ClinSight

Hierarchical Multimodal Clinical Intelligence for Emergency Decision Support

🌐 Live Demo • 🤗 Hugging Face • 📖 Technical Walkthrough • 🎥 Demo Video

🎥 Judge Note: The live demo below shows pre-computed results from our 50-case benchmark run (AMD MI300X credit exhausted). The submitted video demonstrates live inference with zero caching on AMD MI300X — see Technical Walkthrough for full evidence.

---

🚨 The Problem

Every year, 795,000 Americans are harmed by delayed diagnosis in emergency departments.

Metric	Current Reality
Preliminary X-ray review	30–60 minutes
Official radiology report	1–3 hours
Rural teleradiology	4–24 hours

For a patient with a collapsed lung, that's a lifetime.

Existing solutions (Aidoc, Qure.ai, BraveCX) are proprietary, NVIDIA-locked, and image-only. None fuse imaging + lab values + patient history in a single open-source inference pipeline. None run on AMD hardware. None use a hierarchical agentic safety layer.

---

🧠 What We Built

ClinSight is an open-source, multi-agent clinical decision support system that reads chest X-rays, lab values, vitals, and triage notes simultaneously — then reasons across all modalities through a compiled LangGraph pipeline running entirely on AMD Instinct MI300X.

Architecture: 5 Parent Agents → 7 Subagents → 12 Reasoning Nodes

Agent	Role	Subagents
🔵 Coordinator	Input validation, quality gates, pediatric safety	Image Quality Gate, Pediatric Gate
🩺 Radiologist	Image analysis, pathology detection, attention regions	Image Prep, Pathology Analyzer
🧪 Lab Analyst	Critical value detection, pattern correlation	Critical Value Detector, Pattern Correlator
🛡️ Safety	Contradiction checking, hallucination guard, bias audit	Contradiction Checker, Hallucination Guard, Bias Auditor, Safety Merge
📝 Documenter	ESI scoring, differential diagnosis, report generation	ESI Scorer, Differential Builder

Pipeline: Coordinator → [pass] → Radiologist → Lab Analyst → Safety → Documenter → END

---

⚡ Why AMD MI300X?

Healthcare AI has three non-negotiable requirements:

1. On-premise deployment — patient data cannot leave the hospital (HIPAA)
2. Large model capacity — medical reasoning requires 35B+ parameters
3. No quantization — clinical accuracy degrades with INT8/INT4

Requirement	AMD MI300X	NVIDIA H100 80GB
On-premise	✅	✅
HBM capacity	192 GB	80 GB
Dual-model FP16	✅ Fits	❌ Does not fit
Headroom	93 GB	None

The decisive advantage: Our dual-model stack (99GB total) fits at full FP16 on MI300X. An H100 80GB would require quantization, degrading clinical accuracy.

---

🏗️ Dual-Model Stack

Model	Role	VRAM	License
Qwen2.5-VL-7B-Instruct	Vision (chest X-ray analysis)	~14 GB	Apache 2.0
Qwen3.5-35B-A3B	Text reasoning (256-expert MoE, 3B active)	~70 GB	Apache 2.0
Total		~99 GB

Qwen2.5-VL-7B  FP16 weights:  ~14 GB
Qwen3.5-35B    FP16 weights:  ~70 GB
KV cache (both, 32K context): ~15 GB
─────────────────────────────────────
Total:                         ~99 GB
MI300X HBM3:                  192 GB
Headroom:                     ~93 GB
Utilization:                   52%

---

📊 50-Case Live Benchmark (AMD MI300X)

Every case ran real inference with cached: false. Zero mock data.

Metric	Value
Cases tested	50
Successful	50 (100%)
Mean latency	23.02s
Min latency	19.80s
Max latency	27.91s
Mode	Real AMD MI300X inference

GPU Evidence (from rocm-smi)

State	VRAM	GPU Use	Power	Temp
Baseline (models loaded)	94.4% (181GB/192GB)	10%	231W	38°C junction
Post-inference	88.6% (170GB/192GB)	49%	263W	40°C junction

📁 Raw evidence: benchmarks/gpu_results/droplet_complete/rocm_smi_*.txt

---

🛡️ Safety Layer: 3 Parallel Checks

The crown jewel of ClinSight is the Safety Agent with three parallel subagents:

Check	What It Does	Example
Contradiction Checker	Cross-modality mismatch detection	Image shows pneumonia, but WBC is normal → downgrade confidence
Hallucination Guard	Visual grounding verification	Finding without attention region → flag as ungrounded
Bias Auditor	Demographic disparity detection	Elderly patient with edema → flag undertriage risk

All three run simultaneously and merge into confidence downgrades before any output reaches a physician.

---

🎯 The "What If?" Demo

Same chest X-ray. Same patient. Different labs → Different triage.

Scenario	Labs	Result
Critical labs	Lactate 3.2, pO2 58	ESI 1 — Immediate
Normal labs	Lactate 1.1, pO2 98	ESI 3 — Urgent

This is multimodal reasoning, not just multimodal input.

---

🚀 Quick Start

# Clone
git clone https://github.com/shamuddin/ClinSight.git
cd ClinSight

# Backend
cd backend
python -m venv .venv
source .venv/bin/activate
pip install -r requirements.txt
PYTHONPATH=.. uvicorn backend.api.main:app --host 0.0.0.0 --port 8000

# Frontend (new terminal)
cd frontend/react-app
npm install
npm run dev
# Open http://localhost:5173

AMD MI300X Production Setup

# Setup ROCm + vLLM (one-time, ~15-30 min)
chmod +x scripts/setup_amd_gpu.sh
./scripts/setup_amd_gpu.sh

# Start dual-model vLLM servers
./scripts/start_vllm_vision.sh &
./scripts/start_vllm_text.sh &

# Verify GPU health
python scripts/gpu_health_check.py

See docs/TECHNICAL_WALKTHROUGH.md for full architecture deep-dive.

---

🔗 Links

Resource	URL
🌐 Live Demo	clinsight-e7ai.onrender.com
🤗 Hugging Face Space	huggingface.co/spaces/shamuddin/clinsight
🎥 Demo Video	YouTube (update with your URL)
📖 Technical Walkthrough	docs/TECHNICAL_WALKTHROUGH.md
🏆 Hackathon	AMD Developer Hackathon @ lablab.ai

---

🧪 Tests

PYTHONPATH=. python -m pytest tests/ -v --cov=backend --cov-report=html

---

📜 License

Apache-2.0 — See LICENSE

⚠️ Medical Disclaimer: This software is for research and educational purposes only. Not for clinical use without regulatory approval and physician oversight. Every output requires clinician review.

---

Built with ❤️ for the AMD Developer Hackathon @ lablab.ai — Track 3: Vision & Multimodal AI
