Password Manager

How to run

Prerequisites

Before you start, you need to have Python 3.8 (or higher version) installed on your machine.

Running

# clone this repository
$ git clone <https://github.com/plhrsl/passmanager>

# enter the project folder
$ cd passmanager

# start a virtual environment (here i'm using pipenv)
$ pipenv shell

# install the requirements to run the project
$ pip install -r requirements.txt

# make the migrations
$ python manage.py makemigrations

# apply migrations to your database
$ python manage.py migrate

# start the web server
$ python manage.py runserver

# the development server will start at http://localhost:8000/

Distinctiveness and complexity

Similarly to project 3 (mail) this is a single page web app that uses JavaScript to make requests to routes defined in the backend and control which parts of the page are displayed. However, it is a password manager - a type of application not explored in previous projects - thus distinguishing itself from these.

The greater complexity of the page in relation to previous projects is in the functionalities related to the frontend, such as: option to show/hide the password; the button that allows you to copy the username and password to the user's clipboard; and the favicon display of the access sites.

Files

The main directory is a Django project called passmanager that contains a single app called pass.

The pass directory contains files and folders that make up a Django app. Let's highlight some of them: the static/pass and templates/pass folders and the models.py, views.py and urls.py files.

• static/pass

  Here are the application's static files: index.js, which contains the JavaScript code; styles.css, which contains some additional styling - given that the main styling of the webapp was done using the Bootstrap framework; lock.png - the site's logo - and favicon.ico.

  The script contains functions that deal with showing/hiding parts of the HTML document and dynamically generating HTML elements. Moreover, every request to the server is made using JavaScript. The defined functions are as follows:

  • getAccesses() - responsible for obtaining the accesses of the logged in user and generating, for each of them, a card element with their information. Each card is appended to the accesses view div.

  • loadAccessesView() and loadAccessView() - toggle between showing the home page with all user accesses or the access add/edit form.

  • addAccess(), updateAccess() and deleteAccess() - perform, respectively, POST, PUT and DELETE requests to the server.

  • generatePassword() - generates a strong password for the user.

  • copy() - copy username or password to user's clipboard.

  • hideAndUnhide() - toggles between displaying or not displaying the password for a certain access on the screen.

  • showAlert() - creates an alert HTML element for some actions within the app: copy username/password; and add, edit, or remove access.

• templates/pass

  This folder all the app's html files: layout.html - which contains the structure base of the other pages, including the navigation bar; login.html and register.html, which contain the application's registration and login forms; and index.html, the main page.

  It's considered good development practice in Django projects for templates and static folders to contain a directory with the same name as the app it belongs to.

• models.py

  This file defines the application models. A model contains the essential fields and behaviors of the data being stored, and each of these maps to a table in the database. In the case of this application, two models are defined: User - which inherits from the AbstractUser provided by Django; and Access - which contains the fields user, site, username and password.

• views.py and urls.py

  In views.py the behaviors of each one of the routes created in the urls.py file are defined. Each path is linked to a function:

  • /register, /login and /logout - control the registration, login and logout of users.

  • /home - returns a JSON Response containing an array with all accesses of the logged in user.

  • /accesses - receives POST requests and creates new accesses.

  • /accesses/<int:access_id> - receives GET, PUT and DELETE requests and returns, edits or removes an access based on id.

Video demo: https://youtu.be/t5CFSgU1R5I
