CodeMirror extension that turns Markdown tables into interactive components

View live demo

Features • Installation • Usage • Customization • Credits • License

Features

Table editor

A powerful table component that seamlessly integrates with CodeMirror

Renders Markdown table text as interactive HTML tables
Autoformats and prettifies Markdown tables while editing
Renders custom styles and custom themes in code and/or CSS
Renders cells with multi-line text
Autocorrects line breaks around tables while editing to keep them separate from surrounding text
Integrates with native CodeMirror undo history
Integrates with native CodeMirror search
Implements touch-friendly controls and editing for mobile browsers
Autoinserts line breaks around pasted tables when necessary to keep them on their own lines
Autoescapes pipe characters in cell text

Interactions

Type multi-line text

Create line breaks with Shift+Enter (inserts a <br>)

Navigate around the table

Move around the table with Up,Down,Left,Right
Move to the next cell with Tab
- Append a new row by moving past the last cell
Move to the previous cell with Shift+Tab
- Prepend a new row by moving before the first cell
Move to the cell below with Enter
- Append a new row by moving past the last row

Select cells

Select a group of cells by Clicking and Dragging
- Scroll the table by Dragging past the editor edge
Resize the cell selection by Shift+Clicking and Dragging
Resize the cell selection with Shift+Up,Shift+Down,Shift+Left,Shift+Right

Clear cells

Clear selected cells with Backspace,Delete
Delete selected empty rows/columns with Backspace,Delete

Copy/paste cells

Copy selected cells as a Markdown table with Ctrl+C/Cmd+C
Cut selected cells as a Markdown table with Ctrl+X/Cmd+X
Paste a Markdown table into selected cells with Ctrl+V/Cmd+V
- Select excess cells to duplicate the pasted Markdown table across the extra cells

Rearrange a row/column

Move row/column by Clicking Row/Column and Dragging to a new location
- Scroll the table by Dragging past the editor edge

Insert rows/columns

Insert a row by Clicking Row Border
Insert one or more rows by Clicking Row Border and Dragging Down
Insert a column by Clicking Column Border
Insert one or more columns by Clicking Column Border and Dragging Right

Delete empty rows/columns

Delete one or more empty rows by Clicking Row Border and Dragging Up
Delete one or more empty columns by Clicking Column Border and Dragging Left

Append rows/columns

Append a row by Clicking Table Bottom Button
Append one or more rows by Clicking Table Bottom Button and Dragging Down
Append a column by Clicking Table Right Button
Append one or more columns by Clicking Table Right Button and Dragging Right
Append a row and column by Clicking Table Bottom-Right Button
Append one or more rows and columns by Clicking Table Bottom-Right Button and Dragging Down-Right

Trim empty rows/columns

Trim one or more empty rows by Clicking Table Bottom Button and Dragging Up
Trim one or more empty columns by Clicking Table Right Button and Dragging Left
Trim one or more empty rows and columns by Clicking Table Bottom-Right Button and Dragging Up-Left

Execute actions on a row/column

Open row/column menu by Clicking Row/Column
- Sort by column
- Align a column to left, center, or right
- Unalign a column
- Add a row/column
- Move a row/column
- Duplicate a row/column
- Clear a row/column
- Delete a row/column

Autocompletion

A convenient autocomplete menu for creating tables

Pops up a CodeMirror autocompletion menu after typing | on an empty line
Displays a customizable list of table size options

Command

A command that smartly inserts a new Markdown table

Inserts an empty Markdown table at the cursor or replaces the current selection
Adds line breaks around table when necessary to prevent overlap with surrounding text

Installation

npm install codemirror-markdown-tables

Usage

Add the core extension (required)

import { EditorView } from "@codemirror/view"

import { markdownTables } from "codemirror-markdown-tables"

// Add Markdown tables extension to CodeMirror
new EditorView({
  extensions: [markdownTables()],
})

Add an extension that autocompletes a table after typing `|` (optional)

import { autocompletion } from "@codemirror/autocomplete"
import { markdown, markdownLanguage } from "@codemirror/lang-markdown"
import { EditorView } from "@codemirror/view"

import { markdownTableAutocompleter } from "codemirror-markdown-tables"

// Create markdown language with GitHub-flavored Markdown support
const markdownLanguageSupport = markdown({ base: markdownLanguage })

// Create Markdown tables autocomplete extension (merges with other Markdown autocomplete extensions)
const markdownTableAutocompletion = markdownLanguageSupport.language.data.of({
  autocomplete: markdownTableAutocompleter(),
})

// Add all extensions to CodeMirror
new EditorView({
  extensions: [autocompletion(), markdownLanguageSupport, markdownTableAutocompletion],
})

Add a keyboard shortcut that inserts a Markdown table (optional)

import { EditorView, keymap } from "@codemirror/view"

import { insertEmptyMarkdownTable } from "codemirror-markdown-tables"

// Create key binding that inserts a 2x2 table
const insertTableKeyBinding = {
  key: "Alt-Mod-t",
  run: insertEmptyMarkdownTable(),
}

// Wrap the key binding inside a keymap and add the extension to CodeMirror
new EditorView({
  extensions: keymap.of([insertTableKeyBinding]),
})

Customization

Core config

Optional config passed into the markdownTables() function to customize the core extension

Property	Values	Default (when omitted or undefined)	Description
`theme`	`TableTheme`, `{ light: TableTheme; dark: TableTheme }`	`{ light: TableTheme.light, dark: TableTheme.dark }`	Color scheme for the table When set to a `light` and `dark` theme, the theme adjusts based on the CodeMirror light and dark mode configuration (not CSS `prefers-color-scheme`) When set to a single theme, the theme applies in both modes (i.e. `theme: SomeTheme` is equivalent to `theme: { light: SomeTheme, dark: SomeTheme }`)
`style`	`TableStyle`	`TableStyle.default`	Fonts and other styles for the table
`selectionType`	`"codemirror"`, `"native"`	`"codemirror"`	Text cursor and selection implementation for the table cell editor When set to `"codemirror"`, the editor uses CodeMirror's implementation Essentially, the CodeMirror editor embedded inside cells enables the `drawSelection` extension along with some CSS that hides the browser's native cursor and selection When set to `native`, the editor uses the browser's implementation Specify `native` only if `drawSelection` isn't enabled in the root CodeMirror editor (it's enabled by default with `basicSetup` and `minimalSetup`)
`handlePosition`	`"outside"`, `"inside"`	`"outside"`	Position of the row and column header grips When set to `"outside"`, handles appear beyond the top/left edge of the table This requires a sufficient left margin to keep the table edge aligned with the root CodeMirror editor edge, but it's much easier to click and drag the handles, especially on mobile When set to `"inside"`, handles appear on the top/left table border itself This requires no extra left margin, but it's difficult to click and drag the handles, especially on mobile
`lineWrapping`	`"wrap"`", `"nowrap"`	`"wrap"`	Wrapping mode of the table When set to `"wrap"`, wraps long table cell text Essentially, the CodeMirror editor embedded inside cells enables the `lineWrapping` extension along with the CSS `"word-break": "normal", "overflow-wrap": "break-word"` When set to `"nowrap"`, the editor does not wrap long table cell text The editor sets the CSS to `white-space: "pre"`
`extensions`	`Extension[]`	`[]`	Extensions for the table cell editor The CodeMirror editor embedded inside cells (not the root CodeMirror editor) enables the given extensions The table cell editor doesn't automatically inherit root CodeMirror editor extensions Instead, specify basic editor extensions like `highlightWhitespace` here to enable them inside cells Keyboard shortcuts specified here execute actions on the CodeMirror editor embedded inside cells, rather than the root CodeMirror editor They operate on the text inside the cell in isolation, rather than the text of the document as a whole Specify KeyBindings from `defaultKeymap` or similar here to enable basic shortcuts inside the cell editor `defaultKeymap` defines shortcuts like `Ctrl+A`/`Cmd+A` which should select all the cell text rather than all the document text Conversely, specify KeyBindings from `historyKeymap` and `searchKeymap` in `globalKeyBindings` instead, since these keyboard shortcuts operate on the root CodeMirror editor and the document as a whole
`markdownConfig`	`MarkdownConfig`	`{}`	Markdown language configuration for the table cell editor The CodeMirror editor embedded inside cells calls the `markdown()` function in `@codemirror/lang-markdown` with the specified options The table cell editor doesn't automatically inherit the root CodeMirror Markdown language configuration See `@codemirror/lang-markdown` for descriptions
`globalKeyBindings`	`KeyBinding[]`	`[]`	Keyboard shortcuts for the table cell editor that delegate to the root CodeMirror editor Keyboard shortcuts specified here execute actions on the root CodeMirror editor, rather than the CodeMirror editor embedded inside cells They operate on the text of the document as a whole, rather than the text inside the cell in isolation Specify KeyBindings from `historyKeymap` or similar here to enable history shortcuts while inside the cell editor `historyKeymap` defines keyboard shortcuts like `Ctrl+Z`/`Cmd+Z` which should undo across the document text rather than just the cell text Another example is `searchKeymap` which defines keyboard shortcuts that should search across the entire document text rather than just the cell text Conversely, specify KeyBindings from `defaultKeymap` in `extensions` instead, since these keyboard shortcuts operate on the CodeMirror editor embedded inside cells and the text inside the cell in isolation

Table theme

A theme is a collection of properties that define the CSS color scheme

Built-in themes

Name	Description
`TableTheme.light`	Basic light theme that works well with the CodeMirror default theme
`TableTheme.dark`	Basic dark theme
`TableTheme.githubLight`	Theme based on table colors in GitHub's light theme
`TableTheme.githubDark`	Theme based on table colors in GitHub's dark theme
`TableTheme.githubSoftDark`	Theme based on table colors in GitHub's soft dark theme
`TableTheme.oneDark`	Dark theme that works well with `@codemirror/theme-one-dark`

Custom themes

Create custom themes in code or override theme properties in CSS

In code

import { TableTheme } from "codemirror-markdown-tables"

const customDarkTheme = TableTheme.dark.with({
  "--tbl-theme-header-row-background": "gray",
  "--tbl-theme-outline-color": "green",
})

In CSS

:root {
  --tbl-theme-header-row-background: gray;
  --tbl-theme-outline-color: green;
}

Properties

Theme properties correspond directly to CSS variables of the same name defined in :root scope

Property	Values	Description
`--tbl-theme-row-background`	CSS `color`	Background color of all cells, unless overriden by other `*-row-background` properties
`--tbl-theme-header-row-background`	CSS `color`	Background color of the cells in the header row
`--tbl-theme-even-row-background`	CSS `color`	Background color of the cells in even rows
`--tbl-theme-odd-row-background`	CSS `color`	Background color of the cells in odd rows (except the header row)
`--tbl-theme-border-color`	CSS `color`	Color of borders
`--tbl-theme-border-hover-color`	CSS `color`	Color of a hovered border
`--tbl-theme-border-active-color`	CSS `color`	Color of a clicked border
`--tbl-theme-outline-color`	CSS `color`	Color of the outline around selected cells
`--tbl-theme-text-color`	CSS `color`	Color of text
`--tbl-theme-menu-border-color`	CSS `color`	Color of menu borders
`--tbl-theme-menu-background`	CSS `color`	Background color of menu items
`--tbl-theme-menu-hover-background`	CSS `color`	Background color of a hovered menu item
`--tbl-theme-menu-text-color`	CSS `color`	Color of menu item text
`--tbl-theme-menu-hover-text-color`	CSS `color`	Color of hovered menu item text
`--tbl-theme-select-all-focus-overlay`	CSS `color`	Color of the layer overlaid on table when a `Select All` takes place and the editor has focus The overlay shows as an alpha layer above the table whereas CodeMirror places its default selection background behind editor text So specify an alpha overlay color that, when mixed with the table background color, mimics the opaque CodeMirror selection background color
`--tbl-theme-select-all-blur-overlay`	CSS `color`	Color of the layer overlaid on table when a `Select All` takes place and the editor doesn't have focus The overlay shows as an alpha layer above the table whereas CodeMirror places its default selection background behind editor text So specify an alpha overlay color that, when mixed with the table background color, mimics the opaque CodeMirror selection background color

Table style

A style is a collection of properties that define fonts and other CSS styles

Built-in styles

Name	Values	Description
`TableStyle.default`	`{ "--tbl-style-font-family": "system-ui", "--tbl-style-font-size": "inherit", "--tbl-style-menu-font-family": "system-ui", "--tbl-style-menu-font-size": "inherit", "--tbl-style-default-header-alignment": "left", }`	Basic style with sensible defaults

Custom styles

Create custom styles in code or override style properties in CSS

In code

import { TableStyle } from "codemirror-markdown-tables"

const customStyle = TableStyle.default.with({
  "--tbl-style-font-family": '"Comic Sans", sans-serif',
  "--tbl-style-font-size": "16px",
})

In CSS

:root {
  --tbl-style-font-family: "Comic Sans", sans-serif;
  --tbl-style-font-size: 16px;
}

Properties

Style properties correspond directly to CSS variables of the same name defined in :root scope

Property	Values	Description
`--tbl-style-font-family`	CSS `font-family`	Font family of text
`--tbl-style-font-size`	CSS `font-size`	Font size of text
`--tbl-style-menu-font-family`	CSS `font-family`	Font family of menu item text
`--tbl-style-menu-font-size`	CSS `font-size`	Font size of menu item text
`--tbl-style-default-header-alignment`	`"left"`, `"center"`, `"right"`	Alignment of text in header cell when its column is otherwise unaligned

Table autocompleter config

Optional config passed into the markdownTableAutocompleter() function to customize the autocompleter

Property	Values	Default (when omitted or undefined)	Description
`options`	`{ rows: number, cols: number}[]`	`[{ rows: 2, cols: 2 }, { rows: 3, cols: 3 }, { rows: 4, cols: 4 }]`	Options shown in the autocomplete popup

Insert table command config

Optional config passed into the insertEmptyMarkdownTable() function to customize the insert table command

Property	Values	Default (when omitted or undefined)	Description
`size`	`{ rows: number, cols: number}`	`{ rows: 2, cols: 2 }`	Size of the inserted table

Examples

Complete, minimal configuration

import { basicSetup } from "codemirror"
import { markdown, markdownLanguage } from "@codemirror/lang-markdown"
import { EditorView, keymap } from "@codemirror/view"

import {
  insertEmptyMarkdownTable,
  markdownTables,
  markdownTableAutocompleter,
} from "codemirror-markdown-tables"

const markdownLanguageSupport = markdown({ base: markdownLanguage })

new EditorView({
  extensions: [
    basicSetup,
    markdownLanguageSupport,
    markdownLanguageSupport.language.data.of({ autocomplete: markdownTableAutocompleter() }),
    markdownTables(),
    keymap.of([{ key: "Alt-Mod-t", run: insertEmptyMarkdownTable({ rows: 2, cols: 2 }) }]),
  ],
  parent: document.body,
})

Complete, extensive configuration

import { basicSetup } from "codemirror"
import { defaultKeymap, historyKeymap } from "@codemirror/commands"
import { markdown, markdownLanguage } from "@codemirror/lang-markdown"
import { searchKeymap } from "@codemirror/search"
import { EditorView, highlightSpecialChars, keymap } from "@codemirror/view"
import { Autolink, Emoji, Strikethrough, Subscript, Superscript } from "@lezer/markdown"

import {
  insertEmptyMarkdownTable,
  markdownTables,
  markdownTableAutocompleter,
  TableStyle,
  TableTheme,
} from "codemirror-markdown-tables"

const markdownLanguageSupport = markdown({ base: markdownLanguage })

new EditorView({
  extensions: [
    basicSetup,
    markdownLanguageSupport,
    markdownLanguageSupport.language.data.of({
      autocomplete: markdownTableAutocompleter({
        options: [
          { rows: 2, cols: 2 },
          { rows: 3, cols: 3 },
        ],
      }),
    }),
    markdownTables({
      theme: {
        light: TableTheme.light,
        dark: TableTheme.dark.with({
          "--tbl-theme-row-background": "#000",
          "--tbl-theme-text-color": "#ccc",
          "--tbl-theme-menu-background": "#000",
          "--tbl-theme-menu-text-color": "#ccc",
        }),
      },
      style: TableStyle.default.with({
        "--tbl-style-font-size": "16px",
        "--tbl-style-menu-font-size": "14px",
        "--tbl-style-default-header-alignment": "center",
      }),
      markdownConfig: {
        extensions: [Strikethrough, Autolink, Subscript, Superscript, Emoji],
      },
      extensions: [highlightSpecialChars(), keymap.of(defaultKeymap)],
      globalKeyBindings: [...historyKeymap, ...searchKeymap],
    }),
    keymap.of([{ key: "Alt-Mod-t", run: insertEmptyMarkdownTable({ rows: 3, cols: 3 }) }]),
  ],
  parent: document.body,
})

Light and dark mode CSS overrides

/* Only applies in CodeMirror light mode */
:root:has([data-tbl-theme-mode="light"]) {
  --tbl-theme-row-background: gray;
}

/* Only applies in CodeMirror dark mode */
:root:has([data-tbl-theme-mode="dark"]) {
  --tbl-theme-row-background: #000;
}

Name		Name	Last commit message	Last commit date
Latest commit History 10 Commits
.github/workflows		.github/workflows
lint		lint
media		media
src		src
test/lib		test/lib
testSupport		testSupport
.editorconfig		.editorconfig
.gitignore		.gitignore
.prettierignore		.prettierignore
.prettierrc.mjs		.prettierrc.mjs
.vale.ini		.vale.ini
LICENSE		LICENSE
README.md		README.md
eslint.config.js		eslint.config.js
index.html		index.html
package-lock.json		package-lock.json
package.json		package.json
svelte.config.js		svelte.config.js
tsconfig.app.json		tsconfig.app.json
tsconfig.json		tsconfig.json
tsconfig.node.json		tsconfig.node.json
vite.config.app.ts		vite.config.app.ts
vite.config.demo.ts		vite.config.demo.ts

Folders and files

Latest commit

History

Repository files navigation

CodeMirror extension that turns Markdown tables into interactive components

Features

Table editor

Interactions

Type multi-line text

Navigate around the table

Select cells

Clear cells

Copy/paste cells

Rearrange a row/column

Insert rows/columns

Delete empty rows/columns

Append rows/columns

Trim empty rows/columns

Execute actions on a row/column

Autocompletion

Command

Installation

Usage

Add the core extension (required)

Add an extension that autocompletes a table after typing | (optional)

Add a keyboard shortcut that inserts a Markdown table (optional)

Customization

Core config

Table theme

Built-in themes

Custom themes

In code

In CSS

Properties

Table style

Built-in styles

Custom styles

In code

In CSS

Properties

Table autocompleter config

Insert table command config

Examples

Complete, minimal configuration

Complete, extensive configuration

Light and dark mode CSS overrides

Credits

License

About

Topics

Resources

License

Uh oh!

Stars

Watchers

Forks

Releases

Contributors 1

Languages

Add an extension that autocompletes a table after typing `|` (optional)
