refactor: remove legacy lighting paths

[MichaelFisher1997]

Summary

• remove legacy entrance-bounce storage, propagation, mesh attributes, shader varyings, and debug controls
• remove unused PCSS and sun-shaft paths, and lock GPU meshing to the CPU fallback until parity is restored
• add terrain vertex ABI coverage, refresh SPIR-V artifacts/baselines, and document the production lighting architecture

Verification

• Zig 0.16.0 + SDL3 Dev Environment
  Compiler: 0.16.0
• Zig 0.16.0 + SDL3 Dev Environment
  Compiler: 0.16.0
  SPIR-V size: assets/shaders/vulkan/bloom_downsample.frag 9764 bytes (73ms compile)
  SPIR-V size: assets/shaders/vulkan/bloom_downsample.vert 1160 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/bloom_upsample.frag 3956 bytes (65ms compile)
  SPIR-V size: assets/shaders/vulkan/bloom_upsample.vert 1160 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/culling.comp 11352 bytes (66ms compile)
  SPIR-V size: assets/shaders/vulkan/debug_shadow.frag 836 bytes (67ms compile)
  SPIR-V size: assets/shaders/vulkan/debug_shadow.vert 1344 bytes (70ms compile)
  SPIR-V size: assets/shaders/vulkan/depth_pyramid.comp 2936 bytes (66ms compile)
  SPIR-V size: assets/shaders/vulkan/fxaa.frag 5916 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/fxaa.vert 1160 bytes (68ms compile)
  SPIR-V size: assets/shaders/vulkan/g_pass.frag 6912 bytes (67ms compile)
  SPIR-V size: assets/shaders/vulkan/lpv_inject.comp 4844 bytes (67ms compile)
  SPIR-V size: assets/shaders/vulkan/lpv_propagate.comp 8316 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/mesh.comp 45244 bytes (70ms compile)
  SPIR-V size: assets/shaders/vulkan/post_process.frag 10856 bytes (71ms compile)
  SPIR-V size: assets/shaders/vulkan/post_process.vert 1160 bytes (85ms compile)
  SPIR-V size: assets/shaders/vulkan/shadow.frag 1592 bytes (78ms compile)
  SPIR-V size: assets/shaders/vulkan/shadow.vert 4596 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/sky.frag 18980 bytes (74ms compile)
  SPIR-V size: assets/shaders/vulkan/sky.vert 2696 bytes (67ms compile)
  SPIR-V size: assets/shaders/vulkan/ssao_blur.frag 1760 bytes (72ms compile)
  SPIR-V size: assets/shaders/vulkan/ssao.frag 6588 bytes (70ms compile)
  SPIR-V size: assets/shaders/vulkan/ssao.vert 1160 bytes (67ms compile)
  SPIR-V size: assets/shaders/vulkan/taa.frag 9760 bytes (73ms compile)
  SPIR-V size: assets/shaders/vulkan/taa.vert 1160 bytes (73ms compile)
  SPIR-V size: assets/shaders/vulkan/terrain_debug.frag 1336 bytes (73ms compile)
  SPIR-V size: assets/shaders/vulkan/terrain.frag 63108 bytes (73ms compile)
  SPIR-V size: assets/shaders/vulkan/terrain.vert 10500 bytes (64ms compile)
  SPIR-V size: assets/shaders/vulkan/ui.frag 744 bytes (71ms compile)
  SPIR-V size: assets/shaders/vulkan/ui_tex.frag 1408 bytes (70ms compile)
  SPIR-V size: assets/shaders/vulkan/ui_tex.vert 1344 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/ui.vert 1336 bytes (68ms compile)
  SPIR-V size: assets/shaders/vulkan/water.frag 22164 bytes (69ms compile)
  SPIR-V size: assets/shaders/vulkan/water.vert 8796 bytes (66ms compile)
  assets/shaders/vulkan/bloom_downsample.vert
  assets/shaders/vulkan/bloom_upsample.vert
  assets/shaders/vulkan/debug_shadow.vert
  assets/shaders/vulkan/fxaa.vert
  assets/shaders/vulkan/post_process.vert
  assets/shaders/vulkan/shadow.vert
  assets/shaders/vulkan/sky.vert
  assets/shaders/vulkan/ssao.vert
  assets/shaders/vulkan/taa.vert
  assets/shaders/vulkan/terrain.vert
  assets/shaders/vulkan/ui_tex.vert
  assets/shaders/vulkan/ui.vert
  assets/shaders/vulkan/water.vert
  assets/shaders/vulkan/bloom_downsample.frag
  assets/shaders/vulkan/bloom_upsample.frag
  assets/shaders/vulkan/debug_shadow.frag
  assets/shaders/vulkan/fxaa.frag
  assets/shaders/vulkan/g_pass.frag
  assets/shaders/vulkan/post_process.frag
  assets/shaders/vulkan/shadow.frag
  assets/shaders/vulkan/sky.frag
  assets/shaders/vulkan/ssao_blur.frag
  assets/shaders/vulkan/ssao.frag
  assets/shaders/vulkan/taa.frag
  assets/shaders/vulkan/terrain_debug.frag
  assets/shaders/vulkan/terrain.frag
  assets/shaders/vulkan/ui.frag
  assets/shaders/vulkan/ui_tex.frag
  assets/shaders/vulkan/water.frag
  assets/shaders/vulkan/culling.comp
  assets/shaders/vulkan/depth_pyramid.comp
  assets/shaders/vulkan/lpv_inject.comp
  assets/shaders/vulkan/lpv_propagate.comp
  assets/shaders/vulkan/mesh.comp
  Shadow ABI reflection: 4 matrices, 352-byte block, offsets 0/256/272/288/304/320/336
• Zig 0.16.0 + SDL3 Dev Environment
  Compiler: 0.16.0
• Zig 0.16.0 + SDL3 Dev Environment
  Compiler: 0.16.0
• Zig 0.16.0 + SDL3 Dev Environment
  Compiler: 0.16.0
  assets/shaders/vulkan/bloom_downsample.vert
  assets/shaders/vulkan/bloom_upsample.vert
  assets/shaders/vulkan/debug_shadow.vert
  assets/shaders/vulkan/fxaa.vert
  assets/shaders/vulkan/post_process.vert
  assets/shaders/vulkan/shadow.vert
  assets/shaders/vulkan/sky.vert
  assets/shaders/vulkan/ssao.vert
  assets/shaders/vulkan/taa.vert
  assets/shaders/vulkan/terrain.vert
  assets/shaders/vulkan/ui_tex.vert
  assets/shaders/vulkan/ui.vert
  assets/shaders/vulkan/water.vert
  assets/shaders/vulkan/bloom_downsample.frag
  assets/shaders/vulkan/bloom_upsample.frag
  assets/shaders/vulkan/debug_shadow.frag
  assets/shaders/vulkan/fxaa.frag
  assets/shaders/vulkan/g_pass.frag
  assets/shaders/vulkan/post_process.frag
  assets/shaders/vulkan/shadow.frag
  assets/shaders/vulkan/sky.frag
  assets/shaders/vulkan/ssao_blur.frag
  assets/shaders/vulkan/ssao.frag
  assets/shaders/vulkan/taa.frag
  assets/shaders/vulkan/terrain_debug.frag
  assets/shaders/vulkan/terrain.frag
  assets/shaders/vulkan/ui.frag
  assets/shaders/vulkan/ui_tex.frag
  assets/shaders/vulkan/water.frag
  assets/shaders/vulkan/culling.comp
  assets/shaders/vulkan/depth_pyramid.comp
  assets/shaders/vulkan/lpv_inject.comp
  assets/shaders/vulkan/lpv_propagate.comp
  assets/shaders/vulkan/mesh.comp

Refs #904

[github-actions]

kcov coverage

Line coverage ran for this PR and uploaded a non-blocking report artifact named kcov-report. Codecov upload is configured as non-blocking while the project captures a stable baseline.

[github-actions]

📋 Summary

PR #910 references #904 ([Lighting Overhaul][Phase 5] Remove legacy paths and enforce regression gates). This PR implements a subset of that issue: it removes the legacy entrance-bounce lighting storage, propagation, mesh attributes, shader varyings, and debug controls; drops unused PCSS and sun-shaft code paths; locks GPU meshing to the CPU fallback; adds a terrain vertex ABI test; refreshes SPIR-V artifacts; and documents the production lighting architecture.

It does not fully close #904: acceptance items like deterministic visual regression captures, benchmark thresholds, and preset tuning are not included in this change. The PR scope is accurately described in the title/body, so leaving #904 open is appropriate.

nix develop --command zig build test passes with exit code 0, and no remaining references to the removed symbols (entrance_bounce, entrance_dir, light_size, sun_shafts, DEBUG_ENTRANCE_BOUNCE) were found in the tree.

📌 Review Metadata

• Reviewed Commit SHA: 724310c47bcacfaf33c0d14ab60acd735977ee4f
• Reviewed PR: refactor: remove legacy lighting paths #910
• Linked Issue: [Lighting Overhaul][Phase 5] Remove legacy paths and enforce regression gates #904 (partially addressed; not fully resolved)

This is a focused cleanup/refactor: 120 insertions, 926 deletions across 50 files. The shader/CPU vertex contract stays aligned, and the new docs/lighting-architecture.md plus the terrain vertex ABI remains tightly packed test provide useful regression protection.

🔴 Critical Issues (Must Fix - Blocks Merge)

None identified.

⚠️ High Priority Issues (Should Fix)

None identified.

💡 Medium Priority Issues (Nice to Fix)

None identified.

ℹ️ Low Priority Suggestions (Optional)

None identified.

📊 SOLID Principles Score

Principle	Score	Notes
Single Responsibility	9	Removes orthogonal responsibilities (entrance bounce, PCSS, sun shafts) from lighting, meshing, and settings modules.
Open/Closed	7	Mostly deletion; the vertex ABI test freezes the CPU-side contract, which is appropriate for a stabilization phase.
Liskov Substitution	8	Interface changes (ShadowParams, Vertex, DebugLightInfo) are propagated consistently across all implementers and tests.
Interface Segregation	8	ShadowParams and FrameRenderParams are slimmed; settings no longer carry dead toggles.
Dependency Inversion	7	No new abstractions introduced; existing RHI contracts remain the boundary.
Average	7.8

🎯 Final Assessment

Overall Confidence Score: 85%

Confidence Breakdown:

• Code Quality: 85% (clean deletions, consistent renames, shader/CPU ABI aligned, tests updated)
• Completeness: 70% (fulfills the stated PR scope, but only a partial step toward [Lighting Overhaul][Phase 5] Remove legacy paths and enforce regression gates #904's full acceptance criteria)
• Risk Level: 30% (removes code paths, but GPU meshing is explicitly disabled and the fallback is production-tested)
• Test Coverage: 80% (relevant unit tests updated, new ABI test added, shader validation passes)

Merge Readiness:

• All critical issues resolved
• SOLID average score >= 6.0
• Overall confidence >= 60%
• No security concerns
• Tests present and passing

Verdict:

MERGE — The PR is a clean, well-scoped refactor that removes dead lighting paths, keeps the production vertex/shader contract consistent, and passes the full test suite including shader validation.

{
  "reviewed_sha": "724310c47bcacfaf33c0d14ab60acd735977ee4f",
  "critical_issues": 0,
  "high_priority_issues": 0,
  "medium_priority_issues": 0,
  "overall_confidence_score": 85,
  "recommendation": "MERGE"
}
