pipe-in ( ⇥ )

Let the HTML stream.

Attribute-based wrapper around the browser's partial update support.

Canonical attribute

<article
    pipe-in=https://link.springer.com/article/10.1007/s00300-003-0563-3 pipe-in-shadowrootmode=open>
    <span slot="AdInsert"><a href="https://www.target.com/b/pedialax/-/N-55lp4">Pedia-Lax</a></span>
</article>

For well controlled environments, for example within a carefully managed custom element registry, where namespace clashes are easy to avoid:

<article
    ⇥=https://link.springer.com/article/10.1007/s00300-003-0563-3 ⇥-shadowrootmode=open>
    <span slot="AdInsert"><a href="https://www.target.com/b/pedialax/-/N-55lp4">Pedia-Lax</a></span>
</article>

In what follows, we will refer to the "base". In the examples above, the base is pipe-in and ⇥ respectively.

Defaults

As the article linked to above indicates, there are quite a number of choices we can make as far as streaming in content.

The following table indicates the default values and how to override.

Name	Default	Override
Method	streamHTML	[base]-method=streamHTML | streamReplaceWithHTML | streamBeforeHTML | streamPrependHTML | streamAppendHTML | streamAfterHTML | streamHTMLUnsafe | streamReplaceWithHTMLUnsafe | streamBeforeHTMLUnsafe | streamPrependHTMLUnsafe | streamAppendHTMLUnsafe | streamAfterHTMLUnsafe
Sanitizer	Default	[base]-sanitizer='{"elements": ["em", "i", "b", "strong"]}'
Script support	No support	[base]-run-scripts
Shadow root mode	None	[base]-shadowrootmode=open | closed
URL rewriting	Off	[base]-base
Cache policy	default	[base]-cache=default | no-store | reload | no-cache | force-cache | only-if-cached
Stream sharing	Enabled	[base]-no-share (disables sharing)

Note: The default sanitizer (used by streamHTML and other non-Unsafe methods) strips elements like <link>, <img>, <script>, and <style>. If you need these elements preserved, use one of the *Unsafe methods or pass a custom sanitizer configuration.

Security

Allowing attributes to specify such things as "run scripts", or specifying allowed elements is a potential xss security concern. Even utilizing unsafe methods must be constrained. To mitigate that risk, these options are only allowed if:

1. The URL is a same-origin path (starts with /), or
2. The URL is a bare specifier with a mapping in an import map

Cross-origin absolute URLs (starting with http:// or https://) are restricted to the default streamHTML method with the default sanitizer and no script execution.

<script type=importmap>
{
    "imports": {
        "springer/": "https://link.springer.com/"
    }
}
</script>
<article
    ⇥=springer/article/10.1007/s00300-003-0563-3
    ⇥-shadowrootmode=open>
    <span slot="AdInsert"><a href="https://www.target.com/b/pedialax/-/N-55lp4">Pedia-Lax</a></span>
</article>

Cross-origin constraints

All fetches performed by pipe-in use the standard Fetch API and are therefore subject to CORS. A cross-origin URL will only succeed if the remote server responds with appropriate Access-Control-Allow-Origin headers. This means untrusted third-party endpoints cannot be silently injected — the remote must explicitly opt in to being consumed.

For same-origin URLs no additional configuration is needed.

Content Security Policy

pipe-in respects the page's Content-Security-Policy. In particular:

• connect-src governs which origins pipe-in may fetch from. If a URL is not permitted by the active CSP, the fetch will be blocked by the browser before any content reaches the page.
• script-src applies when [base]-run-scripts is used. Even if the import-map gate allows script execution, CSP can independently block inline or remote scripts that don't match the policy.
• style-src applies to any inline styles present in the streamed content.

A recommended baseline policy for pages using pipe-in:

Content-Security-Policy: connect-src 'self' https://trusted.example.com; script-src 'self'; style-src 'self' 'unsafe-inline'

This layers defense-in-depth on top of the import-map gate: even if an attacker could influence markup attributes, the browser-enforced CSP limits where content can be loaded from and whether scripts can execute.

CORS proxies for cross-origin content

Many useful HTML sources (documentation sites, CMSs, third-party APIs) don't serve CORS headers. When you control the target server, the fix is to add Access-Control-Allow-Origin there. When you don't, a CORS proxy can relay the request and attach the required headers.

Recommended: Cloudflare Worker (self-hosted)

A Cloudflare Worker is the best option for most deployments. The free tier provides 100,000 requests/day, there's no server to manage, latency is low thanks to Cloudflare's edge network, and you maintain full control over allowed origins.

cloudflare-cors-anywhere is a minimal, ready-to-deploy Worker (~30 lines) you can deploy with wrangler publish. Usage:

https://your-worker.your-subdomain.workers.dev/?https://example.com/content.html

You can lock it down by adding an origin allowlist so only your site can call the proxy.

Alternatives:

• cors-anywhere — The original Node.js CORS proxy. Self-host on any Node environment (Heroku, Fly.io, a VPS). More infrastructure to manage, but full flexibility. The public demo at cors-anywhere.herokuapp.com is rate-limited and not suitable for production.
• corsproxy.io — Free hosted service, no setup required. Convenient for prototyping, but you're trusting a third party with your traffic and uptime.

Usage with pipe-in:

<script type=importmap>
{
    "imports": {
        "proxied/": "https://your-worker.workers.dev/?"
    }
}
</script>
<article pipe-in="proxied/https://example.com/article.html">
    <p>Loading...</p>
</article>

Note: Because the URL above uses a bare specifier mapped through an import map, the security constraints on sanitizer/script overrides are also satisfied.

URL rewriting

When [base]-base is present, pipe-in rewrites relative URLs (href, src, action, poster, and url() in inline styles) in the streamed HTML to absolute URLs, using the directory of the fetch URL as the base. The URL rewriting module (rewrite-urls.js) is only loaded when [base]-base is present.

Note: <base> elements don't work inside shadow roots per the HTML spec, so pipe-in uses a streaming TransformStream to rewrite URLs on the fly as content is piped in. This same approach works for both shadow DOM and light DOM streaming.

<article pipe-in=/demo/partials/sample.html
         pipe-in-base
         pipe-in-method=streamHTMLUnsafe>
    <p>Loading...</p>
</article>

Relative links in sample.html like href="styles.css" and src="icon.svg" will be resolved to /demo/partials/styles.css and /demo/partials/icon.svg respectively.

Typically you'll want streamHTMLUnsafe when using [base]-base, since the default sanitizer strips elements like <link> and <img> that are often present in content with relative URLs.

Piping state

pipe-in sets attributes on the enhanced element to indicate the current state of the content fetch. This enables CSS-based loading indicators and accessible feedback.

Attributes set

Attribute	Values	Purpose
aria-busy	true (during loading/streaming), removed on complete/error	Standard ARIA attribute for assistive technologies
[base]-state	loading | streaming | complete | error	Fine-grained CSS hook for styling each phase

State transitions

1. loading — Fetch has been initiated, waiting for response
2. streaming — First chunk received, content is being piped in
3. complete — All content has been streamed successfully
4. error — Fetch or streaming failed

Example CSS

[pipe-in-state="loading"] {
    opacity: 0.5;
}
[pipe-in-state="streaming"] {
    /* content is appearing progressively */
}
[pipe-in-state="complete"] {
    opacity: 1;
}
[pipe-in-state="error"] {
    border: 1px solid red;
}

/* Or using aria-busy for simpler loading/done toggle */
[aria-busy="true"] {
    background: url('spinner.gif') no-repeat center;
}

Support for snipping

When importing a full HTML page or a large fragment, you often only need a specific portion. The [base]-start and [base]-end attributes let you extract a slice of the streamed content. Both are optional and can be used independently or together:

• [base]-start — Content before this marker is discarded. The marker itself and everything after it is kept.
• [base]-end — Content from this marker onward is discarded. Only content before it is kept.

When both are present, only the content between start (inclusive) and end (exclusive) is emitted.

Snipping runs before URL rewriting, so markers match the original source HTML.

<article pipe-in=/demo/partials/sample.html
         pipe-in-shadowrootmode=open
         pipe-in-start="<body"
         pipe-in-end="</body>"
         pipe-in-base
         pipe-in-method=streamHTMLUnsafe>
    <p>Loading...</p>
</article>

Shared streams

By default, pipe-in deduplicates fetches for identical URLs (with matching snip/rewrite parameters). When multiple elements share the same computed storage key, only one performs the actual fetch — others join the in-progress stream or use the cached result.

How it works

1. The first instance to call hydrate registers itself as the source stream in a module-level inflight map
2. While streaming, it broadcasts each chunk to any late-joining subscribers
3. A second instance arriving mid-stream catches up by replaying all accumulated chunks, then receives live chunks going forward
4. After the source stream completes, the accumulated HTML is persisted to sessionStorage
5. Any instance arriving after completion reads directly from sessionStorage — no network request needed

Opting out

Add [base]-no-share to disable sharing entirely for a given element. It won't register as a source, won't join existing streams, and won't read from sessionStorage. Each no-share instance always performs its own independent fetch.

<article pipe-in=/content.html pipe-in-no-share>
    <p>Loading...</p>
</article>

Storage key

The deduplication key incorporates the resolved URL plus the transform parameters that affect output:

pipe-in:{resolvedUrl}|{start}|{end}|{base}

Two elements with the same URL but different snip markers or one with URL rewriting and one without will not share streams — their outputs would differ.

Custom element template handoff

When pipe-in is used on a custom element (any tag with a dash in its name) that contains a <script type="precede"> child, pipe-in will automatically coordinate with custom element features like templ-maker to provide a template for the element's definition.

How it works

1. Before fetching, pipe-in checks if the enhanced element has a <script type="precede"> in its light DOM
2. If found, pipe-in accumulates the final transformed HTML (after snipping, URL rewriting, etc.) into a string while streaming
3. After streaming completes, pipe-in creates a <template> element, sets its innerHTML to the accumulated string, and attaches it to the script element via Symbol.for('pipe-in:template')
4. pipe-in then flips the script's type from precede to cede, which triggers mount-observer to proceed with custom element registration.

Usage

<hello-world enh-pipe-in=my-package/hello-world.html
             enh-pipe-in-shadowrootmode=open
             enh-pipe-in-base
             enh-pipe-in-method=streamHTMLUnsafe>
    <script type="precede" data-extends="el-maker"></script>
</hello-world>

The first <hello-world> instance fetches and streams the HTML, then hands the template to templ-maker via the precede → cede flip. Once the custom element is defined, subsequent instances get their content from the element's own lifecycle — no pipe-in attribute needed:

<hello-world></hello-world>

The precede protocol

The type="precede" convention is a generic coordination mechanism. Any feature that needs to wait for pipe-in to finish streaming before it activates can use this pattern:

• The script sits inert (browsers ignore scripts with unknown types)
• pipe-in attaches a template at scriptEl[Symbol.for('pipe-in:template')]
• pipe-in flips type to cede, triggering whatever mount-observer or mutation-based logic is watching for that type

This keeps coupling at the markup level — pipe-in doesn't import or reference templ-maker, and templ-maker doesn't import pipe-in.

Events

pipe-in dispatches standard events on the enhanced element:

Event	When	Bubbles
load	Content has been successfully streamed into the DOM	No
error	Fetch or streaming failed	No

const article = document.querySelector('article[pipe-in]');
article.addEventListener('load', () => {
    // Content is ready — safe to query the shadow DOM, etc.
});
article.addEventListener('error', () => {
    // Handle failure
});

Presets

be-importing ( 📥 )

A shortcut preset for the common "custom element definition via HTML import" pattern. It bundles the typical settings needed when importing a custom element's template from an HTML file.

The be-importing attribute (or 📥 shorthand) implies:

Setting	Value
shadowrootmode	open
injectBase	true
method	streamHTMLUnsafe
start	<?start
end	<?end>
runScripts	true
cache	default

These settings are baked in and cannot be overridden via attributes when using this preset.

<xtal-side-nav be-importing=xtal-side-nav/xtal-side-nav.html>
    <script type="precede" data-extends="el-maker"></script>
    <section style='color:white'>
        <div>Menu Item 1</div>
        <div>Menu Item 2</div>
    </section>
</xtal-side-nav>

The HTML file (xtal-side-nav.html) delineates its template body with processing instruction markers:

<!-- head content, styles, etc. -->
<?start>
<div class="sidebar">
    <slot></slot>
</div>
<?end>

To register this preset with be-hive:

<be-hive>
    <script type=emc src="pipe-in/be-importing.json"></script>
</be-hive>

Viewing Demos Locally

1. Install git
2. Fork/clone this repo
3. Install node.js
4. Open command window to folder where you cloned this repo

5. git submodule add https://github.com/bahrus/types.git types

6. git submodule update --init --recursive

7. npm install

8. npm run serve

9. Open http://localhost:8000/demo/ in a modern browser

Running Tests

> npm run test
