ZeroRange

Flipper Zero Training System
Practice. Master. Repeat.

A hands-on training platform to master Flipper Zero capabilities through gamified challenges.
Built on Raspberry Pi with an interactive LCD interface.

▶ Watch on YouTube

📟 LCD Interface Preview

┌────────────────────────────────────┐
│  ╔════════════════════════════╗    │
│  ║ >iButton         25/120   ║    │
│  ║ U/D SEL=Go L=Bk           ║    │
│  ╚════════════════════════════╝    │
│                                    │
│      [▲]                           │
│  [◄] [●] [►]                       │
│      [▼]                           │
└────────────────────────────────────┘

Navigate through challenges using the 5-button interface:

▲ UP / ▼ DOWN - Navigate menus
● SELECT - Confirm selection
◄ LEFT - Go back

Challenges

Currently Available

Module	Challenges	Points	Status
iButton	Touch & Read, Clone, Emulate	30 pts	Available
NFC	Detect, Clone, MIFARE Attack	30 pts	Available
RFID	Detect, Clone, Simulate	30 pts	Available
SubGHZ	Detect Signal, Record & Replay, Signal Analysis	30 pts	Available

Total: 120 points across 12 challenges

Coming Soon

Module	Description	Status
IR	Infrared signal challenges	In Development

Hardware Requirements

Raspberry Pi 5              Components
──────────────              ──────────
GPIO 2 (SDA)  ─────────────► Adafruit LCD (I2C)
GPIO 3 (SCL)  ─────────────►
5V / GND      ─────────────►

USB Port 1    ─────────────► iButton USB Reader (HID)
USB Port 2    ─────────────► Proxmark3 (NFC/RFID)
USB Port 3    ─────────────► HackRF One (SubGHZ)

Components:

Raspberry Pi 5 (or Pi 4)
Adafruit RGB LCD Shield 16x2
iButton USB Reader (HID keyboard emulation)
Proxmark3 (for NFC/RFID challenges)
HackRF One (for SubGHZ challenges)
Flipper Zero (your training tool)

🛒 Shopping List

Affiliate Disclaimer: As an Amazon and AliExpress Associate, I earn from qualifying purchases. You will pay the same price, but I might earn a small commission — this helps finance the gear and support the development of ZeroRange. Thank you!

Component	Amazon	AliExpress
Raspberry Pi 5 (4GB)	Buy on Amazon	—
Adafruit i2c 16x2 RGB LCD Pi Plate	Buy on Amazon	—
Proxmark3	Buy on Amazon	Buy on AliExpress
HackRF One	Buy on Amazon	—
HackRF + Porta Pack	—	Buy on AliExpress
iButton USB Reader	—	Buy on AliExpress

Quick Start

On the Raspberry Pi

# Clone the repository
git clone https://github.com/samxplogs/ZeroRange.git
cd ZeroRange

# Install system dependencies
sudo apt-get update
sudo apt-get install -y python3-pip python3-smbus python3-evdev i2c-tools

# Install Python dependencies
pip3 install -r requirements.txt

# Run ZeroRange
sudo python3 zerorange.py

sudo is required for hardware access (I2C, USB HID, Proxmark3).

Auto-start as a service

sudo bash install_service.sh

This installs a systemd service that automatically starts ZeroRange on boot, including the web interface (port 8000) and LCD API (port 5000).

WiFi Hotspot (optional)

Make ZeroRange fully portable — no existing network required:

sudo bash setup_hotspot.sh
sudo reboot

After reboot, connect to the ZeroRange WiFi network. A captive portal redirects you to the web interface automatically.

Web Interface

Once running, access the web interface at:

http://<RASPBERRY_PI_IP>:8000

The Pi gets its IP via DHCP. Run hostname -I on the Pi to find it. In hotspot mode, the IP is 10.0.0.1.

For detailed installation instructions, see INSTALLATION.md.

Challenge Examples

iButton - Touch & Read

╔════════════════════════════╗
║ Challenge 1               ║
║ Touch & Read              ║
╚════════════════════════════╝
         ↓
╔════════════════════════════╗
║ Waiting for key...        ║
║ Touch to reader           ║
╚════════════════════════════╝
         ↓
╔════════════════════════════╗
║ SUCCESS! +10pts           ║
║ Challenge Done!           ║
╚════════════════════════════╝

NFC - Detect Card

╔════════════════════════════╗
║ NFC Challenge 1           ║
║ Detect any card           ║
╚════════════════════════════╝
         ↓
╔════════════════════════════╗
║ Scanning...               ║
║ Place card on PM3         ║
╚════════════════════════════╝
         ↓
╔════════════════════════════╗
║ FOUND: MIFARE 1K          ║
║ UID: 04:A3:F5:B2          ║
╚════════════════════════════╝

SubGHZ - Record & Replay

╔════════════════════════════╗
║ SubGHz Ch2 [1/2]          ║
║ Press TX button           ║
╚════════════════════════════╝
         ↓
╔════════════════════════════╗
║ Signal captured!          ║
║ Strength: -45dBm          ║
╚════════════════════════════╝
         ↓
╔════════════════════════════╗
║ SOLVED! +10pts            ║
║ Signal replayed!          ║
╚════════════════════════════╝

Features

Gamified Learning - CTF-style challenges with points and progression
Real Hardware - Practice on actual RFID/NFC/iButton systems
Score Tracking - SQLite database tracks your progress
Auto-start - Systemd service for standalone operation
WiFi Hotspot - Connect directly to ZeroRange without network

Project Structure

ZeroRange/
├── zerorange.py          # Main application
├── lcd_manager.py        # LCD display control
├── database.py           # Score persistence
├── config.json           # Configuration
│
├── ibutton_handler.py    # iButton challenge logic
├── nfc_handler.py        # NFC challenges (Proxmark3)
├── rfid_handler.py       # RFID challenges (Proxmark3)
├── proxmark_handler.py   # Proxmark3 interface
├── subghz_handler.py     # SubGHZ challenges (HackRF)
├── hackrf_handler.py     # HackRF One interface
│
├── SUBGHZ_INTEGRATION.md # SubGHZ setup guide
└── docs/                 # Web documentation

Legal Notice

ZeroRange is designed for educational purposes only in a controlled environment.

Only practice on hardware you own or have explicit permission to test. Never use these skills on systems without authorization.

License

This project is licensed under CC BY-NC-SA 4.0 (Creative Commons Attribution-NonCommercial-ShareAlike 4.0).

Attribution - You must give appropriate credit
NonCommercial - No commercial use
ShareAlike - Derivatives must use the same license

See LICENSE for details.

Contributing

Contributions welcome! Please:

Fork the repository
Create a feature branch
Test on real hardware
Submit a pull request

Credits

Created by samxplogs

GitHub: @samxplogs
YouTube: @samxplogs

Built for the Flipper Zero community.

Practice. Master. Repeat.
