Mode Reference

Reference creates from boards from various sources unlike Preview and Grid that read from a single source. For this reason the boards can act as an independant list of favorites from various folders and even from the internet to compose a mood board. Due to its nature these boards can help organize ideas and can also be archived for future reference even without the original sources being acessible anymore.

Display

Picture Picture Picture

Interaction

  • [PICKER] LMB : Read pixel color when Color picker is active
  • Pin : Pin options
    • [PIN] LMB : Activate Pin
    • [PIN] LMB ( Drag ) : Pin Move
      • SHIFT or CTRL or ALT or SHIFT + CTRL : Move Pin amd then press modifier key to snap
    • [PIN] LMB x2 : Pin full preview toggle
    • [PIN] SHIFT + CTRL + ALT + LMB : Pin full preview toggle
  • Pin Transform : Transform options ( Image and Text Pins behave different )
    • [PIN] SHIFT + CTRL + LMB ( Drag ) : Pin Move ( snaps always )
    • [PIN][NODE] SHIFT + CTRL + LMB ( Drag Perpendicular ) : Pin Scale ( snaps with cursor over node )
    • [PIN][CENTER] SHIFT + CTRL + LMB ( Drag Horizontal ) : Pin Rotate ( snaps to 5 angles always )
  • Camera : Camera options
    • MMB ( Drag ) : Camera Pan
    • Wheel : Camera Zoom
    • SHIFT + LMB ( Drag ) : Camera Pan
    • SHIFT + RMB ( Drag Vertical ) : Camera Zoom
  • Selection : Selection options
    • [BOARD] LMB ( Drag ) : Box Select
    • [PIN] CTRL + LMB : Pin Select/Deselect
    • [PIN] CTRL + RMB : Pin Select/Deselect
    • CTRL + LMB ( Drag ) : Box Select
    • CTRL + RMB ( Drag ) : Box Deselect
    • CTRL + LMB x2 : Select all Pins
    • CTRL + RMB x2 : Deselect all Pins
  • Drag and Drop : Drag and Drop options
    • ALT + LMB ( Drag ) : Drag and Drop a selected images out of the Panel into ( Krita, Keyenter, Reorder, Drive )
    • Drop Image In : Drop image into the board
  • RMB : Context Menu
    • Fit : Fits all Pins to the available space
    • Reference : Reference options
      • Refresh : Refresh the display of all Pins
      • Label : Create a text label Pin
      • Link : Input image URL to insert Pin
    • Board : Board options
      • [EO]file_name : EO file options
        • New : Create new EO file
        • Open : Open from EO file
        • Save : Save to EO file
        • Save As : Export into a new EO file
        • Archive : Archive into EO file ( bigger EO file size )
      • [KRA]file_name : KRA file options
        • Read : Read from KRA file
        • Write : Write into KRA file
        • Archive : Archive into KRA file ( bigger KRA file size )
        • Unarchive : Unarchive into KRA file ( smaller KRA file size )
    • Pin : Pin options
      • Pack[NUM] : Pack selected Pins
        • Linear Grid : Grid of images ( faster solution )
        • Linear Row : Row of images
        • Linear Column : Column of images
        • Linear Pile : Pile images
        • Optimal Area : Optimal packing with Area sort
        • Optimal Perimeter : Optimal packing with Perimeter sort
        • Optimal Ratio : Optimal packing with Ratio sort
        • Optimal Class : Optimal packing with Class sort
      • Reset : Reset options
        • Rotation : Reset Pins rotation
        • Scale : Reset Pins scale
      • File : File options
        • Open Location : Open the folder and highlights the url ( if possible )
        • Copy Path : Copy to the clipboard the url
        • Copy Image : Copy to the clipboard the image
      • Color : Color options
      • Edit : Edit options
        • View Grayscale : Toggle display Grayscale
        • Flip Horizontal : Toggle display fliped horizontal
        • Flip Vertical : Toggle display fliped vertical
        • Edit Reset : Reset all edit options
      • Insert : Insert options
        • Document : Insert image as a new document
        • Layer : Insert image as a new layer
        • Reference : Insert image as a new reference
      • Download : Download Pins to destination
      • Rebase : Relocate selected Pins
      • Delete : Delete selected Pins
    • Full Screen : Toggle full-screen ( maximized )


Control Interface


  • Text : Text to display
  • Font : Text font
  • Size : Text size
  • Color Text : Picker for the text color
  • Color Background : Picker for the background color


Mode Icons

Picture Picture Picture

  • Lock : Lock board from edits
  • Color Picker : Toggle color picker
  • Context Menu : Toggle reference control interface


Settings

Check Tab Display in the Settings.
