Note

This project is currently under actively developing and improving, some APIs and interfaces may change as the design continues to mature.

About 🚀

• MOS is a Real-Time Operating System (RTOS) project built in C++/Rust, which consists of a preemptive kernel and a command-line shell with other applications (e.g., GuiLite and FatFS).

• Renode is a virtual development tool created by Antmicro for multi-node embedded networks (both wired and wireless) and is intended to enable a scalable workflow for creating effective, tested and secure IoT systems.

Repository 🌏

• mos-rust - A "Vibe Coding" Chimera, check here.

• mos-core - The Kernel and the Shell, check here.

• mos-stm32 - Running on STM32 series, check here.

• mos-renode - Test on Renode emulation, check here.

Boot Up ⚡

Milestone 🧾

📦 v0.5

✅ Done：

• [Experimental] Port to ESP32-C6(RISC-V), Add BLE support
• [Experimental] Rewrite it in Rust

📦 v0.4

✅ Done：

• Add Hardware FPU support
• CMake Tools are now available for compiling the project
• Add external library ETL, a C++ template library for embedded applications
• Add Renode emulation platform, add stable support for Cortex-M series
• [Experimental] Add scheduler lock Scheduler::suspend()
• [Experimental] Add Asynchronous stackless coroutines Async::{Executor, Future_t, co_await/yield/return}

📌 Planned:

• Shift from FatFS to LittleFS

📦 v0.3

✅ Done:

• Mapping Tids to BitMap_t
• Message queue IPC::MsgQueue_t
• Task::create allows generic function signatures as void fn(auto argv) with type checker
• Add ESP32-C3 as a WiFi component
• Add Driver::Device::SD_t, SD card driver, porting FatFs file system
• Add Shell::usr_cmds for user-registered commands
• [Experimental] Atomic types <stdatomic.h>
• [Experimental] Utils::IrqGuard_t, nested interrupt critical sections
• [Experimental] Simple formal verification of Scheduler + Mutex

📌 Planned:

• Inter-Process Communication: pipes/channels
• FPU hardware float support
• Performance benchmarking
• Error handling with Result<T, E>, Option<T>
• DMA_t DMA Driver
• Software/hardware timers Timer
• [Experimental] Adding POSIX support
• [Experimental] More real-time scheduling algorithms

📦 v0.2

✅ Done:

• Synchronization primitives Sync::{Sema_t, Lock_t, Mutex_t<T>, CondVar_t, Barrier_t}
• Scheduler::Policy::PreemptPri with RoundRobin scheduling for same priority levels
• Task::terminate implicitly called upon task exit to reclaim resources
• Simple command-line interaction Shell::{Command, CmdCall, launch}
• HAL::STM32F4xx::SPI_t and Driver::Device::ST7735S_t, porting the GuiLite graphics library
• Blocking delay with Kernel::Global::os_ticks and Task::delay
• Refactored project organization into {kernel, arch, drivers}
• Support for GCC compilation, compatible with STM32Cube HAL
• Real-time calendar HAL::STM32F4xx::RTC_t, CmdCall::date_cmd, App::Calendar
• idle uses Kernel::Global::zombie_list to reclaim inactive pages
• Three basic page allocation policies Page_t::Policy::{POOL, DYNAMIC, STATIC}

📦 v0.1

✅ Done:

• Basic data structures, scheduler, and task control, memory management

📌 Planned:

• Timers, round-robin scheduling
• Inter-Process Communication (IPC), pipes, message queues
• Process synchronization (Sync), semaphores, mutexes
• Design a simple Shell
• Variable page sizes, memory allocator
• SPI driver, porting GuiLite/LVGL graphics libraries
• Porting to other boards/arch, e.g., ESP32-C3 (RISC-V)

References 🛸

• How to build a Real-Time Operating System(RTOS)
• PeriodicScheduler_Semaphore
• STM32F4-LCD_ST7735s
• A printf/sprintf Implementation for Embedded Systems
• GuiLite
• STMViewer
• FatFs
• The Zephyr Project
• Eclipse ThreadX
• Embassy
• Renode
• Embedded Template Library (ETL)

---

🖖 Live Long and Prosper.
