drawiterm

Excalidraw-style system design sketching tool for the terminal

Draw boxes, arrows, and labels directly in your terminal using keyboard and mouse. Diagrams are saved as plain JSON files. Works over SSH — no graphics extensions, no browser, no GUI framework required.

╭──────────╮        ╭──────────╮        ╭──────────╮
│   API    │───────►│  Cache   │───────►│    DB    │
╰──────────╯        ╰──────────╯        ╰──────────╯

Demo

Requirements

• Python 3.12+
• Any ANSI/VT100-compatible terminal (xterm, kitty, alacritty, tmux, etc.)

Installation

With pipx (recommended)

pipx install drawiterm

With Nix

nix run github:dmille56/drawiterm

With pip

pip install drawiterm

Usage

drawiterm                       # new blank diagram
drawiterm mydiagram.drawiterm   # open existing file

Tools

Key	Tool
s / Escape	Select
r	Rectangle
e	Ellipse
d	Diamond
a	Arrow
l	Line
p	Draw (freehand)
x	Eraser
t	Text

Arrows and Lines are orthogonal by default; use Shift+Tab to toggle to straight. Use Draw (p) to sketch freehand paths by clicking and dragging. When tool lock is OFF, the app switches back to Select after using a tool; press Ctrl+L to toggle tool lock.

Key Bindings

Key	Action
Ctrl+S	Save
Ctrl+O	Open file
Ctrl+Z	Undo
Ctrl+Y / Ctrl+Shift+Z	Redo
Ctrl+A	Select all
Ctrl+D	Duplicate selection
Delete / Backspace	Delete selected elements
Arrow keys	Nudge selected elements
Tab	Next tool
Shift+Tab	Toggle arrow/line style (straight/orthogonal)
Ctrl+L	Toggle tool lock (keep active tool after use)
Ctrl+Arrow	Pan canvas
Ctrl+Left-drag	Pan canvas
Ctrl+Q	Quit

Double-click an element to edit its label. Press Escape to commit the edit.

Pro tip: Some keys do SpOoKy things the UI doesn't tell you about. Try the ones you're least likely to use in your workflow.

File Format

Diagrams are saved as .drawiterm JSON files — human-readable and version-control friendly.

Development

Setup lorri (and use it)

• https://github.com/nix-community/lorri
• Make sure to run lorri daemon as a service

lorri init
direnv allow        # activate Nix shell (sets PYTHONPATH=src automatically)

--or-- Manually use nix development shell:

nix develop
export PYTHONPATH=src

Install pre-commit hooks (so that it runs ruff everytime when you commit to fix issues)

pre-commit install

Commands

python -m drawiterm # run from source

ruff check src/     # lint
ruff format src/    # format
pytest              # tests

See SPEC.md for the full requirements specification.

Release process

Automatically

python scripts/bump_version.py --push

--or-- Manually

• Bump the version in pyproject.toml and nix/drawiterm.nix (no leading "v" in the file values).
• Commit, then tag and push (tag must be v and match pyproject.toml):

git tag -a "v0.1.0b1" -m "v0.1.0b1"
git push origin v0.1.0b1

Other

The GitHub Actions "Release" workflow will lint, test, build, and create a GitHub Release. If you add a repository secret PYPI_API_TOKEN (from PyPI), it will also publish to PyPI.
