bharatlas

A visual catalog, drag-drop verifier, and anonymous contribution flow for India's geo data. Admin boundaries from state to village, plus community-submitted layers under open licences.

Live: https://bharatlas.com

catalog          → state · district · subdistrict · block · village (LGD-coded)
verify           → drop GeoJSON · KML · KMZ · GPX · TCX · Parquet → render + validate
submit           → contribute under an open licence · anonymous · admin-token model
view (/c/<id>)   → public page per submission, ▲/▼ vote, JSON-LD indexed

What's in this repo

Path	Contents
web/	Vanilla TypeScript + Vite viewer + Cloudflare Pages Functions (web/functions/).
web/migrations/	D1 SQL migrations: submissions, tokens, ratings, votes, originals.
web/tests/	vitest unit tests for pure functions (validators, tokens, view rendering, votes).
scripts/fetch.sh	Pulls parquets + PMTiles from yashveeeeeeer/india-geodata releases.
scripts/extract_per_state.py	Slices pan-India parquets into per-state GeoJSON via DuckDB-spatial.
scripts/upload_r2.sh	Mirrors sources/ + data/ to Cloudflare R2.
scripts/admin/cleanup_submission.sh	Delete community submissions by name pattern (R2 + D1).
catalog.json	Curated-layer index used by the viewer. Single source of truth.
REPORT.md	Coverage + provenance + caveats per curated layer.

Large data files (sources/, data/) are not in git — they live in R2. See scripts/fetch.sh to rebuild locally.

Stack

Layer	Tech
Frontend	Vanilla TypeScript, Vite, MapLibre GL JS, PMTiles, DuckDB-WASM (lazy)
Static hosting	Cloudflare Pages
Edge functions	Cloudflare Pages Functions (web/functions/) — submit, vote, sitemap, edge-rendered /c/<id>
Storage	Cloudflare R2 (open data, no egress)
Submissions DB	Cloudflare D1 (SQLite at the edge)
Anti-abuse	Cloudflare Turnstile + per-IP rate limits
CI/CD	GitHub Actions — tests + build + auto-deploy on push to main

Develop

# clone + viewer-only dev (no submissions, no D1)
git clone git@github.com:urbanmorph/geodata.git
cd geodata/web
npm install
npm run dev    # http://localhost:5173
npm test       # 167 vitest tests

For the full submission flow (D1 + R2 + Turnstile + Pages Functions), see docs/full-dev.md (TODO) or read wrangler.toml + .dev.vars.example.

Contributing

1. Branch off main: git checkout -b feat/short-name
2. Write a test first if you're adding logic to web/functions/lib/*. Pure functions are tested via vitest in web/tests/.
3. Make sure npm test and npm run build both pass.
4. Open a PR against main. CI runs tests + build automatically.
5. The maintainer reviews and merges. Merge to main = auto-deploy.

Commit messages: short subject, body explains why not what. Examples in git log.

Tests

cd web && npm test

167 tests across validators, token generation, vote tally, render-view HTML, etc. See web/tests/.

Roadmap

• v1 — pan-India admin layers, parquet + PMTiles downloads
• v2 — DuckDB-WASM filter & export per state
• v3 — submission flow: drag-drop verify, anonymous token, auto-moderation, /c/[id] view page, mixed catalog, votes
• v4 — public API + MCP server + Claude Code plugin

Security

Report vulnerabilities to sathya@urbanmorph.com instead of opening a public issue. Acknowledgement within 72 hours.

Licence

Code: MIT. Data: each layer carries its own open licence — see the per-card line on the catalog. Curated data is sourced under CC0-1.0 / CC-BY-4.0 / GODL-India depending on provider.

Use of data

The platform doesn't warrant accuracy or fitness for any purpose. Boundaries shown are for reference, not legal authority — refer to LGD, SOI, Bhuvan or the state revenue department for official use. Community submissions are auto-moderated, not editorially curated; verify provenance via the source link on each card. See /about → Use of data.

Credits

• yashveeeeeeer/india-geodata — upstream parquet + PMTiles publisher.
• LGD, SOI, Bhuvan — primary government sources.
• geoBoundaries — independent cross-check.
• mdshare — the anonymous-token contribution pattern lineage.

Built by Urban Morph · @sathyasankaran. Drop a ⭐ if you find it useful.

Status

Alpha. The submission flow is live and accepting contributions, but the schema and API may change before v4. Community submissions are permanent under the open licence the contributor selected.
