Diction

The iOS keyboard for voice and AI.

Dictate, compose, and edit - by voice, in any app.
On-device, cloud, or self-hosted. Open-source gateway.

Download on the App Store Diction on Product Hunt

Website • Self-Hosting Guide • Privacy Policy

License: MIT Coverage

A Diction Labs project.

Contributors

omachala
omachala 		jeprecated
jeprecated 		ankitson
ankitson 		DXCanas
DXCanas

What is Diction?

Diction is an iOS keyboard that transcribes speech to text directly in any app. Tap the mic, speak, text lands in the field. No switching apps, no copy-paste.

This repo is the open-source gateway: a Go service that sits between the iOS keyboard and your speech-to-text backend. It handles the WebSocket streaming protocol, AES-256-GCM end-to-end encryption, and optional LLM cleanup. The iOS app is on the App Store; the gateway is what you self-host.

  • Self-hosted in one command. docker compose up and paste the URL into the app. Your server, your models, your data.
  • Model-agnostic. The gateway speaks the OpenAI transcription API spec. Point it at any speech-to-text backend that implements it. Your model, your stack.
  • On-device option. On-device models run locally on the iPhone. No gateway needed for that mode.
  • Encrypted in transit. AES-256-GCM with X25519 key exchange. Same primitives used by Signal and WireGuard.
  • Zero tracking. No analytics, no telemetry, no data collection. Audit the source yourself.
  • Free and unlimited. Self-hosted and on-device modes have no caps, no rate limits, no expiry.

Self-Hosting

Diction speaks the OpenAI transcription API (POST /v1/audio/transcriptions) directly, so any compatible Whisper server works without the gateway. The gateway adds a WebSocket layer for live streaming — audio is transcribed as you speak, so by the time you tap stop the result is already back. For longer dictations the difference is noticeable; for short phrases it barely matters. The gateway also handles end-to-end encryption and optional LLM cleanup.

Full walkthrough with screenshots: How to Set Up Diction - the self-hosted speech-to-text alternative to Wispr Flow

Requirements:

  • Any machine that can run Docker: Mac, Linux box, NUC, home server, VPS. Apple Silicon works (via Rosetta).
  • iPhone running iOS 17.0 or later.

Step 1 - Write the Compose File

Create a folder for the stack and save this as docker-compose.yml:

services:
  # The whisper server runs as uid 1000. A volume left behind by the older root-based
  # images is owned by root, so without this the server cannot write and every model
  # download fails with a permission error. No-op on a fresh install.
  whisper-models-init:
    image: dictionlabs/whisper-server:latest-cpu
    user: root
    volumes:
      - whisper-models:/cache
    entrypoint: ["sh", "-c", "chown -R 1000:1000 /cache"]
    restart: "no"

  whisper-small:
    image: dictionlabs/whisper-server:latest-cpu
    container_name: diction-whisper-small
    restart: unless-stopped
    depends_on:
      whisper-models-init:
        condition: service_completed_successfully
    volumes:
      - whisper-models:/home/ubuntu/.cache/huggingface/hub
    healthcheck:
      test: ["CMD", "curl", "-fsS", "-o", "/dev/null", "http://localhost:8000/health"]
      interval: 30s
      timeout: 5s
      retries: 3
      start_period: 120s

  # The whisper server never downloads a model on demand: it answers "not installed
  # locally" instead of fetching. Without this one-shot pull the stack starts cleanly
  # and then fails every transcription. Idempotent, exits once the model is on disk.
  whisper-small-pull:
    image: dictionlabs/whisper-server:latest-cpu
    depends_on:
      whisper-small:
        condition: service_healthy
    entrypoint: ["curl", "-fsS", "-X", "POST",
                 "http://whisper-small:8000/v1/models/DictionLabs/whisper-small-ct2"]
    restart: "no"

  gateway:
    image: ghcr.io/dictionlabs/gateway:latest
    platform: linux/amd64
    container_name: diction-gateway
    restart: unless-stopped
    ports:
      - "8080:8080"
    depends_on:
      - whisper-small
    environment:
      DEFAULT_MODEL: small

volumes:
  whisper-models:

Existing installs on ghcr.io/omachala/diction-gateway continue to work and receive identical images — no action needed. Images are now published under Diction Labs on both GHCR and Docker Hub.

The whisper-models volume persists the model weights (~500 MB for small) so they survive container rebuilds. DEFAULT_MODEL: small maps to the service named whisper-small - see Swap the Speech Model if you change the model.

The first up takes a few minutes longer than later ones while whisper-small-pull downloads the model. It exits as soon as that finishes, and subsequent starts skip straight past it.

Step 2 - Start the Stack

docker compose up -d

First run pulls the images and downloads model weights - give it 2–3 minutes.

docker compose logs -f          # watch progress
docker compose ps               # check status

Expected:

NAME                     STATUS
diction-gateway          Up 30 seconds
diction-whisper-small    Up 2 minutes (healthy)
Error Fix
pull access denied on gateway image docker logout ghcr.io and retry
exec format error on Apple Silicon Enable Rosetta in Docker Desktop → Settings → General
health: starting for > 3 minutes Model still downloading - docker compose logs -f whisper-small
Gateway exits immediately Whisper container failed - check its logs

Step 3 - Test the Server

Generate a test audio file (macOS):

say -o test.aiff "Hello from my home server"

Or record a voice memo on your phone and AirDrop it over.

curl -X POST http://localhost:8080/v1/audio/transcriptions \
  -F "file=@test.aiff" \
  -F "model=small"
{"text":"Hello from my home server."}
# Check timing headers
curl -sS -D - -o /dev/null \
  -X POST http://localhost:8080/v1/audio/transcriptions \
  -F "file=@test.aiff" -F "model=small" | grep -i diction

That returns three headers, verified against a live gateway:

Header Meaning
X-Diction-Whisper-Ms speech model inference latency in milliseconds
X-Diction-Route-Model which backend actually served the request
X-Diction-Route-Lang detected language, empty when detection didn't run

X-Diction-LLM-Ms is added when AI cleanup runs. X-Diction-Route-Model is the quickest way to confirm a model switch took effect, since an unrecognised model name silently falls back to DEFAULT_MODEL.

Response Cause
Connection refused Gateway not running - docker compose ps
502 Bad Gateway Whisper unreachable, still loading, or DEFAULT_MODEL names a service that isn't running
400 Bad Request Unsupported response_format (only json and text)
404 Not Found URL typo - path must be exactly /v1/audio/transcriptions
OOM / container crash Model too large for available RAM

Step 4 - Find Your Server's IP

macOS:

ipconfig getifaddr en0
# or
ifconfig | grep 'inet ' | grep -v 127.0.0.1

Linux:

hostname -I | awk '{print $1}'

Windows:

ipconfig | findstr IPv4

Pick the 192.168.x.x or 10.x.x.x address. Ignore anything starting with 100. - that's Tailscale.

Set a DHCP reservation in your router so the IP doesn't change on reboot. Or use Tailscale for a stable address that follows the machine anywhere.

Step 5 - Connect the App

Install Diction on your iPhone. On first launch:

  1. Settings → General → Keyboard → Keyboards → Add New Keyboard → Diction
  2. Tap Diction in the list → enable Allow Full Access
  3. Grant microphone access when prompted

Point it at your server:

  1. Open Diction → Preferences → Mode → Self-Hosted
  2. Enter your endpoint: http://192.168.1.42:8080 (your IP from Step 4)
  3. Tap Test connection - you should get a green check within a second

To dictate: open any app, tap a text field, long-press the globe icon (bottom-left of the iOS keyboard), pick Diction, tap the mic, speak, release.

Reach From Anywhere

Tailscale (recommended)

Tailscale creates a private WireGuard mesh between your devices. Install it on the server and iPhone, sign in to the same account, and use the 100.x.x.x Tailscale IP as your Diction endpoint. Works on cellular, café WiFi, anywhere. Free for personal use.

Cloudflare Tunnel (public URL, no port forwarding)

Add to your compose file:

  cloudflared:
    image: cloudflare/cloudflared:latest
    container_name: diction-cloudflared
    restart: unless-stopped
    command: tunnel --no-autoupdate run
    environment:
      TUNNEL_TOKEN: "${CLOUDFLARE_TUNNEL_TOKEN}"

Create a tunnel in the Cloudflare Zero Trust dashboard, grab the token, add it to .env, route the public hostname to http://gateway:8080. Free tier. Note: transcripts pass through Cloudflare's network (HTTPS-encrypted, but a third party is in the path).

ngrok (quick testing)

ngrok http 8080

Free tier URLs change on restart - good for a demo, not daily use.

Swap the Speech Model

Pick a compose profile and set DEFAULT_MODEL on the gateway to match:

DEFAULT_MODEL Compose profile Service name Weights served RAM Notes
small small whisper-small DictionLabs/whisper-small-ct2 ~850 MB Best for CPU
medium medium whisper-medium DictionLabs/whisper-medium-ct2 ~2.1 GB More accurate, slower on CPU
large-v3-turbo large whisper-large-turbo DictionLabs/whisper-large-v3-turbo-ct2 ~2.3 GB Highest accuracy; slow on CPU, fast on GPU
parakeet-v3 parakeet parakeet baked into the image ~2 GB 25 European languages; fast on CPU, faster on GPU
docker compose --profile small up -d

DEFAULT_MODEL and the service name must both match the table: the gateway resolves backends by Docker hostname, so if the named service isn't running every request fails with 502.

An unrecognised model name is not an error. The gateway falls back to DEFAULT_MODEL, so a typo transcribes successfully with the wrong model rather than telling you. Check the X-Diction-Route-Model response header to see which backend actually served a request.

The weights column is informational. You do not set it anywhere: the gateway names the model when it forwards each request. The whisper server does not fetch models on demand, so the compose file ships a one-shot pull service per profile that installs the model before first use. Those are our own CTranslate2 builds of OpenAI's checkpoints, published at huggingface.co/DictionLabs, so the models your server pulls come from a namespace we control rather than a third party's conversion.

docker compose up -d   # recreates only the changed container

NVIDIA GPU

Install the NVIDIA Container Toolkit on the host first.

Option A - Parakeet TDT 0.6B v3 (fastest, 25 European languages)

Parakeet transcribes a 5-second clip in well under a second on a consumer GPU.

Whisper Large-v3 Parakeet TDT 0.6B v3
WER (English) 7.4% ~6.3%
Latency (GPU) Under 2s Sub-second
VRAM (INT8) ~2.3 GB ~2 GB
Languages 99 25 European

Supported languages: English, Bulgarian, Croatian, Czech, Danish, Dutch, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Lithuanian, Maltese, Polish, Portuguese, Romanian, Slovak, Slovenian, Spanish, Swedish, Russian, Ukrainian.

For languages outside this list, use Option B.

services:
  parakeet:
    image: dictionlabs/parakeet:latest-int8
    container_name: diction-parakeet
    restart: unless-stopped
    deploy:
      resources:
        reservations:
          devices:
            - driver: nvidia
              count: 1
              capabilities: [gpu]

  gateway:
    image: ghcr.io/dictionlabs/gateway:latest
    platform: linux/amd64
    container_name: diction-gateway
    restart: unless-stopped
    ports:
      - "8080:8080"
    depends_on:
      - parakeet
    environment:
      DEFAULT_MODEL: parakeet-v3

Model weights are baked into the image - no download on first start. Or use the profile from this repo:

docker compose --profile parakeet up -d

Option B - large-v3-turbo (multilingual, 99 languages)

services:
  whisper-large-turbo:
    image: dictionlabs/whisper-server:latest-cuda
    container_name: diction-whisper-large-turbo
    restart: unless-stopped
    volumes:
      - whisper-models:/home/ubuntu/.cache/huggingface/hub
    deploy:
      resources:
        reservations:
          devices:
            - driver: nvidia
              count: 1
              capabilities: [gpu]

  gateway:
    image: ghcr.io/dictionlabs/gateway:latest
    platform: linux/amd64
    container_name: diction-gateway
    restart: unless-stopped
    ports:
      - "8080:8080"
    depends_on:
      - whisper-large-turbo
    environment:
      DEFAULT_MODEL: large-v3-turbo

volumes:
  whisper-models:

First boot downloads ~1.6 GB of model weights into the volume. Subsequent starts are instant.

Already Have a Voice Server?

Keep it. Use CUSTOM_BACKEND_URL to put the Diction Gateway in front of your existing server for WebSocket streaming and end-to-end encryption:

services:
  gateway:
    image: ghcr.io/dictionlabs/gateway:latest
    platform: linux/amd64
    container_name: diction-gateway
    restart: unless-stopped
    ports:
      - "8080:8080"
    environment:
      CUSTOM_BACKEND_URL: http://your-existing-server:8000
      CUSTOM_BACKEND_MODEL: DictionLabs/whisper-small-ct2
Variable Description
CUSTOM_BACKEND_AUTH Authorization header forwarded to your backend, e.g. Bearer sk-xxx
CUSTOM_BACKEND_NEEDS_WAV Set to "true" if your backend only accepts WAV - the gateway converts with ffmpeg
CUSTOM_BACKEND_CANONICAL_ID HuggingFace-style ID advertised via /v1/models (default: CUSTOM_BACKEND_MODEL, or the literal custom if that is unset too)

AI Cleanup (BYO LLM)

The gateway passes transcripts through any OpenAI-compatible LLM before returning them. You say "so um basically the meeting went well and uh they agreed to the timeline." The LLM returns "The meeting went well. They agreed to the timeline."

Enable the AI Companion toggle in the app. The gateway forwards the transcript to {LLM_BASE_URL}/chat/completions with your prompt, then returns the cleaned text. If the LLM fails, the raw transcript is returned - dictation never breaks.

Variable Required Description
LLM_BASE_URL Yes OpenAI-compatible endpoint, e.g. https://api.openai.com/v1
LLM_MODEL Yes Model identifier, e.g. gpt-4o-mini
LLM_API_KEY No Bearer token. Not needed for local Ollama.
LLM_PROMPT No System prompt string, or a file path starting with / (mount via volume)
LLM_REASONING_EFFORT No OpenAI-compatible reasoning effort such as none, low, medium, or high. Omitted by default.

Both LLM_BASE_URL and LLM_MODEL must be set or the feature stays off.

Option A - Cloud LLM (OpenAI, Groq, etc.)

echo "OPENAI_API_KEY=sk-your-key-here" > .env
  gateway:
    environment:
      DEFAULT_MODEL: small
      LLM_BASE_URL: "https://api.openai.com/v1"
      LLM_API_KEY: "${OPENAI_API_KEY}"
      LLM_MODEL: "gpt-4o-mini"
      LLM_PROMPT: "Clean up this voice transcription. Remove filler words (um, uh, like). Fix punctuation and capitalization. Return only the cleaned text, nothing else."

Docker Compose reads ${OPENAI_API_KEY} from .env automatically. Works with any OpenAI-compatible provider - Groq, Together, Fireworks, Mistral, OpenRouter - swap LLM_BASE_URL and LLM_MODEL.

Option B - Local Ollama (zero cost, fully private)

  ollama:
    image: ollama/ollama:latest
    container_name: diction-ollama
    restart: unless-stopped
    volumes:
      - ollama-models:/root/.ollama

  gateway:
    environment:
      DEFAULT_MODEL: small
      LLM_BASE_URL: "http://ollama:11434/v1"
      LLM_MODEL: "gemma2:9b"
      LLM_PROMPT: "Clean up this voice transcription. Remove filler words. Fix punctuation and capitalization. Return only the cleaned text, nothing else."

volumes:
  whisper-models:
  ollama-models:
docker compose up -d
docker exec diction-ollama ollama pull gemma2:9b
Model Memory Notes
gemma2:9b ~6 GB Best cleanup quality at this size
qwen2.5:7b ~5 GB Strong instruction following
llama3.1:8b ~5 GB Most popular, well-tested
gemma3:4b ~3 GB For tighter machines

Models under 7B tend to answer questions about the transcript instead of cleaning it up. 7B or larger recommended.

Testing cleanup

curl -X POST "http://localhost:8080/v1/audio/transcriptions?enhance=true" \
  -F "file=@test.aiff" \
  -F "model=small"
# Confirm LLM fired - look for X-Diction-LLM-Ms in the output
curl -sS -D - -o /dev/null \
  -X POST "http://localhost:8080/v1/audio/transcriptions?enhance=true" \
  -F "file=@test.aiff" -F "model=small" | grep -i diction

Prompt file

Mount a file and point LLM_PROMPT at the path:

  gateway:
    volumes:
      - ./cleanup-prompt.txt:/config/prompt.txt:ro
    environment:
      LLM_PROMPT: "/config/prompt.txt"

If LLM_PROMPT starts with /, the gateway reads it as a file. Otherwise it uses the string directly.

NixOS

The repo ships a flake with a hardened systemd module - no Docker needed.

nix run github:DictionLabs/Diction#diction-gateway

Enable as a service:

{
  inputs.diction.url = "github:DictionLabs/Diction";

  outputs = { nixpkgs, diction, ... }: {
    nixosConfigurations.your-host = nixpkgs.lib.nixosSystem {
      modules = [
        diction.nixosModules.default
        {
          services.diction-gateway = {
            enable = true;
            openFirewall = true;
            # customBackend.url = "http://127.0.0.1:8000";
            # llm.baseUrl = "http://127.0.0.1:11434/v1";
            # llm.model = "gemma2:9b";
            # environmentFile = "/run/secrets/diction-gateway.env";
          };
        }
      ];
    };
  };
}

The unit runs under DynamicUser with ProtectSystem=strict, NoNewPrivileges, and a narrow syscall filter. Use environmentFile for secrets - they don't end up in the world-readable Nix store. Full option list: nix/module.nix.

OpenAI API Compatibility

The gateway implements the OpenAI audio transcription API - any client that works against api.openai.com/v1/audio/transcriptions works against a Diction gateway.

from openai import OpenAI

client = OpenAI(
    base_url="http://your-server:8080/v1",
    api_key="anything",  # not checked when AUTH_ENABLED=false
)

with open("audio.wav", "rb") as f:
    result = client.audio.transcriptions.create(
        file=f,
        model="small",            # or "DictionLabs/whisper-small-ct2"
        response_format="text",
    )
print(result)

Works with the Node SDK, LangChain, Flowise, n8n, or any tool that expects OpenAI's speech API.

Supported:

  • POST /v1/audio/transcriptions - file, model, language, prompt, response_format=json|text
  • GET /v1/models - returns an OpenAI-compatible data[] array plus a providers[] grouping consumed by the iOS app. HuggingFace IDs (DictionLabs/whisper-small-ct2, nvidia/parakeet-tdt-0.6b-v3) and short aliases (small, medium, large-v3-turbo, parakeet-v3) are both accepted. The older Systran/* and deepdml/* ids stay accepted as aliases, so existing scripts keep working.
  • WebSocket /v1/audio/stream - used by the Diction app for low-latency streaming

Not supported:

  • TTS (/v1/audio/speech)
  • response_format=verbose_json|srt|vtt (no word-level timestamps)
  • SSE streaming on REST (use WebSocket /v1/audio/stream instead)
  • Model download/delete (POST/DELETE /v1/models/{id})
  • OpenAI Realtime API (/v1/realtime)

Authentication is off by default (AUTH_ENABLED=false). Pass any non-empty string as the API key from the client - the gateway doesn't check it.

Do not set AUTH_ENABLED=true on a self-hosted deployment. It does not enable a shared secret. The middleware accepts only an Apple App Store JWS validated against the Apple root CA, or an HMAC trial token signed with TRIAL_SECRET. Both exist for Diction One. Turning it on locks you out of your own server. To expose a gateway publicly, put it behind a reverse proxy or tunnel that does the auth, or keep it on a VPN.

Error shape: errors return {"error":"<message>"}, except auth failures, which return {"error":"unauthorized","reason":"...","message":"..."}, not OpenAI's nested {"error":{"message":"...","type":"..."}}. Most SDKs surface these as HTTPError rather than APIError.

Privacy

  • On-device: Everything stays on your phone. No network connection is made.
  • Self-hosted: Audio goes to your server only. Neither the gateway nor the whisper server persists audio - it's transcribed and discarded.
  • AI cleanup enabled: The transcript (plain text, no audio) goes to your configured LLM. If you use Ollama locally, nothing leaves your machine.
  • Diction One (cloud): Audio is transcribed and immediately discarded. Not stored, not used for training.
  • Zero third-party SDKs in the app. No analytics, no tracking, no telemetry.
  • Full Access is required by iOS for any keyboard that makes network requests. Diction has no QWERTY input - the only data that leaves the app is the audio recording, sent to the endpoint you configured.

Read the full Privacy Policy.

Diction One

On-device and self-hosted are completely free with no word limits.

If you don't want to run a server, Diction One gives you a fine-tuned cloud model with advanced audio filtering - without the setup. Audio is sent to the Diction endpoint, transcribed, and immediately discarded. Pricing and trial details are in the app.

Contributing

Contributions are welcome. See CONTRIBUTING.md.

License

MIT. See LICENSE.

About

Open Source self-hosted alternative to WisprFlow - iOS speech-to-text keyboard

Resources

Readme
MIT license

Contributing

Contributing
Activity
Custom properties

Stars

220 stars

Watchers

2 watching

Forks

10 forks
Report repository

Releases

Packages

Contributors

Languages
