Getting Started w/ diy-client

diy-client is the official js client for the DIY API. With it you can interact with DIY data such as maker and skill info.

For this guide you'll need some basic Frontend Dev skills like JavaScript and HTML.

You can download the files for this guide here. Once you have the files just open index.html in a browser and check the console for output.

Initial Steps

Create a HTML document and reference the diy.dist.js file.

<script type="text/javascript" charset="utf-8" src="diy.dist.js"></script>

Then call the diyClient function which returns another function you can use to make requests to the DIY API.

<script type="text/javascript">
    var diy = diyClient();


Now that we have a diy function we can ask the API for some data… Let's try maker data. A call to diy requires 2 arguments: a route or uri as the first argument and a callback function as the second argument.

<script type="text/javascript">
    var diy = diyClient();

    diy('/makers/drk', function (err, body) {

Now we're cookin'! 🥚

The uri in this case is the /makers/:url resource. You can replace :url with any existing maker url like /makers/astro to get their DIY data.

The callback function will be called when the request to the DIY API is done.

All of the response data can be found in the body.response variable, but first you'll want to make sure there wasn't an error while requesting.

So we can beef up the callback function to be a little more tolerant:

diy('/makers/drk', function (err, body) {
    if (err) return alert('Error fetching maker data.');


If there is an error we return early and alert that an error occured.

If everything went ok body.response should contain an object literal that looks like this:

    "id": 32581,
    "stamp": "2013-01-03T12:56:15.000Z",
    "url": "drk",
    "nickname": "drk",
    "email": "d*****@m*.com",
    "type": {
        "moderator": true,
        "adult": false,
        "subscriber": false,
        "verified": true,
        "suspended": false
    "avatar": {
        "id": 93,
        "icon": {
            "url": "https://d3hv8qdd474bjn.cloudfront.net/drk_icon.png",
            "mime": "image/jpeg",
            "width": 30,
            "height": 28
        "small": {
            "url": "https://d3hv8qdd474bjn.cloudfront.net/drk_small.png",
            "mime": "image/jpeg",
            "width": 90,
            "height": 90
        "medium": {
            "url": "https://d3hv8qdd474bjn.cloudfront.net/drk_medium.png",
            "mime": "image/jpeg",
            "width": 160,
            "height": 150
        "large": {
            "url": "https://d3hv8qdd474bjn.cloudfront.net/drk_large.png",
            "mime": "image/jpeg",
            "width": 460,
            "height": 431
    "portfolio": {
        "bio": "I write stuff.",
        "foreground": "#ffffff",
        "background": "#ffd531"
    "stats": {
        "projects": 53,
        "achievements": 27,
        "patches": 6,
        "following": 111,
        "followers": 1099

By this point your HTML file should look close to the included index.html file.

That is the most basic way to get data from the DIY API! Once you have this down try and guess how to fetch some skill data. If you need some help figuring out the skill uri check docs.diy.org.

More Requests

Coming soon!

  • How to add data to the API
  • How to authenticate so you can post project from the api
  • Search!


Why do I have to call a diyClient() function to get the other function named diy?

The initial call to diyClient allows you to set a custom API host and version number, but most of the time you just want the default http://api.diy.org and current API version. This is more of a convenience for DIY internally as it allows us to easily swap out versions of the API while tesitng.

What kind of data can I play with?

You can see all the different types of data in the DIY API here: See docs.diy.org.

Is there another way to install diy-client?

Yup! diy-client is available in npm and can be installed by running:

npm install diy

diy-client works both on the server in Node and in browsers that support CORS.

In the browser you can bundle diy-client w/ browserify or use the standalone diy.dist.js file included here.
