin3191 Would you like to debug it by yourself? This is a quicker way to get your problem fixed. Or you may wait for the community to fix.

Please have a look at How to debug ECharts if you'd like to give a try. 🤓

[github-actions]

This issue has been automatically marked as stale because it did not have recent activity. It will be closed in 7 days if no further activity occurs. If you wish not to mark it as stale, please leave a comment in this issue.

[github-actions]

This issue has been automatically closed because it did not have recent activity. If this remains to be a problem with the latest version of Apache ECharts, please open a new issue and link this to it. Thanks!
