SpeQL is an API Spec Query Analyser that uses CodeQL and a built-in Python analyzer to scan Azure REST API specifications for security vulnerabilities — including SAS URI exposure, Key Vault misconfigurations, missing access control, and exposed credentials.
SpeQL is the engine that feeds APISpy — it exports a structured index of every Azure REST API operation, which APISpy uses for real-time request classification in the browser.
SilentReaper is a vulnerability class characterized by an API emitting a SAS URI in its response, which becomes dangerous when combined with improper RBAC or inadequate control/data plane isolation.
- Quick Start with CLI Menu
- Tools Overview
- Vulnerabilities Detected
- Repository Structure
- Multi-Source Architecture
- Smart Memory Management
- Installation
- Usage
- Database Management
- Export Pipeline
- Query Details
- Ecosystem
- Contributing
- License
# Install dependencies
pip3 install -r requirements.txt
# Launch the interactive CLI menu
python3 SpeQL.py
The CLI menu provides:
- Intuitive navigation - Browse all actions organised by category
- Interactive prompts - Step-by-step guidance for complex operations
- ASCII art logo - SpeQL branding via figlet (falls back gracefully if not installed)
- Comprehensive coverage - Access to all scripts and tools
- Smart memory management - Automatic CodeQL memory optimisation for large databases
- 📊 Security Analysis - Run security scans on Azure API specifications
- 🗄️ Database Management - Clone, update, and rebuild the CodeQL database
- 🔍 CodeQL Security Queries - Execute CodeQL queries and view results
- 📈 SARIF Analysis Tools - Analyse SARIF output for threat hunting
- ⚙️ Setup and Installation - Automated setup and dependency management
- 📚 Documentation and Help - Access guides and documentation
- ℹ️ About SpeQL - Learn about the tool and its capabilities
For automation or scripting, use the individual scripts directly:
python3 analyze.py # Run security analysis
python3 refresh_database.py # Update database
./run-queries.sh # Run CodeQL queries| Tool | Entry Point | Description |
|---|---|---|
| Interactive CLI | SpeQL.py |
Menu-driven interface for all SpeQL actions |
| Python Security Analyzer | analyze.py |
Standalone scanner; no CodeQL required; detects insecure Logic App triggers, Key Vault misconfigs, missing access control, hardcoded credentials |
| CodeQL Queries | queries/azure-security/ |
8 queries detecting SAS URI exposure, exposed tokens, proxy invocation, Logic App secrets, hardcoded ARM secrets, sensitive GET responses, control-plane bypass, and obfuscated secrets |
| Database Refresh | refresh-database.sh · refresh_database.py |
Clone and build a CodeQL database from the Azure REST API spec corpus |
| SARIF Analysis Tools | scripts/sarif-analysis/ |
Shell scripts for deduplicating, parsing, and prioritising CodeQL findings |
| Export Pipeline | scripts/export/export_api_inventory.py |
Walks the spec corpus and produces a structured JSON index of every Azure REST API operation, published to APISpy via GitHub Releases |
Detects Logic App HTTP triggers that can be invoked without authentication:
- Missing authentication configuration
- Weak authentication (None/Anonymous)
- Public HTTP endpoints without access control
CWE References: CWE-306 (Missing Authentication), CWE-862 (Missing Authorization)
Identifies Key Vault misconfigurations that expose secrets:
- Missing network restrictions
- Public network access enabled
- Overly permissive access policies
- Embedded secrets instead of Key Vault references
CWE References: CWE-284 (Improper Access Control), CWE-522 (Insufficiently Protected Credentials)
Finds API endpoints without proper security:
- Sensitive operations (DELETE, CREATE, UPDATE) without authentication
- Endpoints with empty security arrays
- Public workflow access without restrictions
CWE References: CWE-284, CWE-862
Locates hardcoded credentials and secrets:
- Connection strings with embedded passwords
- Hardcoded API keys and secrets
- Basic authentication with visible passwords
- Secure strings with default values
CWE References: CWE-798 (Hardcoded Credentials), CWE-259 (Hard-coded Password)
The CodeQL query (SasUriInResponse.ql) detects Azure Shared Access Signature (SAS) URIs in API example responses:
- SAS tokens in response bodies (
inputsLink,outputsLink, etc.) - URIs containing signature parameters (
sig,se,sp,sv) - Control-plane APIs exposing data-plane access credentials
Security Impact: SAS URIs grant time-limited access to Azure resources. When exposed in control-plane API responses with improper RBAC or inadequate control/data plane isolation, they can enable unauthorised data-plane access and data exfiltration. This is the defining characteristic of a SilentReaper vulnerability.
CWE References: CWE-200 (Exposure of Sensitive Information), CWE-359
The CodeQL query (ExposedSasTokens.ql) detects pre-authenticated SAS URIs or tokens in example payloads or JSON strings containing signature material (sig, sv).
CWE References: CWE-200, CWE-522
The CodeQL query (ProxyAndDynamicInvocation.ql) identifies bridge endpoints in management-plane specs that allow callers to proxy arbitrary requests to backend services, bypassing intended isolation.
CWE References: CWE-441, CWE-610
The CodeQL query (MissingLogicAppSecureData.ql) detects Logic App workflow definitions where sensitive inputs or outputs are not secured via runtimeConfiguration.secureData.
CWE References: CWE-312, CWE-532
The CodeQL query (HardcodedSecretsInArm.ql) detects ARM template parameters typed as securestring that include a plaintext default value.
CWE References: CWE-312, CWE-798
The CodeQL query (SensitiveDataInGetResponse.ql) flags GET operations that return credential-named properties without x-ms-secret: true.
CWE References: CWE-200, CWE-359
The CodeQL query (ControlPlaneBypass.ql) scans data-plane specs for resource management operations that should be restricted to the management plane.
CWE References: CWE-284, CWE-269
The CodeQL query (Base64EncodedSecrets.ql) searches for high-entropy or base64-encoded strings that may mask obfuscated secrets in API examples or schema definitions.
CWE References: CWE-312, CWE-522
UndREST-SpecQL/
├── README.md
├── CONTRIBUTING.md
├── LICENSE
├── SpeQL.py # Interactive CLI menu entry point
├── setup.sh # Automated setup script
├── refresh-database.sh # Bash script to refresh/clone a spec source and build the DB
├── refresh_database.py # Python script (same, cross-platform)
├── analyze.py # Python-based security analyzer (no CodeQL required)
├── run-queries.sh # CodeQL query execution script
├── config/
│ ├── SpeQL.yml # CodeQL database configuration
│ └── sources/ # Source registry — one JSON file per API spec source
│ └── azure.json # Azure REST API Specifications source definition
├── database/ # CodeQL database(s) (generated)
│ └── azure-api-db/
├── demos/ # Demo GIFs (01–07)
├── docs/ # Documentation
│ ├── ADDING_API_SOURCES.md # Guide for adding new API spec sources
│ ├── CODEQL_WORKFLOW.md
│ ├── DATABASE_REFRESH.md
│ ├── EXAMPLE_OUTPUT.md
│ ├── MEMORY_MANAGEMENT.md
│ ├── QUICKSTART.md
│ ├── QUICK_REFERENCE.md
│ ├── REPOSITORY_STRUCTURE.md
│ ├── SARIF_ANALYSIS_QUICKSTART.md
│ └── inventory/
│ ├── API_INDEX_SCHEMA.md
│ ├── CONSUMER_GUIDE.md
│ └── EXPORT_PIPELINE.md
├── inventory/ # Export artifacts (generated)
│ └── api-index-sharded-<run-id>.zip
├── queries/ # CodeQL queries — one subdirectory per platform
│ ├── README.md # How to add queries for a new platform
│ └── azure-security/
│ ├── SasUriInResponse.ql # Detects SAS URIs in API example responses
│ ├── ExposedSasTokens.ql # Detects pre-authenticated SAS tokens in example payloads
│ ├── ProxyAndDynamicInvocation.ql # Identifies bridge endpoints enabling cross-service access
│ ├── MissingLogicAppSecureData.ql # Detects Logic App workflows without secure data settings
│ ├── HardcodedSecretsInArm.ql # Detects securestring ARM params with plaintext defaults
│ ├── SensitiveDataInGetResponse.ql # Flags GET responses returning unprotected credential properties
│ ├── ControlPlaneBypass.ql # Detects management ops exposed on data-plane paths
│ ├── Base64EncodedSecrets.ql # Detects obfuscated secrets encoded as base64
│ └── qlpack.yml
├── results/ # Analysis results (generated)
├── scripts/
│ ├── export/ # API inventory export pipeline
│ │ ├── export_api_inventory.py
│ │ └── normalize_api_inventory.py
│ └── sarif-analysis/ # SARIF analysis and threat hunting tools
│ ├── deduplicate-by-product-operation.sh
│ ├── parse-sarif-endpoints.sh
│ ├── prioritize-threats.sh
│ └── README.md
├── tests/
│ ├── test_api_inventory_export.py
│ ├── test_api_inventory_normalization.py
│ ├── test_json_file_count_fix.sh
│ ├── test_memory_management.sh
│ └── vhs/ # VHS tape recordings for animated GIF demos (01–07)
└── utils/
└── memory_utils.sh # Memory management utilities
SpeQL is designed to work with any OpenAPI/Swagger spec corpus, not just
azure-rest-api-specs. Adding support for a new API platform requires only:
- A source config file (
config/sources/<platform>.json) — declares the upstream repository URL, local directory names, and metadata. - Optionally, platform-specific CodeQL queries (
queries/<platform>-security/).
All scripts and workflows accept a --source-config flag:
# Refresh using a custom source
python3 refresh_database.py --source-config config/sources/my-platform.json --all --skip-db-build
# Export API inventory for a custom source
python3 scripts/export/export_api_inventory.py \
--source my-platform-api-specs/specification \
--source-repo MyOrg/my-platform-api-specsSee docs/ADDING_API_SOURCES.md for the complete guide.
SpeQL includes intelligent memory management for CodeQL query execution.
- Automatic Detection: Detects total system memory on Linux and macOS
- Smart Optimisation: Applies memory limits (90% of total RAM) for databases with >50K JSON files
- Manual Override: Set custom limits via
CODEQL_MEMORY_LIMITenvironment variable
./run-queries.sh # Automatic
export CODEQL_MEMORY_LIMIT=4096 && ./run-queries.sh # ManualFor detailed information, see docs/MEMORY_MANAGEMENT.md.
./setup.sh
This installs Java Development Kit, CodeQL CLI 2.20.2, and all required CodeQL query pack dependencies.
# Ubuntu/Debian
sudo apt-get install openjdk-17-jdk
java -versionImportant: CodeQL 2.23.x+ has compatibility issues with JSON-only databases. Use 2.20.1 or 2.20.2.
wget https://github.com/github/codeql-cli-binaries/releases/download/v2.20.2/codeql-linux64.zip
unzip codeql-linux64.zip
export PATH="$PATH:$(pwd)/codeql"
# Install query pack dependencies
cd queries/azure-security && codeql pack install && cd ../..
codeql version
./run-queries.shpip3 install -r requirements.txtpip3 install pytest
python3 -m pytest tests/test_api_inventory_export.py tests/test_api_inventory_normalization.py -vpython3 analyze.py
# Verbose mode
python3 analyze.py --verbose
# Specific Azure service
python3 analyze.py --source azure-rest-api-specs/specification/keyvault
# All Azure services (after cloning with --all)
python3 analyze.py --source azure-rest-api-specs/specification
# Build database then run queries
python3 refresh_database.py --path specification/keyvault --fresh
./run-queries.shResults are saved in SARIF format in results/ and can be viewed in VS Code (SARIF Viewer extension) or uploaded to GitHub Advanced Security.
# Deduplicate findings
./scripts/sarif-analysis/deduplicate-by-product-operation.sh results/SasUriInResponse-results.sarif
# Extract structured endpoint data as CSV
./scripts/sarif-analysis/parse-sarif-endpoints.sh -f csv results/SasUriInResponse-results.sarif
# Prioritise by severity
./scripts/sarif-analysis/prioritize-threats.sh --threshold high results/SasUriInResponse-results.sarifSee scripts/sarif-analysis/README.md for full documentation.
# Update and rebuild (default: Azure Logic Apps)
./refresh-database.sh
# Use a specific source config
./refresh-database.sh --source-config config/sources/azure.json
# Fresh clone
./refresh-database.sh --fresh
# Specific service path within the source
./refresh-database.sh --path specification/keyvault
# All specifications in the source
./refresh-database.sh --all
# Repo only (no CodeQL build)
./refresh-database.sh --skip-db-build
For full documentation, see docs/DATABASE_REFRESH.md. To add a new API source, see docs/ADDING_API_SOURCES.md.
The export pipeline walks any OpenAPI/Swagger spec directory and produces a structured JSON index of every REST API operation.
# Azure (default)
python3 scripts/export/export_api_inventory.py \
--source azure-rest-api-specs/specification \
--output-dir inventory/ \
--sharded --minified --verbose
# Custom source
python3 scripts/export/export_api_inventory.py \
--source my-platform-api-specs/specification \
--source-repo MyOrg/my-platform-api-specs \
--output-dir inventory/ \
--sharded --minified --verboseOutput formats:
api-index.json— Flat pretty-printed indexapi-index-grouped.json— Grouped/deduplicated (schema 3.0.0)shards/{Provider.Namespace}.min.json— Per-provider shards for APISpy
Cross-repo pipeline: The daily-api-index-export-sharded.yml workflow runs nightly, publishes the sharded zip to the shards-latest GitHub Release, and triggers UndREST-APISpy to update its extension shard data automatically.
See docs/inventory/EXPORT_PIPELINE.md for the full schema and consumer guide.
| Attribute | Value |
|---|---|
| ID | azure/sas-uri-in-response |
| Severity | Error |
| Security Severity | 8.5 |
| Precision | High |
| CWE | CWE-200, CWE-359 |
Detects API specs that emit Azure Shared Access Signature (SAS) URIs in API responses. SAS URIs contain sensitive tokens granting time-limited access to Azure resources. This is the defining characteristic of a SilentReaper vulnerability — an API emitting a SAS URI in its response, which becomes dangerous with improper RBAC or inadequate control/data plane isolation.
| Attribute | Value |
|---|---|
| ID | azure/exposed-sas-tokens |
| Severity | Error |
| Security Severity | 8.5 |
| Precision | High |
| CWE | CWE-200, CWE-522 |
Detects pre-authenticated SAS URIs or tokens found in example payloads or JSON strings. These contain sensitive signature material (sig, sv) along with scope or expiry parameters that, if exposed, can grant unauthorized access to Azure resources.
| Attribute | Value |
|---|---|
| ID | azure/proxy-dynamic-invocation |
| Severity | Warning |
| Security Severity | 7.5 |
| Precision | Medium |
| CWE | CWE-441, CWE-610 |
Identifies "bridge" endpoints in management-plane specs that allow callers to proxy arbitrary requests to backend services, potentially bypassing intended isolation and enabling unauthorized cross-service access.
| Attribute | Value |
|---|---|
| ID | azure/missing-logic-app-secure-data |
| Severity | Error |
| Security Severity | 7.0 |
| Precision | Medium |
| CWE | CWE-312, CWE-532 |
Detects Logic App workflow definitions where sensitive inputs or outputs are not secured via runtimeConfiguration.secureData, potentially exposing secrets in run history and execution logs.
| Attribute | Value |
|---|---|
| ID | azure/hardcoded-secrets-arm |
| Severity | Error |
| Security Severity | 9.0 |
| Precision | High |
| CWE | CWE-312, CWE-798 |
Detects ARM template parameters typed as securestring that inadvertently include a plaintext default value. Such defaults are stored in cleartext in deployment logs and template history, defeating the purpose of the secure type.
| Attribute | Value |
|---|---|
| ID | azure/sensitive-data-in-get-response |
| Severity | Error |
| Security Severity | 8.0 |
| Precision | Medium |
| CWE | CWE-200, CWE-359 |
Flags GET operations that return properties whose names suggest credentials (keys, tokens, secrets, passwords, connection strings) but are not annotated with the mandatory x-ms-secret: true extension, risking unintended exposure of sensitive data.
| Attribute | Value |
|---|---|
| ID | azure/control-plane-bypass |
| Severity | Warning |
| Security Severity | 7.0 |
| Precision | Low |
| CWE | CWE-284, CWE-269 |
Scans data-plane specifications for resource management operations (e.g., creating deployments, accounts, or configurations) that should typically be restricted to the management plane. Such paths may enable unauthorized resource lifecycle control.
| Attribute | Value |
|---|---|
| ID | azure/base64-encoded-secret |
| Severity | Warning |
| Security Severity | 6.5 |
| Precision | Low |
| CWE | CWE-312, CWE-522 |
Searches for high-entropy strings or fields explicitly formatted as base64-encoded bytes that may mask obfuscated secrets within API examples or schema definitions.
SpeQL is part of the UndREST Labs ecosystem:
| Project | Repo | Description |
|---|---|---|
| SpeQL | (this repo) | Query and reason about API behaviour; the engine that feeds APISpy |
| APISpy | UndREST-APISpy | Real-time visibility into API calls in the browser; powered by SpeQL exports |
| Atlas | (future) | Mapping API ecosystems at scale |
Observe → Understand → Map → Evolve
This repository uses cARL — a version-controlled governance layer for AI coding agents. cARL artefacts are committed under .github/carl/ and provide:
- Durable memory —
.github/carl/memory.mdcaptures SpecQL's architecture, security invariants, and canonical test commands so future agent sessions start with full context. - PR contracts —
.github/carl/current-pr-contract.mdconstrains each PR's approved scope, forbidden changes, and stop conditions. - Instruction packs —
.github/instructions/packs load per-language and per-domain governance (Python, Azure, CI/CD, security) automatically into every Copilot agent session.
# Install the cARL CLI
# Latest release and platform-specific install instructions:
# https://github.com/goldjg/cARL/releases/latest
# QuickStart (Linux, macOS, Windows):
# https://github.com/goldjg/cARL#quickstart
# Verify installation
carl version
# Check runtime health
carl doctor
# Repair drifted artefacts (never overwrites memory.md)
carl repairAI agents working in this repo: hydrate
.github/carl/memory.mdbefore planning. Do not change product code, query logic, or generated artefacts unless explicitly within the active PR contract.
See CONTRIBUTING.md for guidelines on adding new security queries, improving existing ones, and contributing to the export pipeline.
For APISpy (extension, portal sweep, shard preparation), see UndREST-APISpy.
See LICENSE.
