NRCS Dimensionless Unit Hydrograph Generator

---

🚀 Overview

The NRCS Dimensionless Unit Hydrograph Generator is an interactive web application for generating synthetic hydrographs based on user-defined watershed and rainfall conditions. Built on the widely accepted NRCS DUH methodology, this tool is ideal for simulating runoff from ungaged basins across a range of Annual Exceedance Probabilities (AEPs).

---

✨ Features

• 🔢 Multiple AEPs: Supports 1, 2, 5, 10, 25, 50, 100, 200, 500, and 1000-year events
• 📊 Interactive Visualization: Dynamic, responsive hydrograph plots using Plotly
• 💧 Flexible Units: View flows in cubic feet per second (CFS) or cubic meters per second (m³/s)
• 📁 CSV Export: Save calculated hydrographs for further analysis
• 🧠 Transparent Calculations: Displays all key time parameters
• 💻 Web Interface: Clean, user-friendly Streamlit app

📺 Click the image below to watch 5-min tutorial on how to install and use the NRCS DUH tool:

---

🧪 Methodology

This application applies the NRCS Dimensionless Unit Hydrograph approach, expressing the normalized flow rate ( Q/Q_p ) as a function of normalized time ( t/T_p ), where:

• ($Q_p$): peak runoff rate
• ($T_p$): time to peak from rainfall excess
• ($m$): gamma distribution shape factor (typically 3.7)

The hydrograph formula used is:

$$ \frac{Q}{Q_p} = \left( \frac{t}{T_p} \cdot e^{1 - \frac{t}{T_p}} \right)^m $$

• Time Lag ($t_{lag}$):
  • CN-based: $t_{lag} = 1.362 \times 10^{-3} \cdot \left(\frac{1000}{CN} - 9 \right)^{0.7} \cdot \frac{L^{0.8}}{\sqrt{S_0}}$
  • S-based: $t_{lag} = 1.362 \times 10^{-3} \cdot \left(\frac{S}{25.4} + 1 \right)^{0.7} \cdot \frac{L^{0.8}}{\sqrt{S_0}}$
• Time of Concentration: $t_c = \frac{t_{lag}}{0.6}$
• Rainfall Duration: $t_r = 0.133 \cdot t_c$
• Time to Peak: $T_p = 0.5 \cdot t_r + t_{lag}$

Conditions are validated against: $t_r \leq 0.2 \cdot t_c \quad \textrm{or} \quad t_r \leq 0.3 \cdot T_p$

---

📦 Installation

Option 1: Clone This Repo

git clone https://github.com/mohsennasab/NRCS_DUH.git
cd NRCS_DUH

Option 2: Download ZIP

• Download and extract from GitHub directly

Set Up a Virtual Environment (Recommended)

python -m venv nrcs_duh
# Activate:
# Windows
nrcs_duh\Scripts\activate
# Mac/Linux
source nrcs_duh/bin/activate

# Install dependencies
pip install streamlit==1.41.1 pandas==1.5.3 numpy==1.26.4 plotly==5.15.0

---

▶️ How to Run

Run the app

python run_app.py

Or launch with Streamlit directly

streamlit run streamlit_app.py --server.port=8888

---

🧑‍💻 Usage

1. Choose your calculation method (Curve Number or S-based)
2. Enter watershed parameters:
   • Area (sq mi), Curve Number (CN) or Storage (S), average slope, time interval
3. Input known peak flows for selected AEPs
4. Click "Generate Hydrographs"
5. Explore:
   • 🌊 Hydrograph Plot
   • 📋 Tabular Data (with download)
   • 🧠 Time Parameters

---

📁 Project Structure

File	Description
streamlit_app.py	Main Streamlit interface
nrcs_calculator.py	Core hydrograph generation logic
run_app.py	Launch script
Images/	Contains app logo and graphics
README.md	This file 🚀

---

📚 References

• NRCS Chapter 16 – Hydrographs (PDF)
• NOAA Unit Hydrograph Manual

---

🛠️ Troubleshooting

• Port already in use? The app auto-detects the next available port
• Streamlit not found? Run pip install streamlit==1.41.1
• No browser? Manually visit http://localhost:8888
• Permission denied? Try running with sudo (Linux/macOS) or as admin (Windows)

---

👨‍💻 Author

Created by Mohsen Tahmasebi Nasab, PhD

---

📄 License

Custom Open-Source License

Copyright (c) 2024 Mohsen Tahmasebi Nasab

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the “Software”), to use, copy, and modify the Software for personal, academic, or internal non-commercial purposes, subject to the following conditions:

1. Commercial use, including but not limited to use in paid services, proprietary software, or as part of any commercial product or package, is not permitted without prior written permission from the copyright holder.

2. Redistribution of the Software, in part or in full, whether modified or unmodified, is also not permitted without prior written permission.

3. This copyright notice and license shall be included in all copies or substantial portions of the Software.
