ChainLinkAgents

Chainlink community node for BizFirst.Ai — a ProcessEngine ExecutionNode (chainlink) that exposes Chainlink's CCIP (Cross-Chain Interoperability Protocol) as drag-and-drop steps in BizFirst.Ai workflow automations: building cross-chain messages, tracking their delivery status, reading Router contract state, and checking Lane/Risk Management Network health.

What it does

ChainLinkAgents lets a BizFirst.Ai workflow build, send-prepare, and monitor Chainlink CCIP cross-chain messages without touching an SDK. message/build does pure local ABI encoding (no network call at all); the HTTP operations call the free, public CCIP API v2 (api.ccip.chain.link/v2); and router/isChainSupported/router/getFee make a real, independent on-chain read via a minimal Nethereum client. No operation on this node holds a wallet or signs a transaction — actually sending a built message (ccipSend(...)) is a separate step performed by the Ethereum ExecutionNode's own contract-write operation.

Resource	Operation	Description
message	build	Builds the ABI-encoded EVM2AnyMessage tuple + extraArgs bytes. Local, pure computation.
message	getStatus	Looks up a sent message's delivery status (UNTOUCHED/IN_PROGRESS/SUCCESS/FAILURE).
message	checkManualExecutionRequired	Reports whether a FAILURE-state message is eligible for manual re-execution.
message	getTokenTransferRateLimit	Prepares a call descriptor for a token's cross-chain rate limit (unresolved — ABI unconfirmed).
router	getAddress	Static per-network Router contract address lookup.
router	isChainSupported	Real on-chain read: is a destination chain supported by this Router.
router	getFee	Real on-chain read: the CCIP fee for a given message.
router	convertChainSelector	Converts between network name, native chain ID, and CCIP chain selector.
lane	getSupportedLanes	Lists supported (source, destination) CCIP lane pairs.
lane	getLatency	Estimated message latency for a specific lane.
lane	getRiskManagementStatus	Risk Management Network ("verifiers") blessing status.

This node covers CCIP only. Chainlink Data Feeds are out of scope (delegated to the Ethereum ExecutionNode's generic contract-call path + Standards Registry); VRF, Automation, and Functions are not implemented by any node in this codebase. See Roadmap.

Source Code

Browse the real implementation in src/ — three .NET projects, copied verbatim from the BizFirst.Ai platform, no code or namespace changes:

• src/BizFirst.Integration.Chainlink.Domain — result records + shared value types (zero deps)
• src/BizFirst.Integration.Chainlink.Services — CCIP API v2 client, ABI encoder, on-chain reader, resource services
• src/BizFirst.Ai.ExecutionNodes.Blockchain.ChainLink — the executor: routing, config parsing, operation DTOs

Documentation

• This site: chainlink.bizfirstai.com — quick reference and links
• Full guide (11 pages): docs.bizfirstai.com/Nodes/ChainLink — configuration, networks, every resource's operations, CCIP concepts, examples, troubleshooting
• Full developer portal: docs.bizfirstai.com

All BizFirst.Ai node documentation is maintained in one place — the UserGuides portal — rather than duplicated per repo.

Project layout

src/
├── BizFirst.Integration.Chainlink.Domain             # Result records + shared value types (zero deps)
├── BizFirst.Integration.Chainlink.Services            # CCIP API v2 client, ABI encoder, on-chain reader, resource services
└── BizFirst.Ai.ExecutionNodes.Blockchain.ChainLink     # Executor: routing, config, operation DTOs
docs/
├── index.html  # This site's homepage — quick reference, links out to the full guide
└── CNAME       # chainlink.bizfirstai.com

Targets .NET 9. The Tests project (unit/regression tests, 44 tests as of the last review pass) is part of the source platform's repo but is not included here.

Naming note: the two integration projects use the lowercase spelling Chainlink (BizFirst.Integration.Chainlink.Domain/.Services), while the executor project and this repo use ChainLink. Both spellings refer to the exact same node.

Configuration

"Chainlink": {
  "BaseUrl": "https://api.ccip.chain.link/v2/",
  "NetworkRpcUrls": {
    "ethereum-mainnet": "https://your-rpc-provider/...",
    "arbitrum-mainnet": "https://your-rpc-provider/...",
    "base-mainnet": "https://your-rpc-provider/..."
  }
}

BaseUrl defaults to the real public CCIP API and rarely needs overriding. NetworkRpcUrls is required only for router/isChainSupported and router/getFee — every other operation works with no RPC configuration at all. No production default RPC URL is bundled, since an RPC endpoint is deployment-specific infrastructure. An optional CCIP API key (an API_KEY-type vault credential) raises rate-limit headroom but is not required for any operation this node implements.

Registration

ChainlinkDependency.RegisterDefaults(services) registers the CCIP API client, rate-limit handler, message builder, on-chain reader, the 3 resource services, the executor (scoped), and the ExecutorRegistry entry (chainlink). Host applications should also add new ChainlinkDependency().RegisterDefaults(services); to their node-plugin bootstrap (Plugins_RegisterAllNodes() in ServiceCollectionExtensionsForAI.cs), alongside a ProjectReference to this executor's csproj, so the assembly is force-loaded and discoverable at runtime.

Roadmap

• Manual execution submission — checkManualExecutionRequired only reports eligibility today; actually submitting a manual execution needs a confirmed authorization/calldata shape.
• Live CCIP Directory integration — the per-network reference table is a small bundled static table today; only Ethereum mainnet's chain selector is independently confirmed, and every Router address is a placeholder.
• getTokenTransferRateLimit resolution — currently returns a prepared call descriptor since no on-chain rate-limiter ABI was confirmed during design review.
• Two originally-designed operations (get message by transaction, list messages by address) were cut — no real CCIP API endpoint was found to back either.

See Roadmap for full detail.

About BizFirst.Ai

BizFirst.Ai is a workflow automation platform for building AI-driven business processes. This node is one of many community connectors that plug into its ProcessEngine — browse the full node catalogue and developer guides at docs.bizfirstai.com, or join the discussion at community.bizfirstai.com.

License

Community node maintained by the BizFirst.Ai team.
