3D Point Cloud Alignment (ICP)

A C++ and CUDA implementation of the Iterative Closest Point (ICP) algorithm, both with brute force approach and KD-Tree implementation. This project demonstrates point cloud alignment and compares CPU vs GPU performance using parallel computing.

Features

• CPU Implementation: Uses Eigen for SVD-based rigid transformations
• CUDA Implementation: GPU-accelerated version with parallel nearest neighbor search, centroid computation, and transformation (Tested on remote GPU server in Linux only)
• Visualization: Open3D-based replay tool (Tested on Windows only)
• Performance Comparison: Demonstrates 300x speedup with GPU acceleration on large point clouds

Algorithm Details

ICP Pipeline

1. Nearest Neighbor Search: Find closest target point for each source point using K-d Tree
2. Centroid Computation: Calculate centers of mass for both point sets
3. SVD Transformation: Compute optimal rigid transformation (rotation + translation)
4. Apply Transform: Update source points
5. Iterate: Repeat until convergence (50 iterations)

CUDA Optimizations

• Parallel Nearest Neighbor Search:

Each thread is assigned to process one source point, enabling massive parallelism across the point cloud.

• Shared Memory Tiling: (icp_cuda_v2)

To minimize slow global memory access, target points are cooperatively loaded into fast, on-chip shared memory in blocks (tiles). This reduces global memory reads by a factor equal to the TILE_SIZE.

• Memory Alignment with float4: (icp_cuda_v3)

Data structures were shifted from float3 to float4 to ensure 128-bit memory alignment. This allows the GPU to perform perfectly coalesced memory transactions, maximizing effective bandwidth.

• Shared Memory Reductions:

Centroid computation utilizes a parallel tree-reduction pattern in shared memory to avoid race conditions and safely sum point coordinates.

• GPU-Accelerated Covariance Matrix:

The 3X3 covariance matrix is calculated using a hybrid approach where the GPU performs the heavy summation of outer products via atomicAdd and the CPU handles the final SVD.

• Parallel Point Transformation:

Once the optimal rotation and translation are found, a specialized kernel applies the 4X4 transformation matrix to the entire source cloud in a single parallel pass.

Computerphile has videos on both ICP and KD-Tree:

Prerequisites

For Windows

• Windows 10/11
• Visual Studio 2022 (C++ Desktop Development workload)
• CMake 3.18+
• Open3D libraries (e.g., D:/Open3D/open3d-devel-windows-amd64-0.19.0/CMake)

For Linux

• CUDA Toolkit 11.0+ with compatible NVIDIA GPU
• CMake 3.18+
• Eigen3 library

Installation

Eigen3 and OPEN3D Setup (for Linux)

sudo apt-get install libeigen3-dev
sudo apt-get install libopen3d-dev

If the sudo command does not work, download pre-built release (https://github.com/isl-org/Open3D/releases)

cd ~
wget https://github.com/isl-org/Open3D/releases/download/v0.18.0/open3d-devel-linux-x86_64-cxx11-abi-0.18.0.tar.xz
tar -xf open3d-devel-linux-x86_64-cxx11-abi-0.18.0.tar.xz

Update CMakeLists.txt to point to it, e.g: set(Open3D_DIR "$ENV{HOME}/open3d-devel-linux-x86_64-cxx11-abi-0.18.0/lib/cmake/Open3D")

OPEN3D Setup (for Windows)

Follow the guide here https://www.open3d.org/docs/release/getting_started.html#c

(Note: Eigen is also installed with Open3D, no need for Eigen installation if you are on Windows)

Update CMakeLists.txt to point to it, e.g: set(Open3D_DIR "D:/Open3D/open3d-devel-windows-amd64-0.19.0/CMake")

Build Instructions

Windows

# Open x64 Native Tools Command Prompt for VS 2022
mkdir build
cd build
cmake ..
cmake --build . --config Release

Linux

mkdir build && cd build
cmake ..
make -j$(nproc)

Usage

1. Generate Target Data

Create a transformed target point cloud:

Windows:

.\build\Release\generate_data.exe data/bun000.ply

Linux:

./build/generate_data data/bun000.ply

Output: data/bun000_target.ply

2. Run ICP Alignment

CPU Version: Remove kd_tree argument for brute force nearest neighbor search

Windows:

.\build\Release\icp_engine.exe data/bun000.ply data/bun000_target.ply kd_tree

Linux:

./build/icp_engine data/bun000.ply data/bun000_target.ply kd_tree

CUDA Version:

Not tested on Windows.

Linux:

./build/icp_cuda data/bun000.ply data/bun000_target.ply

./build/icp_cuda_kdtree data/bun000.ply data/bun000_target.ply

Output: Creates frames/ directory with intermediate alignment steps (iter_0.ply, iter_5.ply, etc.)

3. Visualize Results

.\build\Release\icp_vis.exe data/bun000_target.ply

Not tested on Linux.

Opens an interactive Open3D window showing the alignment animation.
