QuickDash is a customizable TUI dashboard.

A simple dashboard I made for my homelab.

Features

• View RAM, CPU, and Disk usage

• Customizable tabs with log streaming and custom command output

  TUI

• Install it on your server

• Since it's TUI, you can access from anywhere via SSH

  Live loaded configs

• QuickDash uses watchfiles to see changes in the config file, and applies them instantly.

Screenshots

Video

quickdashDemo.mp4

Installation

pipx, uvx (TODO)

Installation Script

curl -s https://raw.githubusercontent.com/khr519/QuickDash/main/install.sh | bash

OR, clone the repo, install deps, and run main.py!

Configuration

The configuration file can be found in

• a) settings.toml inside the folder you installed QuickDash in, if you installed via cloning the repo or using the installation script.
• b) ~/.config/quickdash/settings.toml if you installed using pipx or uvx <-- WIP

The settings.toml contains an example configuration. You can edit that to customize your setup.

disks:

[[disks]]
name = "ROOT"
path = "/"

[[disks]]
name = "HOME"
path = "/home"

The disks section is where the disk usage shown in the top bar is configured.

• name is the displayed name of each disk.
• path is the path to check disk usage

tabs:

Note: The python code snippet insideparse is executed using eval().

[tabs."Tab Name"]
container = "container name"
command = { exec = "command to run", parse = "parsing code" }
log = { command = "log command", ignore = ["strings to ignore"], parse = "parsing code" }

The tabs section is where tabs containing log viewers and custom command outputs are configured.

If tab is for a docker container:

1. Set container to your docker container name. (or, for some reason you don't want to, follow this)

2. If you want to see a custom command output, set command.

   • command.exec is the disired command to run inside the container.

     (because the container is specified, the actual command will look like docker exec {container} {command.exec})

   • command.parse is optional. It parses the command output using the given python code snippet. The variable output contains the command output.

   • ex) command = { exec = "date", parse = "f'The current date and time is: {output}'" }

3. The log is fetched using docker logs -f {container} by default.

   • The command to use can be specified by setting log.command = "your command"
   • log.ignore = [] is optional. It can be set to ignore lines containing the strings specified.
   • log.parse is optional. It parses each line of log using the given python code snippet. The variable line contains one line of log.

# Example using docker container (itzg/docker-minecraft-server)
[tabs."Minecraft Server"]
container = "minecraft-mc-1"
command = { exec = "rcon-cli list", parse = "f'online: {output.split(' ')[2]}/{output.split(' ')[7]}'" }
#           ^^^^ This will execute "docker exec minecraft-mc-1 rcon-cli list"
log = { ignore = ["RCON","villager"], parse = "f'the server says: {line}'" }

If tab is not for a docker container

LXC, VM, some service on host, etc...

1. Do not specify container (which is ment for docker)

2. If you want to see a custom command output, set command.

   • command.exec is the disired command to run.
   • command.parse is optional. it parses the command output using the given python code snippet. the variable output contains the command output.
   • ex) command = { exec = "date", parse = "f'The current date and time is: {output}'" }

3. You can fetch logs by setting log

   • Set log.command to fetch logs. Use the -f flag if available.
   • log.ignore = [] is optional. It can be set to ignore lines containing the strings specified.
   • log.parse is optional. It parses each line of log using the given python code snippet. The variable line contains one line of log.

# Example using journalctl and date
[tabs."System Journal"]
command = { exec = "date", parse = "f'The current date and time is: {output}'" }
log = { command = "journalctl -f", ignore = ["CRON","ACPI"], parse = "f'[System Journal] ==> {line}'" }
