gStream

中文文档

High-performance real-time video streaming for Godot — encode game frames and stream them to browsers via WebRTC with hardware-accelerated encoding.

Features

• 🎮 Godot Native — GDExtension plugin with zero-GC viewport capture and C# fallback
• 📺 WebRTC Streaming — Millisecond latency with keyboard/mouse/gamepad input relay
• 🚀 Multi-Codec — H264 / H265 / AV1 / VP9 with auto GPU encoder selection (NVENC / QSV / AMF / VAAPI)
• 📦 Native AOT — Core library compiles to native DLL/SO, callable from C++ engines (UE5, etc.) via C API
• 📱 Cross-Platform — Windows / Linux / macOS

Quick Start

Option 1: GDExtension (Recommended)

Download the latest gstream-v*-gde-win-x64.zip from Releases, extract into your Godot project, and enable the plugin.

Option 2: Godot .NET Plugin

1. Copy demo/gstream-godot/addons/gstream/ into your Godot project's addons/gstream/
2. Enable the plugin in Project → Project Settings → Plugins
3. Add a StreamServer node to your scene

Signaling Server

cd src/gstream-webapp
npm install && npm run build
npm start   # Listens on port 80, use --port to change

Requirements

Component	Version
Godot	4.6+ (standard for GDE, .NET for C# plugin)
.NET SDK	10.0
Node.js	18+ (signaling server)
OS	Windows 10+ / Linux x64 / macOS

Supported Encoders

GPU	H264	H265	AV1
NVIDIA NVENC (GTX 9xx+)	✅	⚠️	—
NVIDIA NVENC (RTX 40+)	✅	✅	✅
Intel QSV (Arc / 11th Gen+)	✅	✅	✅
AMD AMF (RX 5000+)	✅	✅	⚠️
Apple VideoToolbox	✅	✅	—
Software (libx264/libvpx)	✅	—	✅

Codec Quick Reference

streamServer.Codec = VideoCodec.Auto;            // Auto-negotiate (recommended)
streamServer.Codec = VideoCodec.H264_High_L31;   // Best compatibility
streamServer.Codec = VideoCodec.AV1_Main_L5;     // Best quality (RTX 40+)
streamServer.Codec = VideoCodec.VP9_Profile0;    // Royalty-free (CPU)

Full codec table and SDP details → README_CN.md § 编解码器支持

Architecture

Godot Engine
├── StreamServer (Node)
│   ├── ViewportCapture → FFmpeg Encoder
│   └── WebRTC Streamer → Signaling Server → Browser
└── gstream_native (C++ GDExtension, optional)

Detailed architecture diagrams → README_CN.md § 架构

Project Structure

src/
├── gStream.Core/          # Core library (encoding / WebRTC / signaling)
├── gStream.GDExtension/   # Native AOT GDExtension
├── gstream-webapp/        # Signaling server + web client (TypeScript / Express)
demo/
├── gstreamGodot/          # Godot .NET demo
└── gstreamGdedemo/        # GDExtension demo (no .NET SDK required)

Build from Source

Godot Plugin (C#)

cd demo/gstreamGodot
dotnet build

Native AOT DLL (for C++ engines)

# Windows x64
dotnet publish src/gStream.Core/gStream.Core.csproj -r win-x64 -c Release -p:PublishAot=true

# Linux x64
dotnet publish src/gStream.Core/gStream.Core.csproj -r linux-x64 -c Release -p:PublishAot=true

Signaling Server

cd src/gstream-webapp
npm install && npm run build
npm start

Full build guide → README_CN.md § 从源码构建

Exported C API (Native AOT)

Function	Description
gstream_session_create(w, h, fps, bitrate, codec, preset, url, addr, recv)	Create streaming session
gstream_push_frame(session, w, h, stride, data)	Push BGRA32 frame
gstream_push_frame_direct(session, w, h, stride, data)	Push frame (zero-copy)
gstream_push_audio(session, samples, count)	Push float32 PCM samples
gstream_force_keyframe(session)	Force next frame as keyframe
gstream_is_connected(session)	Check WebRTC connection status
gstream_session_destroy(session)	Destroy session

Complete API reference → README_CN.md § 导出的 C API

Known Issues

• H265 WebRTC — Chrome requires experimental flag, Firefox not supported. Use AV1 or H264 instead.

License

MIT
