RoboScribe

RoboScribe is a natural language robotics interface that translates commands into humanoid robot motion inside NVIDIA Isaac Sim. You speak or type "walk in a circle of radius 1 meter" — the system parses it, reads it back to you for voice confirmation, executes the motion on a Unitree H1 humanoid, and captures the full joint trajectory at 200Hz for dataset export. Commands can be issued via ElevenLabs STT (speech-to-text) directly from the browser, making the entire interaction hands-free: speak a command, hear the confirmation, say yes, watch the robot move. It also supports visual navigation: say "go to the desk" and an onboard VLM (Qwen3-VL-2B) locates the object from the robot's camera and steers toward it.

System Overview

Three independent processes communicate over WebSocket, with a FastAPI backend acting as the central hub:

┌─────────────────────────────────────────────────────────────────────┐
│                         RoboScribe System                           │
│                                                                     │
│  ┌──────────────┐    WS /ws    ┌──────────────┐    WS /sim         │
│  │  Next.js     │◄────────────►│  FastAPI     │◄──────────────►    │
│  │  Dashboard   │              │  Backend     │   Isaac Sim Ext.   │
│  │  :3000       │              │  :8000       │                    │
│  └──────────────┘              └──────┬───────┘                    │
│                                       │                            │
│                              ┌────────┴────────┐                   │
│                              │                 │                   │
│                         Featherless       Qwen3-VL                 │
│                         LLM API           (local GPU)              │
│                         (parse cmd)       (visual nav)             │
└─────────────────────────────────────────────────────────────────────┘

Components

1. FastAPI Backend (`backend/`)

The backend is the nerve centre. It does not store any view state — it orchestrates the lifecycle of every command through a LangGraph state machine.

Files:

main.py — FastAPI app with two WebSocket endpoints (/ws for the dashboard, /sim for Isaac Sim) and a /vla fast-path for external vision clients. Also holds the global latest_camera_frame cache populated by camera_update messages from Isaac Sim.
langgraph_agent.py — RoboScribeAgent runs one async LangGraph graph per command: parse_command → send_confirmation → await_confirmation → dispatch_to_sim → END. Stores an in-memory list of completed trajectories (agent.trajectories). Calls receive_execution_result() when Isaac Sim reports back.
command_parser.py — Calls the Featherless LLM API (default: deepseek-ai/DeepSeek-V3-0324) with a detailed motion-planner system prompt. Returns one of three command types: single (one velocity step), sequence (up to 24 steps for patterns like figure-8, square, spiral), or navigate (visual grounding). Falls back to regex if the API key is missing.
vision_navigator.py — Wraps Qwen3-VL-2B-Instruct (~4GB VRAM, loaded lazily). locate_object(frame, name) returns a bounding box; compute_nav_command(bbox, depth) returns [vx, vy, wz] velocity. Skipped entirely at import time if torch/CUDA is unavailable.
convex_client.py — HTTP client that POSTs trajectory data to a Convex HTTP Action at CONVEX_SITE_URL. No auth required (public endpoint). Graceful no-op if env var is unset.
n8n_client.py — Sends observability JSON webhooks to N8N_WEBHOOK_URL. Optional; silently skipped if unset. Supports a second webhook (LOW_ACCURACY_ALERT_URL) for low-accuracy execution alerts routed to Discord.
models.py — Pydantic models: ParsedCommand, TrajectoryMetadata, enums for RobotStatus and VoiceState.

Command type breakdown:

Type	Example	Execution
`single`	"walk forward 2 meters"	One `[vx, vy, wz, duration]` step
`sequence`	"walk in a square"	Up to 24 steps executed serially
`navigate`	"go to the desk"	VLM loop: detect → steer → repeat

2. Isaac Sim Extension (`exts/roboscribe.h1.bridge/`)

A self-contained Omniverse extension that loads inside Isaac Sim and runs the Unitree H1 humanoid using H1FlatTerrainPolicy. It connects back to the FastAPI backend over WebSocket and records all joint data during execution.

Files (inside roboscribe_h1_bridge_python/):

extension.py — Extension lifecycle (startup/shutdown), menu registration, physics step subscription. Delegates everything to UIBuilder.
ui_builder.py — Renders the Load / Reset / Run buttons in the Isaac Sim panel. Sets up the World scene and hands off robot logic to RoboScribeH1Scenario.
scenario.py — Core robot logic. Loads the warehouse USD environment + H1 robot. update() is called every physics step (200Hz): applies the current velocity command, records joint state into the trajectory buffer, and captures camera frames at ~5Hz via omni.kit.viewport.utility. Keyboard control (arrow keys / numpad) works alongside WebSocket commands.
roboscribe_bridge.py — WebSocket client running in a daemon thread with exponential-backoff reconnect. Receives execute/stop messages from the backend and pushes joint_update (20Hz), execution_progress, execution_complete (full trajectory), and camera_update (JPEG frames) back.
global_variables.py — Shared mutable state accessed across extension modules.

H1 robot facts:

19 DOF joints, controlled by H1FlatTerrainPolicy
Velocity input: [vx, vy, wz] — forward, lateral, yaw (range −1.0 to 1.0)
Nominal walking speed: 0.75 m/s · Turning rate: 0.75 rad/s
Physics at 200Hz · Rendering at 25Hz · Camera capture at ~5Hz
Joint torques are NOT exposed by the policy (always 0.0 Nm)

3. Next.js Dashboard (`frontend/`)

A React 19 / Next.js 16 / Tailwind 4 single-page app. All command flow is WebSocket-only — there are no REST calls for commands or confirmations.

Key files:

lib/api-client.ts — robotWebSocket singleton (auto-reconnects). robotApi.sendCommand() and robotApi.confirmCommand() both send WS messages. Handles LAN IP substitution so the dashboard works when opened from a different host than localhost.
context/robot-context.tsx — RobotProvider is the single source of truth. Handles all 10+ incoming WS message types and updates state: pendingCommand, robotStatus, executionProgress, trajectories, stats, navigationState. Also wires the Convex recordings.save mutation via saveRecordingRef.
hooks/use-robot-state.ts — Thin hook that reads from context. Import this in components, not the context directly.
components/command-panel.tsx — The main user interaction surface: voice input via ElevenLabs STT or keyboard text → confirmation dialog with ElevenLabs TTS (falls back to browser speechSynthesis) → execution progress bar. The full interaction loop is hands-free: speak → hear confirmation → say yes → robot moves.
components/dataset-panel.tsx — Dataset recording controls and trajectory table.
components/realtime-chart.tsx / joint-monitor.tsx / joint-data-stream.tsx — Live joint telemetry display (positions + velocities in degrees/deg-s, streamed from 20Hz joint_update messages).
components/stats-bar.tsx — Live stats from stats_update WS messages (total trajectories, success rate, timesteps, unique commands).

Dashboard tabs: Monitor (default — command + dataset panels) · Control · Chart · Datasets · Settings

Convex integration:

convex/schema.ts — Two tables: trajectories (written by backend) and recordings (written by frontend).
convex/trajectories.ts / recordings.ts — Convex functions (save, getAll, getStats).

4. Command Parser & Motion Planner

command_parser.py is the intelligence layer that converts plain English to robot motion. It uses a richly specified system prompt covering:

Planar motion geometry (arc radius = vx/wz, circular paths, straight lines)
14 named motion concepts: STRAIGHT, BACKWARD, SPIN, STRAFE, CIRCLE, FIGURE-8, SQUARE, ZIGZAG, PATROL, SPIRAL OUT/IN, ACCELERATION, DECELERATION, DRUNK/WOBBLE
Speed vocabulary: "slow/sneak" → 0.2–0.4 m/s · "normal/walk" → 0.75 · "fast/run" → 0.85–1.0
Multi-step sequence generation with total_duration validation
Visual navigation intent detection → navigate type with target noun

The regex fallback handles the 6 most common cases (forward, backward, left, right, stop, navigate-to) without any API dependency.

5. Visual Navigation (VLA)

vision_navigator.py enables the robot to navigate to real objects visible in its camera:

Isaac Sim streams JPEG camera frames as camera_update WS messages at ~5Hz
Backend caches the latest frame in latest_camera_frame
On a navigate command, the LangGraph agent enters a vision loop: locate_object() → compute_nav_command() → dispatch velocity to sim → repeat until arrived or timeout
locate_object() runs Qwen3-VL-2B with a bounding-box grounding prompt. Coordinates are in 0–1000 normalised range, then scaled to image dimensions.
compute_nav_command() translates the bbox centre offset into [vx, vy, wz]
Debug frames are saved to logs/ for inspection

The /vla WebSocket endpoint provides a fast-path for external navigation clients that bypass LangGraph entirely.

6. Data Flow & Persistence

Per-command lifecycle:

User types command
    → [WS] → Backend: parse (LLM/regex)
    → [WS] → Dashboard: awaiting_confirmation + TTS
    → [WS] → Backend: user confirms yes/no
    → [WS] → Isaac Sim: execute {vx,vy,wz,duration}
    → Isaac Sim executes + records 200Hz trajectory
    → [WS] → Backend: execution_complete {full_trajectory}
    → Backend: store in-memory + write to Convex (if configured)
    → [WS] → Dashboard: trajectory_saved + stats_update

Persistence layers:

Store	What	Status
`agent.trajectories`	Python in-memory list	Always active, lost on restart
Convex `trajectories` table	Backend-written via HTTP action	Active if `CONVEX_SITE_URL` set
Convex `recordings` table	Frontend-written via mutation	Wired, called from `saveDataset()`
Frontend React state	Session-only trajectories + datasets	Lost on page refresh

Known gaps: Recording duration timer and joint frame capture during manual recording are not implemented — startRecording() creates metadata-only Dataset shells.

7. Trajectory Data Schema

Every executed command produces a synchronized trajectory recorded at 200Hz. Each timestep contains:

TIMESTAMP 0.000s
  joint_positions    [19 values, rad]       — full H1 joint state
  joint_velocities   [19 values, rad/s]     — joint velocity
  base_position      [x, y, z]              — world-frame position
  base_orientation   [qx, qy, qz, qw]       — world-frame quaternion
  base_transform     4×4 TF matrix          — complete SE(3) transform
  velocity_command   [vx, vy, wz]           — command applied this step
  language_label     "walk forward 1m"      — NL instruction (per trajectory)
  outcome            success / fail          — execution result
  accuracy           0–100%                 — distance achieved vs. commanded

TIMESTAMP 0.005s  (repeats at 200Hz for the full duration)
  ...

The base_transform (SE(3) TF matrix) is collected alongside the quaternion, giving full 6-DoF pose in a format directly consumable by robot learning frameworks.

Sample Convex database record:

Same data visualised in Foxglove Studio (joint states + base pose over time):

n8n Observability Workflow

The backend posts JSON events to an n8n webhook after each command execution. The n8n workflow routes alerts to different Discord channels based on event severity:

graph LR
    WH[Webhook<br/>POST] --> SW{Switch<br/>mode: Rules}
    SW -->|0 - info| D0[Discord<br/>Send a message]
    SW -->|1 - warning| D1[Discord<br/>Send a message1]
    SW -->|2 - error / low accuracy| D2[Discord<br/>Send a message2]

Rule mapping (configured in the Switch node):

Output 0 — general observability events (command executed, trajectory saved)
Output 1 — warnings (regex fallback used, VLM degraded)
Output 2 — errors / low-accuracy executions (triggers LOW_ACCURACY_ALERT_URL)

Set N8N_WEBHOOK_URL in .env to activate. All three outputs post to the RoboScribe Discord channel via the built-in Discord node (send: message).

Sample alerts in Discord — each command posts its type, duration, command ID, and execution result including accuracy, distance achieved, and heading drift:

WebSocket Protocol

All messages are flat JSON with a type field (no envelope wrapper).

Dashboard (/ws) receives:

Message	Trigger
`command_parsed`	LLM parsed the command
`awaiting_confirmation`	Ready for yes/no
`execution_started`	Isaac Sim acknowledged
`execution_progress`	Steps completed (0–N)
`joint_update`	20Hz telemetry from Isaac Sim
`trajectory_saved`	Execution complete + stored
`stats_update`	Aggregate stats refreshed
`result_text`	Human-readable outcome
`status`	Robot idle/executing/error

Isaac Sim (/sim) receives: execute, stop

VLA Model Compatibility

RoboScribe is designed from the ground up to produce training data for Vision-Language-Action models. The trajectory schema it collects today is the exact input format expected by leading VLA frameworks:

Model	Organisation	Input modalities	RoboScribe provides
GR00T N1 / N1.6	NVIDIA	Language + proprioception + vision	✅ joints · pose · command · (🔜 camera)
pi0 / pi0.5	Physical Intelligence	Language + proprioception + vision	✅ joints · pose · command · (🔜 camera)
OpenVLA	Stanford	Language + vision + actions	✅ command labels · (🔜 camera frames)
Isaac Lab RL policies	NVIDIA	Proprioception + actions	✅ full joint state at 200Hz

What RoboScribe generates per session:

joint_positions    [19 values, rad]      200Hz  ✅
joint_velocities   [19 values, rad/s]    200Hz  ✅
base_position      [x, y, z]             200Hz  ✅
base_orientation   [qx, qy, qz, qw]      200Hz  ✅
base_transform     SE(3) TF matrix        200Hz  ✅
velocity_command   [vx, vy, wz]          200Hz  ✅
language_label     "walk forward 1m"     per trajectory  ✅
outcome            success / fail         per trajectory  ✅
camera_frame       [640×480 RGB]         synced at 200Hz  🔜

Policy validation layer: The Qwen3-VL VLM sees the same scene as the robot and independently generates expected velocity commands. RoboScribe compares these against what H1FlatTerrainPolicy actually executed — flagging silent divergences that unit tests would miss.

Roadmap — Full Multimodal Sync

The current build collects complete proprioceptive + language data. The next step closes the camera sync gap:

CURRENT                              NEXT
─────────────────────────────────    ─────────────────────────────────────
✅ NL → velocity command             🔜 camera_frame [640×480 RGB] synced
✅ joint positions + velocities           at the same 200Hz timestamp
   at 200Hz
✅ base pose (position + quaternion)  timestep_0042: {
✅ SE(3) TF transform                   t: 0.210s,
✅ command label per timestep           joint_positions: [...19...],
✅ success / fail outcome               joint_velocities: [...19...],
✅ VLM validation (Qwen3-VL)            base_transform: {pos, quat, tf},
                                        camera_frame: [640×480 RGB],  ← THIS
                                        velocity_command: [0.75, 0.0, 0.0],
                                        language_instruction: "walk forward"
                                      }

With camera frames synchronized, every RoboScribe session becomes a ready-to-train multimodal robot dataset for GR00T N1.6, pi0, and OpenVLA — with zero additional annotation required.

LangGraph State Machine

The backend orchestrates every command through this graph. The navigate branch drives the VLM vision loop; search_and_retry handles the case where the target object isn't visible yet.

---
config:
  flowchart:
    curve: linear
---
graph TD;
    __start__([<p>__start__</p>]):::first
    parse_command(parse_command)
    send_confirmation(send_confirmation)
    await_confirmation(await_confirmation)
    dispatch_to_sim(dispatch_to_sim)
    dispatch_navigation(dispatch_navigation)
    search_and_retry(search_and_retry)
    __end__([<p>__end__</p>]):::last
    __start__ --> parse_command;
    await_confirmation -. &nbsp;reject&nbsp; .-> __end__;
    await_confirmation -. &nbsp;navigate&nbsp; .-> dispatch_navigation;
    await_confirmation -. &nbsp;dispatch&nbsp; .-> dispatch_to_sim;
    dispatch_navigation -.-> __end__;
    dispatch_navigation -. &nbsp;search&nbsp; .-> search_and_retry;
    parse_command --> send_confirmation;
    send_confirmation --> await_confirmation;
    dispatch_to_sim --> __end__;
    search_and_retry --> __end__;
    classDef default fill:#f2f0ff,line-height:1.2
    classDef first fill-opacity:0
    classDef last fill:#bfb6fc

Concept Graph

                            ┌─────────────────────────────────────────┐
                            │           USER (Browser)                │
                            │  "walk in a square"                     │
                            └────────────────┬────────────────────────┘
                                             │ WebSocket /ws
                                             ▼
┌────────────────────────────────────────────────────────────────────────────┐
│                         FastAPI Backend (:8000)                            │
│                                                                            │
│  ┌──────────────────────────────────────────────────────────────────────┐  │
│  │                    LangGraph State Machine                           │  │
│  │                                                                      │  │
│  │  parse_command ──► send_confirmation ──► await_confirmation          │  │
│  │       │                                        │                    │  │
│  │       ▼                                        ▼                    │  │
│  │  [Featherless LLM]               confirmed? ──yes──► dispatch_to_sim │  │
│  │  or regex fallback                             │                    │  │
│  │                                               no                   │  │
│  │                                                │                    │  │
│  │                                              END                   │  │
│  └──────────────────────────────────────────────────────────────────────┘  │
│                                                                            │
│  ┌─────────────────────┐     ┌──────────────────────────────────────────┐  │
│  │  vision_navigator   │     │  receive_execution_result()              │  │
│  │  Qwen3-VL-2B        │     │  → agent.trajectories (in-memory)        │  │
│  │  locate_object()    │     │  → convex_client.py → Convex DB          │  │
│  │  compute_nav_cmd()  │     │  → n8n_client.py → webhook               │  │
│  └─────────────────────┘     └──────────────────────────────────────────┘  │
└──────────────┬─────────────────────────────────────┬───────────────────────┘
               │ WebSocket /ws                        │ WebSocket /sim
               ▼                                      ▼
┌──────────────────────────┐         ┌────────────────────────────────────────┐
│   Next.js Dashboard      │         │     Isaac Sim Extension                │
│   (:3000)                │         │     roboscribe.h1.bridge               │
│                          │         │                                        │
│  RobotProvider           │         │  H1FlatTerrainPolicy                   │
│  ├─ command-panel.tsx    │         │  ├─ scenario.py (200Hz physics)        │
│  │  └─ ElevenLabs TTS    │         │  │  ├─ apply [vx,vy,wz] command        │
│  ├─ stats-bar.tsx        │         │  │  ├─ record joint positions/vel      │
│  ├─ joint-monitor.tsx    │◄────────│  │  └─ capture camera @ 5Hz           │
│  ├─ realtime-chart.tsx   │20Hz     │  ├─ roboscribe_bridge.py (WS thread)   │
│  ├─ trajectory-table.tsx │joint    │  │  ├─ send joint_update (20Hz)        │
│  └─ dataset-panel.tsx    │updates  │  │  ├─ send camera_update (~5Hz)       │
│                          │         │  │  └─ send execution_complete         │
│  Convex (frontend)       │         │  └─ keyboard control (arrow/numpad)    │
│  └─ recordings.save      │         └────────────────────────────────────────┘
└──────────┬───────────────┘
           │
           ▼
┌──────────────────────┐
│   Convex Database    │
│   trajectories       │◄── backend writes (convex_client.py)
│   recordings         │◄── frontend writes (useMutation)
└──────────────────────┘

Running the System

Prerequisites

Python 3.10+ with pip install -r requirements.txt
Node.js 20+ with npm
NVIDIA Isaac Sim 5.1 with isaaclab conda environment
(Optional) CUDA GPU for Qwen3-VL visual navigation (~4GB VRAM)

Environment Variables (`.env` at repo root)

# LLM command parsing (falls back to regex if unset)
FEATHERLESS_API_KEY=...
FEATHERLESS_MODEL=deepseek-ai/DeepSeek-V3-0324

# Convex persistence (in-memory fallback if unset)
CONVEX_SITE_URL=https://your-deployment.convex.site

# Observability webhooks (skipped if unset)
N8N_WEBHOOK_URL=...
LOW_ACCURACY_ALERT_URL=...   # Discord/Slack/generic webhook

# ElevenLabs STT (speech-to-text input) + TTS (voice confirmation output)
# Falls back to browser speechSynthesis for TTS if unset
NEXT_PUBLIC_ELEVENLABS_API_KEY=...
NEXT_PUBLIC_ELEVENLABS_VOICE_ID=...

# Frontend WebSocket URL (defaults to ws://localhost:8000/ws)
NEXT_PUBLIC_ROBOT_WS_URL=ws://localhost:8000/ws

Start Backend

cd backend
set -a && source ../.env && set +a
uvicorn main:app --host 0.0.0.0 --port 8000 --reload

Start Frontend

cd frontend
npm install
npm run dev       # http://localhost:3000
npm run build     # production build
npm run lint
npx tsc --noEmit  # type check

Start Convex (run alongside frontend)

cd frontend
npx convex dev    # syncs schema + functions, watches for changes

Start Isaac Sim

conda activate isaaclab
isaacsim --ext-folder /home/omar/Cursor_Hackathon/Roboscribe/exts --enable roboscribe.h1.bridge

Test Without Isaac Sim (websocat)

websocat ws://localhost:8000/ws
# → {"type": "command", "text": "walk forward 1 meter"}
# ← {"type": "awaiting_confirmation", "command_id": "abc123", ...}
# → {"type": "confirmation", "command_id": "abc123", "confirmed": true}

cd backend
python test_ws.py "walk forward 1 meter"   # interactive CLI client

Project Structure

Roboscribe/
├── backend/
│   ├── main.py                  # FastAPI app, WS endpoints (/ws /sim /vla)
│   ├── langgraph_agent.py       # LangGraph state machine + trajectory store
│   ├── command_parser.py        # Featherless LLM + regex fallback
│   ├── vision_navigator.py      # Qwen3-VL-2B visual navigation
│   ├── convex_client.py         # Optional Convex HTTP action client
│   ├── n8n_client.py            # Optional observability webhooks
│   └── models.py                # Pydantic models
├── frontend/
│   ├── app/                     # Next.js app router (layout + page)
│   ├── components/              # React UI components
│   ├── context/robot-context.tsx# Central WS state manager
│   ├── lib/api-client.ts        # WebSocket singleton + robotApi
│   ├── convex/                  # Convex schema + functions
│   └── hooks/use-robot-state.ts # Context consumer hook
├── exts/roboscribe.h1.bridge/
│   └── roboscribe_h1_bridge_python/
│       ├── extension.py         # Omniverse extension lifecycle
│       ├── ui_builder.py        # Isaac Sim panel UI
│       ├── scenario.py          # H1 robot logic + camera capture
│       └── roboscribe_bridge.py # WS client thread
├── ACTION_PLAN.md               # Prioritised implementation backlog
├── requirements.txt             # Python dependencies
└── .env                         # All environment variables (not committed)

Name		Name	Last commit message	Last commit date
Latest commit History 5 Commits
backend		backend
exts/roboscribe.h1.bridge		exts/roboscribe.h1.bridge
frontend		frontend
.gitignore		.gitignore
ConvexDatabase.png		ConvexDatabase.png
FoxgloveDataView.png		FoxgloveDataView.png
INTEGRATION_PLAN.md		INTEGRATION_PLAN.md
README.md		README.md
SampleDiscordMessages.png		SampleDiscordMessages.png
modelsKeys.md		modelsKeys.md
n8nArch.png		n8nArch.png
requirements.txt		requirements.txt
roboscribe_bridge_agent.md		roboscribe_bridge_agent.md
test_camera.py		test_camera.py
test_featherless.sh		test_featherless.sh

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Repository files navigation

RoboScribe

System Overview

Components

1. FastAPI Backend (`backend/`)

2. Isaac Sim Extension (`exts/roboscribe.h1.bridge/`)

3. Next.js Dashboard (`frontend/`)

4. Command Parser & Motion Planner

5. Visual Navigation (VLA)

6. Data Flow & Persistence

7. Trajectory Data Schema

n8n Observability Workflow

WebSocket Protocol

VLA Model Compatibility

Roadmap — Full Multimodal Sync

LangGraph State Machine

Concept Graph

Running the System

Prerequisites

Environment Variables (`.env` at repo root)

Start Backend

Start Frontend

Start Convex (run alongside frontend)

Start Isaac Sim

Test Without Isaac Sim (websocat)

Project Structure

About

Uh oh!

Releases

Packages

Uh oh!

Contributors

Uh oh!

Languages

Folders and files

Latest commit

History

Repository files navigation

RoboScribe

System Overview

Components

1. FastAPI Backend (backend/)

2. Isaac Sim Extension (exts/roboscribe.h1.bridge/)

3. Next.js Dashboard (frontend/)

4. Command Parser & Motion Planner

5. Visual Navigation (VLA)

6. Data Flow & Persistence

7. Trajectory Data Schema

n8n Observability Workflow

WebSocket Protocol

VLA Model Compatibility

Roadmap — Full Multimodal Sync

LangGraph State Machine

Concept Graph

Running the System

Prerequisites

Environment Variables (.env at repo root)

Start Backend

Start Frontend

Start Convex (run alongside frontend)

Start Isaac Sim

Test Without Isaac Sim (websocat)

Project Structure

About

Resources

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

1. FastAPI Backend (`backend/`)

2. Isaac Sim Extension (`exts/roboscribe.h1.bridge/`)

3. Next.js Dashboard (`frontend/`)

Environment Variables (`.env` at repo root)

Packages
