Makefile: Use pkg-config if available. by ddiproietto · Pull Request #618 · NetSys/bess

ddiproietto · 2017-08-24T19:38:24Z

Debian buster(testing) and presumably ubuntu 17.10 package all the
dependencies required to build BESS (except dpdk).

New versions of GRPC (packaged in debian) require libc-ares and if BESS
is statically linked (by default it is), -lcares must be passed to the
linker.

Instead of forcing a new dependency for all users (even the ones that don't
need it), this commit makes use of pkg-config, which will automatically
include the indirect dependencies (such as libc-ares).

For users that have an old grpc version (such as container_build.py),
pkg-config is still optional. I'd like to make it required, but a new
container image must be generated, and that's a decision we can make
later.

Debian buster(testing) and presumably ubuntu 17.10 package all the dependencies required to build BESS (except dpdk). New versions of GRPC (packaged in debian) require libc-ares and if BESS is statically linked (by default it is), `-lcares` must be passed to the linker. Instead of forcing a new dependency for all users (even the ones that don't need it), this commit makes use of pkg-config, which will automatically include the indirect dependencies (such as libc-ares). For users that have an old grpc version (such as `container_build.py`), pkg-config is still optional. I'd like to make it required, but a new container image must be generated, and that's a decision we can make later.

`-ldl` is used by DPDK on some systems. Therefore it needs to be listed also after it on the LDFLAGS.

chris3torek · 2017-08-25T18:04:57Z

+NO_PKG_CONFIG_LIBS_INDIRECT := -lgrpc -lssl -lcrypto -llzma
+
+ifeq ($(HAS_PKG_CONFIG), yes)
+    PKG_CFLAGS = $(shell $(PKG_CONFIG) --cflags $(PKG_CONFIG_DEPS))


Can this be statically defined (with :=)?

Thanks for the suggestion! I did that here and in the other places I was shelling out to call pkg-config

gflags on ubuntu 16.04 doesn't have a pkg-config file, so we have to list it manually. `-ldl` is used by DPDK and must be listed before and after to properly be dynamically linked.

codecov · 2017-08-26T00:01:42Z

Codecov Report

Merging #618 into master will decrease coverage by 0.02%.
The diff coverage is n/a.

@@            Coverage Diff            @@
##           master    #618      +/-   ##
=========================================
- Coverage   69.33%   69.3%   -0.03%
=========================================
  Files         204     204
  Lines       13037   13068      +31
=========================================
+ Hits         9039    9057      +18
- Misses       3998    4011      +13

Impacted Files	Coverage Δ
core/drivers/unix_socket.cc	`80.15% <0%> (-4.9%)`	⬇️
core/modules/queue.h	`100% <0%> (ø)`	⬆️
core/modules/vlan_split.h	`0% <0%> (ø)`	⬆️
core/modules/port_inc.h	`100% <0%> (ø)`	⬆️
core/drivers/unix_socket.h	`100% <0%> (ø)`	⬆️

Continue to review full report at Codecov.

Legend - Click here to learn more
Δ = absolute <relative> (impact), ø = not affected, ? = missing data
Powered by Codecov. Last update 425ce73...bbb11c3. Read the comment docs.

sangjinhan · 2017-08-29T23:29:35Z

+# user requests a static build.  These needs to be listed first, so even
+# if they're listed again in the static section, they will be dynamically
+# linked.
+ALWAYS_DYN_LIBS := -lpthread -ldl


Is it necessary to add -lpthread here? The -pthread option already implies this...

I believe it's necessary.

grpc includes -lpthread in its statically required libraries. If we don't specify -lpthread before (in the dynamic section), -lpthread will be linked statically, and that's not well supported apparently

sangjinhan · 2017-08-29T23:30:05Z

+	$(PKG_LIBS) $(ALWAYS_LIBS) \
 	$(LIBS_DL_SHARED) \
-	-ldl
+	$(ALWAYS_DYN_LIBS)


Just checking: Adding $(ALWAYS_DYN_LIBS) twice was intended?

It was intended.

DPDK depends on -ldl, so -ldl must be specified after DPDK.

But then again, we want to dynamically link with -ldl. If one of the other libs depend on -ldl it will be listed in the static section. We must make sure that we include it at the beginning of the cmdline, in the dynamic section

sangjinhan · 2017-08-30T00:30:41Z

Great, thanks!

Codeacious · 2017-08-30T04:43:11Z

This pull request appears to have broken static builds for me on Ubuntu 16.04 LTS (kernel 4.4.0-93-generic):

/usr/local/home/rotor/bess/deps/dpdk-17.05/build/lib/librte_pmd_ark.a(ark_ethdev.o): In function `check_for_ext':
/usr/local/home/rotor/bess/deps/dpdk-17.05/drivers/net/ark/ark_ethdev.c:199: warning: Using 'dlopen' in statically linked applications requires at runtime the shared libraries from the glibc version used for linking
/usr/lib/gcc/x86_64-linux-gnu/5/../../../x86_64-linux-gnu/libdl.a(dlopen.o): In function `dlopen':
(.text+0x5): undefined reference to `__dlopen'
/usr/lib/gcc/x86_64-linux-gnu/5/../../../x86_64-linux-gnu/libdl.a(dlclose.o): In function `dlclose':
(.text+0x1): undefined reference to `__dlclose'
/usr/lib/gcc/x86_64-linux-gnu/5/../../../x86_64-linux-gnu/libdl.a(dlsym.o): In function `dlsym':
(.text+0x5): undefined reference to `__dlsym'
/usr/lib/gcc/x86_64-linux-gnu/5/../../../x86_64-linux-gnu/libdl.a(dlerror.o): In function `dlerror':
(.text+0x1): undefined reference to `__dlerror'
collect2: error: ld returned 1 exit status
Error: port_test
g++ -o port_test port_test.o gtest-all.o gtest_main.o bess.a -rdynamic -L/usr/local/home/rotor/bess/deps/dpdk-17.05/build/lib -Wl,-rpath=/usr/local/home/rotor/bess/deps/dpdk-17.05/build/lib -pthread -static-libstdc++ -lpthread -ldl -Wl,-non_shared -Wl,--whole-archive -ldpdk -Wl,--no-whole-archive -L/usr/local/lib -lglog -lprotobuf -pthread -lpthread -lz -lgrpc++ -lgrpc -lssl -ldl -lcrypto -ldl -lunwind -llzma -lz -lpcap -lgflags -Wl,-call_shared -lpthread -ldl -libverbs
Makefile:394: recipe for target 'port_test' failed

The full output is much longer, but are duplicates of this error on other files.

The issue seems to be that pkg-config --libs --static grpc++ returns -L/usr/local/lib -lgrpc++ -lgrpc -lz -lssl -ldl -lcrypto -ldl, meaning g++ attempts to use symbols from the static library libdl.a instead of libdl.so when linking DPDK. Manually running the linking command without the additional -ldl flags returned by pkg-config solves the issue.

An easy, but hacky, way to do this in the Makefile is to use sed:
PKG_LIBS := $(shell $(PKG_CONFIG) --static --libs $(PKG_CONFIG_DEPS) | sed -e s/-ldl//g)
But there's probably better method to solve this issue.

ddiproietto · 2017-08-30T19:02:01Z

Thanks for reporting this and sorry for the breakage.

I wasn't able to reproduce it on ubuntu 16.04, but your suggestion makes sense to me (I like it better than listing twice the libraries).

I submitted PR #626, I removes -ld from the static libraries, I hope it fixes the problem for you.

Thanks

ddiproietto added the notready label Aug 25, 2017

Makefile: list -ldl also after DPDK.

4067b84

`-ldl` is used by DPDK on some systems. Therefore it needs to be listed also after it on the LDFLAGS.

chris3torek reviewed Aug 25, 2017

View reviewed changes

ddiproietto added 2 commits August 25, 2017 15:57

Makefile: Fix build on container.

c3c0292

gflags on ubuntu 16.04 doesn't have a pkg-config file, so we have to list it manually. `-ldl` is used by DPDK and must be listed before and after to properly be dynamically linked.

Makefile: Use := instead of = when shelling out.

bbb11c3

ddiproietto removed the notready label Aug 28, 2017

sangjinhan approved these changes Aug 29, 2017

View reviewed changes

sangjinhan merged commit 78c6c00 into NetSys:master Aug 30, 2017

ddiproietto deleted the pkg_config branch August 30, 2017 00:36

sangjinhan mentioned this pull request Sep 8, 2017

"undefined reference to '__dlopen'" in [TEST_LD]gate_test of building ''Daemon" #631

Closed
