Git Folder Dashboard

English | 中文

A locally running dashboard for managing Git repositories.

Given a parent directory, it automatically scans first-level subdirectories for Git repositories, and provides a unified web interface to view their status, file changes, and perform common operations.

Positioning: A multi-repository overview tool, not an IDE replacement.

---

Overview

Suitable for directory structures like:

~/Code
  project-a
  project-b
  project-c
  notes

Features:

• Scan directories and detect Git repositories

• Display current branch and sync status (ahead / behind)

• Show working tree changes (staged / unstaged / untracked)

• Export the current working tree mismatch state as a snapshot zip

• Import a snapshot zip and forcibly apply it to the current working tree

• View file diffs or contents

• Execute common operations:

  • fetch / pull / push
  • commit / checkout

• File-level operations:

  • stage / unstage
  • discard changes
  • delete / ignore untracked files

Runtime compatibility:

• Supports Python 3.6
• Suitable for Ubuntu 18.04 environments
• Dependency versions are pinned intentionally because newer ASGI stacks are not reliable in this Python 3.6 target
• The tested compatibility set is Flask 2.0.3 + Werkzeug 2.0.3
• Supports mounting under a subpath such as /git via --base-path /git

---

Architecture

The overall design is intentionally simple:

• Backend (Python / Flask): executes Git commands, accesses the filesystem, returns JSON
• Frontend (plain HTML / JS): renders UI, manages state, handles interactions
• In-memory store: maintains repo_id -> path mapping

Data flow:

Browser
  ↓
static (HTML / JS)
  ↓
Flask (app.py)
  ↓
git_service.py
  ↓
Git + filesystem

---

Project Structure

git-folder-dashboard/
  app.py
  git_service.py
  snapshot_service.py
  repo_store.py
  static/
    index.html
    style.css
    message.js
    app.js

Responsibilities:

• app.py

  • Route definitions
  • Parameter validation
  • Calls service layer
  • Returns responses

• git_service.py

  • All Git operations
  • Status parsing
  • File operations

• snapshot_service.py

  • Build working tree snapshots
  • Export mismatch state as zip
  • Import snapshot and overwrite files directly

• repo_store.py

  • In-memory mapping: repo_id -> path

• static/

  • Frontend UI and interaction logic

---

Backend Responsibilities

Handles only three types of logic:

1. Receive requests
2. Execute Git / file operations
3. Return JSON

Does NOT include:

• Template rendering
• Persistent storage
• Frontend state management

---

Core Modules

git_service.py

Core business logic.

Git execution entry

run_git(repo_path, args)

Executes all Git commands in a unified way and returns structured results.

---

Repository status

get_repo_status(repo_id, repo_path)

Returns:

• Current branch
• Branch list (local / remote)
• File changes (staged / unstaged / untracked)
• Dirty status
• Ahead / behind
• Repository state (clean / dirty / diverged, etc.)

---

File operations

Unified entry:

apply_file_action()

Supports:

• stage → git add
• unstage → git restore --staged
• discard → git restore
• delete → remove file
• ignore → write to .git/info/exclude

---

snapshot_service.py

Implements working tree snapshot export / import.

Principle:

• Does not use git apply as the primary restore path
• Exports the current working tree result, not a patch stream
• Restores by direct file overwrite / creation / deletion

Snapshot zip contents:

• manifest.json
• files/*

Manifest records:

• relative path
• entry kind (modified / added / deleted)
• scope (staged / unstaged / untracked)
• payload file location inside the zip when content is required

Current behavior boundary:

• Restores the final working tree file state
• Supports modified / added / deleted files
• Supports nested newly created files
• Supports binary files because file contents are stored directly in the zip
• Does not attempt to recreate the exact Git index staging layout
• Does not rely on patch context matching

---

repo_store.py

Maintains repository mapping:

repo_id → local path

Characteristics:

• In-memory only
• No persistence
• Requires re-scan after restart

---

app.py

Handles request dispatching:

request → route → service → refresh → response

Key flow:

• Get path from repo_id
• Execute Git operation
• Refresh repository state
• Return latest data

Startup notes:

• Uses Flask's synchronous local server instead of an ASGI stack
• Avoids uvicorn, h11, and asyncio compatibility issues on Python 3.6
• Supports subpath hosting by stripping a configured URL prefix before routing

Example:

python app.py --host 0.0.0.0 --port 8765 --base-path /git

Then the app is served under:

https://example.com/git/

---

Frontend

No framework, fully state-driven rendering.

Core state:

state = {
  repos,
  activeRepoId,
  theme,
  preview,
  ...
}

Responsibilities:

• Render repository list and details
• Manage UI state (tabs / expand / theme)
• Manage language switching (English / Chinese)
• Call APIs
• Re-render based on results

---

File Tree Rendering

Backend returns flat paths:

a/b/c.txt

Frontend:

1. Splits path
2. Builds tree
3. Renders nodes

Advantages:

• Keeps backend simple
• Flexible UI

---

Typical Workflow

Example: staging a file

Click button
  ↓
Frontend POST /files/action
  ↓
app.py route
  ↓
apply_file_action()
  ↓
git add
  ↓
refresh_repo()
  ↓
get_repo_status()
  ↓
Return result
  ↓
Frontend re-render

---

Configuration

Configured via command-line arguments. No .env required.

---

Run

Common commands:

Scenario	Command
Start with defaults	python app.py
Custom host / port / default path	python app.py --host 127.0.0.1 --port 8080 --default-path ~/Code --no-browser=true
Mount under a subpath	python app.py --host 0.0.0.0 --port 8765 --base-path /git

Arguments:

Argument	Description	Default
--host	Bind address	127.0.0.1
--port	Port	8765
--default-path	Default workspace path	""
--base-path	URL prefix for subpath hosting, such as /git	""
--no-browser	Disable auto browser open, supports true/false	false

Aliases:

Alias	Equivalent
--defaut-path	--default-path
--no-brower	--no-browser

Default URL:

http://127.0.0.1:8765

---

Build

pip install -r requirements.txt
pyinstaller --onefile --name git-folder-dashboard --add-data "static:static" app.py

Windows:

pip install -r requirements.txt
pyinstaller --onefile --name git-folder-dashboard --add-data "static;static" app.py

Output:

dist/git-folder-dashboard

Example:

./dist/git-folder-dashboard --host 127.0.0.1 --port 8080 --default-path ~/Code --base-path /git --no-browser=true

---

API

Config

• GET /api/config

Workspace

• POST /api/select-folder
• POST /api/scan

Repo Actions

• POST /api/repos/{id}/refresh
• POST /api/repos/{id}/fetch
• POST /api/repos/{id}/pull
• POST /api/repos/{id}/push
• POST /api/repos/{id}/commit
• POST /api/repos/{id}/checkout
• POST /api/repos/{id}/discard

File Actions

• POST /api/repos/{id}/files/preview
• POST /api/repos/{id}/files/action
• POST /api/repos/{id}/files/bulk-action

---

Core Call Chain

Browser request
  → app.py route
    → require_repo()
    → git_service.*()
    → refresh_repo()
      → get_repo_status()
    → return JSON

Responsibilities:

• app.py: routing & orchestration
• git_service.py: execution
• get_repo_status(): view data generation

---

Scan Flow

POST /api/scan
  → app.py.scan()
    → repo_store.clear()
    → repo_store.add()
    → get_repo_status()
    → repo_store.update()

Output:

• Repository list
• Non-Git directories

---

File Operation Flow

POST /files/action
  → app.py.file_action()
    → apply_file_action()
      → stage_file()
      → unstage_file()
      → discard_file()
      → ...
    → refresh_repo()
      → get_repo_status()

Key points:

• All file operations go through apply_file_action()
• State is always refreshed afterward

---

Preview Flow

POST /files/preview
  → app.py.file_preview()
    → preview_repo_file()
      → git diff
      → git diff --cached
      → read file

Behavior:

• staged → git diff --cached
• unstaged → git diff
• untracked → read file directly

---

Repo Operation Flow

POST /repos/{id}/push
  → app.py.repo_action()
    → run_git(["push"])
    → refresh_repo()

Others follow the same pattern:

fetch / pull / checkout / commit
  → git_service
  → refresh_repo()

---

Frontend Call Flow

scan()
previewFile()
runRepoAction()
runFileAction()
  → requestJson()
    → call backend API
  → update state
  → render()

Render breakdown:

render()
  → renderTabs()
  → renderSidebar()
  → renderRepoDetail()
  → renderNonGit()

---

One Complete Example

Click "Stage file"
  → runFileAction()
  → POST /files/action
  → apply_file_action()
  → git add
  → refresh_repo()
  → get_repo_status()
  → return state
  → render()

---

Key Layers

Orchestration (app.py)

require_repo()
refresh_repo()
API routes

---

Core Logic (git_service.py)

run_git()
get_repo_status()
commit_repo()
checkout_repo()
discard_repo_changes()

---

File Operations

apply_file_action()
apply_bulk_file_action()

stage_file()
unstage_file()
discard_file()
delete_untracked_file()
ignore_untracked_file()

---

Status Parsing

parse_porcelain_line()
normalize_status()
build_file_entry()

---

One-line Summary

app.py → orchestration
git_service.py → execution
get_repo_status() → data generation
frontend → rendering

---

Repo Status

• clean
• dirty
• ahead
• behind
• diverged
• no_remote
• error

---

Limitations

• Only scans first-level subdirectories
• No persistence
• Commit uses git add .
• No permission control (local use only)

---

Suggested Reading Order

• Entry: app.py
• Core: git_service.py
• Mapping: repo_store.py
• Frontend: static/app.js
