feat: snap to vector tile basemap features#75

Merged
jessicamcinchak merged 16 commits intomainfrom
jess/snapping
Nov 12, 2021
Merged

feat: snap to vector tile basemap features#75
jessicamcinchak merged 16 commits intomainfrom
jess/snapping

Conversation

@jessicamcinchak
Copy link
Copy Markdown
Member

@jessicamcinchak jessicamcinchak commented Nov 10, 2021

Implementation assumptions:

  • Snapping is only possible if OS Vector Tiles basemap is enabled (not OS Raster basemap or OSM); this requires OS API key
  • Snapping points appear when drawMode is enabled and zoom level > 20
  • Snapping points remain visible after you've closed your shape as reference points, but when modifying you won't get the same pixelTolerance/gravitational pull towards the snaps as you do when in initial drawing mode

Default styles:

  • Drawing cursor is updated to red crosshair rather than dot
  • Snapping points are solid black with a radius of 3 pixels, a bit smaller than drawing cursor and red drawing vertices
  • Drawing vertices will always appear on top of snapping points
  • Color & size are currently not user configurable, but please say so if this is a MVP priority and we can convert to a Lit property!

chrome-capture (3)

Closes #55

@netlify
Copy link
Copy Markdown

netlify Bot commented Nov 10, 2021

✔️ Deploy Preview for oslmap ready!

🔨 Explore the source changes: 577ac9a

🔍 Inspect the deploy log: https://app.netlify.com/sites/oslmap/deploys/618cff4e45bcbf0008281014

😎 Browse the preview: https://deploy-preview-75--oslmap.netlify.app

@jessicamcinchak jessicamcinchak changed the title netlify test feat: snap to vector tile basemap features Nov 10, 2021
@jessicamcinchak jessicamcinchak mentioned this pull request Nov 10, 2021
@jessicamcinchak jessicamcinchak requested review from a team and melzreal November 10, 2021 10:29
@jessicamcinchak
Copy link
Copy Markdown
Member Author

Comment thread src/my-map.ts
}

// extract snap-able points from the basemap, and display them as points on the map
setTimeout(() => {
Copy link
Copy Markdown
Contributor

Choose a reason for hiding this comment

The reason will be displayed to describe this comment to others. Learn more.

Is this timeout really necessay?

Copy link
Copy Markdown
Member Author

Choose a reason for hiding this comment

The reason will be displayed to describe this comment to others. Learn more.

the timeout helps keep the zoom & pan interactions feeling a lot smoother in my opinion, and a bit more performant to only extract the snap points once a user has settled on location rather than mid-drag

Comment thread tsconfig.json
"experimentalDecorators": true,
"forceConsistentCasingInFileNames": true,
"lib": ["es2017", "dom", "dom.iterable"],
"lib": ["es2019", "dom", "dom.iterable"],
Copy link
Copy Markdown
Contributor

Choose a reason for hiding this comment

The reason will be displayed to describe this comment to others. Learn more.

Can we keep es2017 just in case?

@jessicamcinchak jessicamcinchak merged commit 941b897 into main Nov 12, 2021
@jessicamcinchak jessicamcinchak deleted the jess/snapping branch November 12, 2021 17:14
