BattleShip

Python implementation of BattleShip for 2 players using sockets.

How to play:

Ensure you are using Python 3.10 or later.

python3 --version

On the school systems, Python 3.10 can be loaded with the following command:

module load python/anaconda

Install the required packages:

pip install -r requirements.txt

Start the server:

python3 server.py  # Default port is 29999, default host is localhost

# To specify a port:
python3 server.py -p 30000  # Port 30000

# To specify a host:
python3 server.py -i 0.0.0.0  # Host

Connect clients:

Client port argument must match the server port argument. Clients are dynamically assigned a port by the server.

python3 client.py  # Default port is 29999

# To specify a port:
python3 client.py -p 30000  # Port 30000

Enter your name when prompted:

Welcome to Battleship! Please enter your name:

The game will begin once both players have connected.

Position your ships!

Commands:

Available Commands:
  move [x] [y] - Make a move at the specified coordinates (e.g., move 3 5)
  chat [message] - Send a chat message to your opponent
  view - View the current state of the game board
  quit - Quit the current game

Play the game:

• Each player positions their battleships using the command line.
  • Position with coordinates (row, column) and orientation (horizontal or vertical).
  • Position randomly by typing random.
  • Position for demo by typing demo. This will advance the board to a late game three-hits to win scenario.
• The game starts.
• Players take turns targeting chosen coordinates, attempting to sink each others ships.
• The first player to eliminate all their opponents ships wins the game!

Technologies Used:

• Python
• Sockets

Sprint 1

Deliverables:

• TCP BattleshipServer: Manages player connections, game state, and turn-based gameplay over TCP.
• TCP BattleshipClient: Connects to the server, handles player interactions and game commands via the command line.
• Message Protocol Class: Serializes and deserializes game data in JSON format for communication between server and clients.
• ErrorHandler Wrapper Class: Provides error handling and recovery mechanisms for server and client methods.
• Unit Tests for Client-Server Communication: Validates client-server communication, message integrity, and server reliability (work in progress).

Sprint 2

Deliverables:

• Designed and Implemented Protocol in Client and Server: Developed a communication protocol for message exchange between the server and clients.
• Defined the Structure and Format of Messages: Established the format for messages exchanged between the server and clients, including message types, data fields, and expected responses.
• Receive, Parse, and Process Messages: Handles incoming messages from clients and parses different message types such as join requests, move commands, and chat messages.
• Send Messages to Server: Implement the ability to send detailed messages to the server, parse server responses, and provide feedback to the user about any errors.
• Handle Client Connections and Disconnections: Implemented mechanisms to manage client connections and disconnections, keep track of connected clients, and inform other clients when a player joins or leaves the game.

Sprint 3

• Refactor Codebase: Refactored the codebase to improve readability, maintainability, and scalability.
• Simplified Message Handling: Simplified message handling by using action based messages.

Sprint 4

Deliverables:

• Winning Condition: Implement the winning condition for the game.
• Command Line Arguments: Add command line arguments to the server and client for specifying the host and port.
• User Interface: Expand the user interface to include more detailed information about the game state and player actions.

Sprint 5

Deliverables:

• Error Handling: Improved error handling and error messages for better user experience. Balanced use of decorators and try-except blocks.
• Integration Testing: Conducted integration testing to ensure the server and client work together as expected.
• Security / Risk Evaluation:
  • Man-in-the-Middle Attack: This game does not have the requisite handshake protocols safeguard against MITM attacks. This can be addressed by implementing a secure certificate based handshake protocol.
  • Source Spoofing: The game does not have any source spoofing protection. This can be addressed by implementing a secure handshake protocol.
  • Denial of Service (DoS) Attack: The game is vulnerable to DoS attacks. This can be addressed by implementing rate limiting and connection throttling.
  • Code Injection: The game is vulnerable to code injection attacks. This can be addressed by validating user input and using secure serialization methods.

Project Roadmap

I could foresee further development of this project in the following directions:

• GUI Implementation: Develop a graphical user interface for the game to enhance the user experience.
• Refine Existing Features: Improve the existing features and functionalities of the game, such as adding a rematch option or re-entering the match queue.
• Add More Game Modes: Implement additional game modes, such as a single-player mode against AI or a tournament mode.
• Enhance Security: Improve the security of the game by implementing secure communication protocols and input validation.
• Potential ML Tournament: Organize a machine learning tournament where AI agents play against each other in the game of Battleship, with boards of 1000x1000 or larger and fleets of 15-20 ships with variant caliber munitions.

Retrospective:

What went well?

• Successfully implemented the core functionality of the game.
• Developed a robust communication protocol for client-server interactions.
• Learned a lot about socket programming and message serialization.

What could have gone better?

• A GUI could have been implemented to enhance the user experience.
• More comprehensive error handling, testing, and logging could have been implemented.
• Additional features such as rematch or re-enter match queue could have been added.

Additional Resources:

• Getting started with Python

Additional documentation coming soon
