lavan

Pupil, glint, and limbus detection on grayscale eye images, plus iris-texture rigid alignment of two eye images. Includes C-accelerated Daugman boundary detectors (used by the limbus detector) and a vendored Pupil Labs 2D pupil detector.

Name

Lavan (لاوان) is an island in the Persian Gulf.

What's inside

Four sub-packages, each owning its own surface:

• lavan.boundary — Daugman-derived boundary detectors: C-accelerated integro-differential operator (1993/2004, circle fit), Fourier-series active contour (2007, non-circular), and an in-house pupil-shape-prior variant.
• lavan.detect — threshold-based pupil and glint detection, and a Daugman-operator limbus detector, for grayscale eye images.
• lavan.pupil_detector_2d — Pupil Labs' 2D pupil detector from the Pupil Core eye-tracking platform, vendored under LGPL v3 from pupil-labs/pupil-detectors and built natively for every wheel platform. Exposes Detector2D, DetectorBase, and Roi. See NOTICE.md for attribution.
• lavan.align — rigid alignment of two eye images by iris texture, given pupil + limbus geometry on each. Returns (dx, dy, theta). Includes iris-centre alignment, minimum-difference search, barrel/iris-mask helpers, and matplotlib-based blend / diff / overlay plotting.

lavan.detect settings

Function	Settings
detect_pupil(img, ...)	pupil_threshold (0–255, default 30), pupil_center_method (convex_hull_centroid / center_of_mass / ellipse_fit_center / min_area_rect_center), pupil_roi (optional (x, y, w, h)), shape gates min_ellipse_fit_ratio / min_roundness_ratio (both 0–1, off by default)
detect_glints(img, pupil_center, pupil_radius, ...)	glint_threshold (0–255, default 240), search_radius_factor (× pupil radius, default 2.0), glint_roi, glint_center_method (same four methods), max_area_px, half-plane filters keep_above / keep_below / keep_left / keep_right + filter_margin_px, glints_target (expected count), split_widest_for_target (4-LED merge case), shape gates as in detect_pupil
detect_limbus(img, pupil_center, pupil_radius, ...)	r_min_factor / r_max_factor (limbus radius range as × pupil radius), search_window_px (centre-search half-window)

lavan.pupil_detector_2d.Detector2D settings

Detector2D exposes 22 properties via get_properties() / update_properties(). The practical ones to start tuning:

Property	Meaning	Default
intensity_range	Pupil-vs-iris brightness gap (0–255 grey levels)	23
pupil_size_min / pupil_size_max	Pupil diameter bounds in pixels	10 / 100
blur_size	Pre-detection Gaussian kernel (odd integer)	5
coarse_detection	Enable Pupil Core's coarse-pupil pre-pass	True
canny_treshold / canny_ration / canny_aperture	Canny edge-detection params	160 / 2 / 5

Run Detector2D().get_default_properties() for the full set + advanced gates.

lavan.align strategies + settings

align_eye_images is the high-level entry point. It runs up to two steps. The caller picks both:

Strategy	step1	step2	Notes
Glint translation only	"glint" (default)	False	Pure translation so glint centroids match. Needs glints in both detections.
Pupil translation only	"pupil"	False	Pure translation so pupil centres match. Needs pupil_center or pupil_ellipse in both.
Iris-texture search only	None	True	No pre-translation; iris-barrel min-diff search covers the full (dx, dy, theta) range. Needs limbus in both.
Glint translation, then iris search	"glint" (default)	True (default)	Default behaviour. Step 1 brings the eyes close; step 2 refines inside the iris barrel.
Pupil translation, then iris search	"pupil"	True	Same as the default but anchored on the pupil instead of the glint. Useful when no usable glint is present.
No-op	None	False	Returns the target unchanged.

Returned dict::

{
    "aligned":            <warped target image, same shape as ref_img>,
    "step1_translation":  (dx, dy)        or None when step1 is None,
    "step2_transform":    (dx, dy, theta) or None when step2 is False,
    "rotation_center":    (cx, cy)       or None when step2 is False,
}

Lower-level settings on the individual functions:

Function	Settings
align_by_min_diff(img_ref, img_mov, mask, ...)	dx_range / dy_range (integer-pixel search bounds, default ±10), rot_range ((start, end, step) degrees, default ±2° at 0.05° steps), rotation_center (defaults to image centre). Coarse integer pass + sub-pixel refinement.
align_by_translation(ref_point, mov_point)	Translation-only; no settings. Generic point-to-point translation — give it any two points (glint centroids, pupil centres, iris centres) and it returns the (dx, dy, 0.0) that maps mov_point onto ref_point.
make_iris_mask(img_shape, limbus_center, limbus_r, pupil_r, ...)	exclude_top (degrees of upper eyelid arc to drop, default 60), exclude_bottom (default 45), inner_margin (pixels added to the pupil radius to avoid pupil-edge bleed, default 15).
make_barrel_mask(...)	Same parameters as make_iris_mask; fills the gap between the left/right crescents to produce a filled barrel rather than a ring.

Installation

pip install lavan

Building from source

If you want to build a wheel yourself (or develop against lavan), the build is driven by scikit-build-core and needs CMake plus OpenCV 4 and Eigen 3 development packages on the host:

• macOS: brew install cmake eigen opencv
• Linux: apt-get install cmake libeigen3-dev libopencv-dev (or your distro's equivalent; manylinux CI builds OpenCV from source via scripts/manylinux-before-all.sh)
• Windows: choco install -y cmake eigen opencv

Then:

git clone https://github.com/mh-salari/lavan
cd lavan
pip install .

lavan ships compiled C/C++ extensions and is not intended to be installed editable — pip install -e . would leave the compiled binaries outside the source tree, where the ctypes loader can't find them. Rebuild + reinstall after edits instead.

Quick start

Single-image detection

import cv2
from lavan.detect import detect_pupil, detect_glints, detect_limbus

img = cv2.imread("eye.png", cv2.IMREAD_GRAYSCALE)

pupil = detect_pupil(img, pupil_threshold=30)
glints = detect_glints(
    img,
    pupil_center=pupil["center"],
    pupil_radius=pupil["radius"],
    glint_threshold=240,
)
limbus = detect_limbus(img, pupil_center=pupil["center"], pupil_radius=pupil["radius"])

A command-line wrapper for single-image detection is installed as lavan-detect.

Pupil Labs 2D detector

import cv2
from lavan.pupil_detector_2d import Detector2D

detector = Detector2D()
img = cv2.imread("eye.png", cv2.IMREAD_GRAYSCALE)
result = detector.detect(img)
print(result["ellipse"], "confidence:", result["confidence"])

Iris-texture alignment

from lavan.align import align_eye_images

# ``ref_geom`` / ``tgt_geom`` each carry the detected pupil + limbus geometry
# for that image. align_eye_images returns the rigid transform that warps
# the target onto the reference, measured by iris-texture similarity inside
# a barrel-shaped iris mask (eyelid zones excluded).
dx, dy, theta = align_eye_images(ref_img, ref_geom, tgt_img, tgt_geom)

License

lavan is released under the GNU Lesser General Public License v3 or later (LGPL-3.0-or-later). The LGPL incorporates the GPL by reference; both are shipped with the package. See NOTICE.md for vendored components and their attribution.

Acknowledgments

This work received funding from the European Union's Horizon Europe research and innovation funding program under grant agreement No 101072410, Eyes4ICU project.
