Reveal SDK Node.js & Cube.dev REST API Example

This repository demonstrates how to integrate the Reveal SDK with a Cube.dev REST API endpoint using a Node.js backend server. It includes:

1. A Node.js/Express server that acts as the backend for the Reveal SDK, handling data source definition and authentication for a Cube.dev REST API.
2. A simple HTML client that embeds the Reveal SDK web component and configures it to use the Node.js server.

Video

Features

• Node.js backend implementation for Reveal SDK (reveal-sdk-node).
• Connects to a Cube.dev REST API endpoint as a data source.
• Dynamically generates the Cube.dev REST API URL based on predefined dimensions and measures.
• Includes a placeholder for Bearer Token authentication required by Cube.dev's REST API.
• Provides a basic HTML/JavaScript client showing how to embed and configure the RevealView.
• Configures the client-side Reveal SDK to recognize the custom "Cube.dev" REST data source defined on the server.
• Starts the RevealView in edit mode (startInEditMode = true).

Prerequisites

• Node.js and npm (or yarn): Required to run the server application. Download from https://nodejs.org/.
• Cube.dev Deployment: You need a running Cube.dev instance with the REST API enabled.
• Cube.dev REST API Endpoint URL: The base URL for your Cube.dev REST API (e.g., https://your-instance.cubecloudapp.dev/cubejs-api/v1/load).
• Cube.dev Bearer Token: A valid Bearer token to authenticate requests to your Cube.dev REST API. You can usually generate this within your Cube Cloud deployment settings or configure it in your self-hosted Cube.js setup.

Setup and Installation

1. Clone the repository:

   git clone <your-repository-url>
   cd <repository-directory>

2. Install dependencies: Navigate to the directory containing package.json (likely the root or a server sub-directory) and run:

   npm install
   # or
   # yarn install

Configuration

You must configure the server before running the application:

1. Edit the Server File (e.g., server.js or app.js):

   • Bearer Token: Locate the authenticationProvider function and replace the placeholder string "Enter Your Bearer Token Here" with your actual Cube.dev REST API Bearer token:

     const authenticationProvider = async (userContext, dataSource) => {
         // ********** UPDATE THIS LINE **********
         return new reveal.RVBearerTokenDataSourceCredential("YOUR_ACTUAL_CUBE_DEV_BEARER_TOKEN");
         // *************************************
     }

   • (Optional) Cube.dev URL & Query: If your Cube.dev REST API base URL or the specific query (dimensions/measures) you want to use differs from the example, update the generateUrl function accordingly:

     const generateUrl = () => {
         // ********** UPDATE IF NEEDED **********
         const baseUrl = '[https://your-instance.cubecloudapp.dev/cubejs-api/v1/load](https://your-instance.cubecloudapp.dev/cubejs-api/v1/load)'; // Update Base URL
         const queryData = {
           "dimensions": [ /* Your Dimensions */ ],
           "measures": [ /* Your Measures */ ]
         };
         // *************************************
         const queryString = JSON.stringify(queryData);
         const encodedQuery = encodeURIComponent(queryString);
         const url = `${baseUrl}?query=${encodedQuery}`;
         return url;
     }

2. Verify Client Configuration (e.g., index.html):

   • Ensure the $.ig.RevealSdkSettings.setBaseUrl(...) call points to the correct address and port where your Node.js server will be running (default is http://localhost:5111/).

Running the Application

1. Start the Node.js Server: From your terminal, in the directory with the server file, run:

   node server.js
   # Or your specific server entry point file

   You should see the message: Reveal server accepting http requests

2. Open the HTML Client: Open the index.html file (or your client HTML file) in your web browser. You can usually do this by double-clicking the file or using a simple local web server extension if needed (like VS Code's Live Server).

   The Reveal SDK component should load, starting in edit mode. When you attempt to add a new visualization and select the "Cube.dev" data source, the client will communicate with the Node.js backend, which will provide the configured Cube.dev URL and authentication token to fetch the data.

How it Works

1. Client Initialization: The index.html page loads the Reveal SDK JS library and initializes RevealView. It sets the backend URL (setBaseUrl) to point to the Node.js server.
2. Data Source Definition (Client): The onDataSourcesRequested callback on the client defines the type of data source available in the UI. It creates a RVRESTDataSource instance named "Cube.dev". This tells the Reveal UI to show this option, but the actual connection details are handled server-side.
3. Data Request: When the user selects the "Cube.dev" data source in the Reveal UI, the client SDK sends a request to the Node.js backend.
4. Server-Side Providers:
   • dataSourceProvider: Intercepts the request for the REST data source. It calls generateUrl to get the specific Cube.dev REST API endpoint URL (including the query) and assigns it to the dataSource.url property.
   • authenticationProvider: Intercepts the request and provides the necessary RVBearerTokenDataSourceCredential containing the Cube.dev Bearer token.
   • dataSourceItemProvider: Ensures the URL from the dataSource is correctly applied to the specific dataSourceItem being processed.
5. Data Fetching: The Reveal SDK backend (running within the Node.js server) uses the provided URL and credentials to make the actual HTTP request to the Cube.dev REST API.
6. Visualization: Reveal SDK processes the response from Cube.dev and renders the data within the RevealView component on the client.

Important Notes

• CORS: The server uses app.use(cors()); without specific origin configuration. This is generally unsafe for production. In a production environment, configure the cors middleware to allow requests only from your specific frontend application's domain.
• Security: The Cube.dev Bearer token is currently hardcoded in the server file. For production, never hardcode sensitive credentials. Use environment variables, secrets management systems (like AWS Secrets Manager, Azure Key Vault, HashiCorp Vault), or other secure configuration methods.
• Hardcoded Query: The generateUrl function uses a fixed Cube.dev query. In a real application, you might want to make this more dynamic based on user context or UI selections.
• Error Handling: The provided code has minimal error handling. Robust applications should include proper error handling for network requests, authentication failures, and unexpected data formats.
