Unity4DGS — Gaussian Splatting for Unity

English · 中文

Real-time 3D/4D Gaussian Splatting renderer and procedural animation toolkit for Unity 6+ / URP, with visionOS / VR stereo support.

Based on aras-p/UnityGaussianSplatting (MIT), heavily extended with a GPU-driven animation system, 4D sequence playback, morphing, and XR rendering paths.

Features

Rendering

• GPU-sorted splat rendering with radix sort (counting-sort fallback on platforms without wave intrinsics)
• Global cross-model sorting: overlapping splat models blend and occlude correctly
• GPU frustum + opacity culling with indirect draw
• Optional tile-based rendering path
• Render modes: full splats, point cloud, and debug views (points, indices, boxes, chunk bounds)
• URP Render Feature (primary target); HDRP pass and built-in pipeline paths exist but are less exercised

Animation & Effects

• GaussianPlayer — 4D playback: plays per-frame splat asset sequences at a configurable frame rate
• GaussianAnimator + GaussianAnimVolume — procedural GPU animation, scoped by box/sphere volumes with falloff, non-destructive (runs on temporary buffers)
• Modifier stack — Dissolve, Wave, Warp, Property, Turbulence, Swirl, Caustic, WheatWave, Converge
• GaussianModifierStateMachine — state machine with parameter capture and blended transitions between modifier states
• GaussianMorph — GPU morph transition between two splat assets
• GaussianCutout — box/ellipsoid cutout regions
• GaussianStylizeVolume — stylization post-processing (stereo aware)

XR

• visionOS stereo rendering: single-dispatch stereo, foveated rendering (VRR) support
• Apple Vision Pro: supported only via the Metal rendering path (Compositor Services); the PolySpatial (RealityKit) path is not supported
• Quest is expected to work in principle, but is currently unverified

Requirements

• Unity 2022.3+ with URP
• A GPU with compute shader support — best results on Vulkan / Metal

Installation

Unity4DGS is a Unity package (com.hankun.4dgs); its manifest lives at Assets/4DGS/package.json. Add it to an existing project either way:

From a Git URL — in the Package Manager, choose Add package from git URL and enter (the ?path= points at the package subfolder):

https://github.com/HankunYu/Unity4DGS.git?path=Assets/4DGS

From disk — clone the repo, then in the Package Manager choose Add package from disk and select Assets/4DGS/package.json:

git clone https://github.com/HankunYu/Unity4DGS.git

Getting Started

1. Add the GaussianSplat URP Feature to your URP Renderer asset.
2. Put a GaussianSplatConfig component in the scene (holds global rendering settings and shader references).
3. Create a splat asset from a .ply / .spz file via Tools > Gaussian Splats > Create GaussianSplatAsset.
4. Add a GaussianSplatRenderer component to a GameObject and assign the asset.
5. For 4D sequences, use GaussianPlayer and point it at a folder of per-frame assets.

Sample Assets

DemoScene references a Gaussian splat asset (a "ceramic" scene) generated with World Labs Marble. That asset is not included in this repository — a fresh clone will show a missing reference in DemoScene. Bring your own .ply / .spz and create an asset (see Getting Started) to populate the scene.

Project Layout

Assets/4DGS/
├── Runtime/          # Renderer, sorting, animation system, modifiers, state machine
├── Editor/           # Asset creator, importers (PLY/SPZ), editing tools
├── Shaders/          # Splat / point cloud shaders, sorting & morph compute
├── Resources/        # Compute shaders (animation, tile rendering, utilities)
└── Settings/         # URP pipeline assets

License

MIT — see LICENSE.

Portions copyright (c) 2023 Aras Pranckevičius (UnityGaussianSplatting).
