Makefile: Fix build on ubuntu 16.04 with pkg-config. by ddiproietto · Pull Request #626 · NetSys/bess

ddiproietto · 2017-08-30T19:00:34Z

Instead of listing twice the libraries that we want to link dynamically
with, we can simply filter those out from the result of pkg-config.

This should fix the build in ubuntu 16.04 (although I wasn't able to
reproduce the problem).

Reported and suggested by @Codeacious

@Codeacious

Instead of listing twice the libraries that we want to link dynamically with, we can simply filter those out from the result of pkg-config. This should fix the build in ubuntu 16.04 (although I wasn't able to reproduce the problem). Reported and suggested by @Codeacious

Codeacious · 2017-08-30T20:24:28Z

I'm able to build successfully with this change. Thanks!

chris3torek · 2017-08-30T20:47:53Z

I don't see why this is stalling on Travis, but something goes wrong during test_list_modules (pybess.test_bess.TestBESS) ... (test never finishes). It seems to be consistent though: all six of the matrix builds stall out in the same spot.

xnhp0320 · 2017-08-31T12:19:26Z

Hi, have this Travis issued been fixed? I am also hitting on this issue, and by using your patch, I can build bess now.

ddiproietto · 2017-08-31T17:14:24Z

I'm still investigating the issue, it doesn't appear to be related to this PR.

I can reproduce the problem locally by upgrading python grpcio to 1.6.0 (@chris3torek and I noticed that it has been updated on pypi yesterday).

test_kill appears to cause problems (

bess/pybess/test_bess.py

Line 90 in 65a01c7

def test_kill(self):

), if I skip it everything seems fine.

This is the output with debug set to true (

bess/pybess/bess.py

Line 97 in 65a01c7

self.debug = False

), it appears that the channel doesn't recover from TRANSIENT_FAILURE

I'm still investigating, worst case we can ask pip to install grpcio 1.4.0

test_connect (pybess.test_bess.TestBESS) ... Channel status: None -> ChannelConnectivity.IDLE
Channel status: ChannelConnectivity.IDLE -> ChannelConnectivity.CONNECTING
Channel status: ChannelConnectivity.CONNECTING -> ChannelConnectivity.READY
ok
test_create_port (pybess.test_bess.TestBESS) ... Channel status: None -> ChannelConnectivity.IDLE
Channel status: ChannelConnectivity.IDLE -> ChannelConnectivity.CONNECTING
Channel status: ChannelConnectivity.CONNECTING -> ChannelConnectivity.READY
==== /bess.pb.BESSControl/CreatePort
---> CreatePortRequest
{'arg': {'type_url': 'type.googleapis.com/bess.pb.PCAPPortArg',
         'value': '\n\x03rnd'},
 'driver': 'PCAPPort',
 'name': 'p0'}
<--- CreatePortResponse
{'name': 'p0'}
==== /bess.pb.BESSControl/CreatePort
---> CreatePortRequest
{'arg': {'type_url': 'type.googleapis.com/bess.pb.PMDPortArg',
         'value': '\x08\x01\x10\xf5o'},
 'driver': 'PMDPort',
 'name': 'p0'}
<--- CreatePortResponse
{'name': 'p0'}
==== /bess.pb.BESSControl/CreatePort
---> CreatePortRequest
{'arg': {'type_url': 'type.googleapis.com/bess.pb.UnixSocketPortArg',
         'value': '\n\t/ajksd/dd'},
 'driver': 'UnixSocketPort',
 'name': 'p0'}
<--- CreatePortResponse
{'name': 'p0'}
==== /bess.pb.BESSControl/CreatePort
---> CreatePortRequest
{'arg': {'type_url': 'type.googleapis.com/bess.pb.VPortArg',
         'value': '\n\x05veth0\x18\xd4\xb4\x01*\x03\x01\x02\x030{8{J\x071.2.3.4J\x0f255.254.253.252'},
 'driver': 'VPort',
 'name': 'p0'}
<--- CreatePortResponse
{'name': 'p0'}
Channel status: ChannelConnectivity.READY -> ChannelConnectivity.TRANSIENT_FAILURE
Channel status: AbnormalDisconnection -> ChannelConnectivity.IDLE
ok
test_kill (pybess.test_bess.TestBESS) ... Channel status: None -> ChannelConnectivity.IDLE
Channel status: ChannelConnectivity.IDLE -> ChannelConnectivity.CONNECTING
Channel status: ChannelConnectivity.CONNECTING -> ChannelConnectivity.READY
==== /bess.pb.BESSControl/KillBess
---> EmptyRequest
<--- EmptyResponse
ok
test_list_modules (pybess.test_bess.TestBESS) ... Channel status: None -> ChannelConnectivity.IDLE
Channel status: ChannelConnectivity.IDLE -> ChannelConnectivity.READY
==== /bess.pb.BESSControl/ListModules
---> EmptyRequest
<--- ListModulesResponse
Channel status: ChannelConnectivity.READY -> ChannelConnectivity.TRANSIENT_FAILURE
ok
test_run_module_command (pybess.test_bess.TestBESS)Channel status: AbnormalDisconnection -> ChannelConnectivity.IDLE
 ... Channel status: None -> ChannelConnectivity.IDLE
Channel status: ChannelConnectivity.IDLE -> ChannelConnectivity.TRANSIENT_FAILURE
Channel status: ChannelConnectivity.TRANSIENT_FAILURE -> ChannelConnectivity.IDLE
�Traceback (most recent call last):
  File "/usr/lib/python2.7/runpy.py", line 174, in _run_module_as_main
    "__main__", fname, loader, pkg_name)
  File "/usr/lib/python2.7/runpy.py", line 72, in _run_code
    exec code in run_globals
  File "/usr/lib/python2.7/unittest/__main__.py", line 12, in <module>
    main(module=None)
  File "/usr/lib/python2.7/unittest/main.py", line 95, in __init__
    self.runTests()
  File "/usr/lib/python2.7/unittest/main.py", line 232, in runTests
    self.result = testRunner.run(self.test)
  File "/usr/lib/python2.7/unittest/runner.py", line 151, in run
    test(result)
  File "/usr/lib/python2.7/unittest/suite.py", line 70, in __call__
    return self.run(*args, **kwds)
  File "/usr/lib/python2.7/unittest/suite.py", line 108, in run
    test(result)
  File "/usr/lib/python2.7/unittest/suite.py", line 70, in __call__
    return self.run(*args, **kwds)
  File "/usr/lib/python2.7/unittest/suite.py", line 108, in run
    test(result)
  File "/usr/lib/python2.7/unittest/suite.py", line 70, in __call__
    return self.run(*args, **kwds)
  File "/usr/lib/python2.7/unittest/suite.py", line 108, in run
    test(result)
  File "/usr/lib/python2.7/unittest/case.py", line 393, in __call__
    return self.run(*args, **kwds)
  File "/usr/lib/python2.7/unittest/case.py", line 329, in run
    testMethod()
  File "/home/ddp/bess/pybess/test_bess.py", line 138, in test_run_module_command
    client.connect(port=self.PORT)
  File "/home/ddp/bess/pybess/bess.py", line 193, in connect
    time.sleep(0.1)
KeyboardInterrupt

sangjinhan · 2017-09-01T07:43:02Z

In my local setup, the test suite failed even without test_kill; test_list_modules succeeds but its next one fails...

With some investigation, I am fairly certain that it's a bug of grpc 1.6.0. If a channel has been closed by the server (self.server.stop()), in some conditions the client doesn't seem to create a new socket for subsequent channels but tries to reuse the already broken file descriptor (shutdown()ed but not close()ed).

#628 would work, but given that pip does not support maintaining multiple package versions, forcing a specific version of grpcio could interfere with other applications using the package.

As a (not ideal either) workaround, we can launch/terminate the dummy gRPC server per testcase (rather than per individual test), so that the channel is not disrupted by between every two tests. This can be done by simply switching setUp()/tearDown() to setUpClass()/tearDownClass().

codecov · 2017-09-01T21:41:16Z

Codecov Report

Merging #626 into master will increase coverage by <.01%.
The diff coverage is n/a.

@@            Coverage Diff            @@
##           master    #626      +/-   ##
=========================================
+ Coverage    69.3%   69.3%   +<.01%
=========================================
  Files         204     204
  Lines       13072   13078       +6
=========================================
+ Hits         9059    9064       +5
- Misses       4013    4014       +1

Impacted Files	Coverage Δ
core/modules/flowgen.cc	`73.7% <0%> (-0.38%)`	⬇️
pybess/test_bess.py	`100% <0%> (ø)`	⬆️
pybess/bess.py	`43.09% <0%> (+0.06%)`	⬆️
core/drivers/unix_socket.cc	`81.67% <0%> (+1.52%)`	⬆️

Continue to review full report at Codecov.

Legend - Click here to learn more
Δ = absolute <relative> (impact), ø = not affected, ? = missing data
Powered by Codecov. Last update 78c6c00...229392a. Read the comment docs.

chris3torek

This seems like the right fix, we get the statics and dynamics all listed separately now.

sangjinhan · 2017-09-04T02:06:58Z

ddiproietto mentioned this pull request Aug 30, 2017

Makefile: Use pkg-config if available. #618

Merged

sangjinhan mentioned this pull request Sep 1, 2017

Launch BESS daemon per testcase, not every test #629

Merged

chris3torek approved these changes Sep 1, 2017

View reviewed changes

sangjinhan merged commit 57497af into NetSys:master Sep 4, 2017

sangjinhan mentioned this pull request Sep 8, 2017

"undefined reference to '__dlopen'" in [TEST_LD]gate_test of building ''Daemon" #631

Closed

ddiproietto deleted the fix_makefile_ubuntu1604 branch September 8, 2017 19:05
