fix: polish LOD seam transitions

[MichaelFisher1997]

Summary

• Blend LOD boundary heights toward a coarse-aligned edge sample to reduce cracks at region seams while keeping the existing heightfield path.
• Use representative surface/water sampling for LOD quad materials and add seam diagnostics behind ZIGCRAFT_LOD_DIAG.
• Widen shader dither handoff and tune LOD mask/fog defaults for softer near/far transitions.

Fixes #687

Verification

• nix develop --command zig fmt modules/world-lod/src/lod_mesh.zig modules/world-lod/src/lod_chunk.zig
• nix develop --command zig build test
• nix develop --command zig build -Dskip-present
• nix develop --command zig build run -Dskip-present -Dauto-world=normal -Dstartup-diagnostic-seconds=5 timed out after 90s during startup/build output

[github-actions]

📋 Summary

Linked Issue: Fixes #687

This PR fully implements issue #687's requirements:

1. ✓ Adjacency-aware edge stitching via stitchedHeight() blending boundary samples toward coarse-aligned grid points
2. ✓ Dithered/faded LOD handoff in terrain.frag replacing chunk-based hard discard with distance-based dither fade (aligned with g_pass.frag); transition width widened from 24→32
3. ✓ Representative material sampling via representativeSurfaceBlock() (majority-vote over 4 cells) and representativeWaterDepth() (coverage-weighted average)
4. ✓ Tuned water/fog/mask — water threshold raised to 0.35 with depth exception, fog start percentages adjusted per level, overlap reduced from -1 to -2 chunks
5. ✓ Debug diagnostics via ZIGCRAFT_LOD_DIAG env flag logging max edge adjustment
6. ✓ Tests updated and added — calculateMaskRadius expectations updated, new tests for blockForLODQuad and stitchedHeight

Overall Quality: Well-scoped, focused PR with clean separation of concerns. No previous automated reviews to reconcile.

---

📌 Review Metadata

• Reviewed Commit SHA: 07006cd1ae4dac4fc6afd8cbb2a3b4971573c473
• Reviewed PR: fix: polish LOD seam transitions #693
• Linked Issues: Phase 1: polish LOD seams, fades, and representative sampling #687 — fully addressed per acceptance criteria

---

🔴 Critical Issues (Must Fix - Blocks Merge)

✅ All previously reported critical issues have been resolved.
None identified.

---

⚠️ High Priority Issues (Should Fix)

✅ All previously reported high priority issues have been resolved.
None identified.

---

💡 Medium Priority Issues (Nice to Fix)

None identified.

---

ℹ️ Low Priority Suggestions (Optional)

[LOW] modules/world-lod/src/lod_mesh.zig:723 — representativeSurfaceBlock tie-breaking undocumented
Confidence: High
Description: When two or more block types tie for majority count (e.g., 2 grass + 2 stone), the first one encountered in the nested loop wins. This is deterministic but arbitrary.
Impact: Minor — could produce inconsistent material selection at biome boundaries depending on loop order.
Suggested Fix: Add a brief comment explaining the tie-breaking behavior, or break ties using a secondary heuristic (e.g., prefer the block at the quad center).

[LOW] modules/world-lod/src/lod_mesh.zig:861 — stitchedHeight magic blend factor undocumented
Confidence: High
Description: The 0.35 multiplier in const blend = edge_weight * 0.35 controls maximum edge blend strength but has no explanatory comment.
Impact: Minor — future maintainers won't know why 0.35 was chosen or whether it's safe to tune.
Suggested Fix: Add a doc comment explaining that 0.35 caps the blend so the heightfield doesn't fully snap to coarse grid, preserving local detail while reducing seams.

---

📊 SOLID Principles Score

Principle	Score	Notes
Single Responsibility	8	Each new function (stitchedHeight, representativeSurfaceBlock, representativeWaterDepth, maxStitchedHeightAdjustment) has a single clear purpose.
Open/Closed	8	Extends LOD behavior without modifying core interfaces; diagnostics are opt-in via env flag.
Liskov Substitution	7	No inheritance used; changes are additive within existing struct behavior.
Interface Segregation	7	No new interfaces introduced; changes fit within existing ILODConfig and meshing patterns.
Dependency Inversion	7	Reuses existing abstractions (engine-core env flag, RHI types, TextureAtlas).
Average	7.4

---

🎯 Final Assessment

Overall Confidence Score: 88%

Confidence Breakdown:

• Code Quality: 90% — Clean, idiomatic Zig; proper allocator hygiene (defer vertices.deinit), consistent naming.
• Completeness: 90% — All issue Phase 1: polish LOD seams, fades, and representative sampling #687 acceptance criteria met; shaders, meshing, and config tuned cohesively.
• Risk Level: 15% — Changes are localized to LOD system; no RHI/Vulkan interface changes; fallback paths preserved.
• Test Coverage: 85% — Existing test updated, two new unit tests added. Could benefit from a visual/regression test but unit coverage is adequate.

Merge Readiness:

• All critical issues resolved
• SOLID average score >= 6.0
• Overall confidence >= 60%
• No security concerns
• Tests present and passing (if applicable)

Verdict:

MERGE

Low-priority documentation nits do not block merge; PR is clean, focused, and fully addresses linked issue #687.

{
  "reviewed_sha": "07006cd1ae4dac4fc6afd8cbb2a3b4971573c473",
  "critical_issues": 0,
  "high_priority_issues": 0,
  "medium_priority_issues": 0,
  "overall_confidence_score": 88,
  "recommendation": "MERGE"
}
