CasaBoard

Open-source, self-hosted dashboard builder for Home Assistant.

Drag-and-drop editing, Docker Compose (or Node) for the app, optional HACS integration for a sidebar panel and health sensors — no account, no cloud, no login.

What you get

Piece	What it does
CasaBoard app	Self-hosted editor + live dashboards (Docker recommended)
HACS integration	Sidebar panel (iframe), online/page sensors, casaboard.refresh service

Your layouts and Home Assistant credentials stay on your machine. Nothing phones home.

Requirements

• A running Home Assistant instance (2024.6+ for the HACS integration)
• Docker + Docker Compose (for the recommended install)
• Optional: HACS to install the sidebar integration

Quick start (app)

git clone https://github.com/element-software/CasaBoard.git
cd CasaBoard
docker compose up -d

Open http://localhost:3000 (or http://<host-ip>:3000).

On first launch you connect to Home Assistant (URL + long-lived access token, or HA sign-in). After that, create a page and build in the drag-and-drop editor.

Dashboard data lives in ./data (bind-mounted into the container) — back that directory up.

Full walkthrough: casaboard.dev/docs

Install the HACS integration

The integration does not replace the CasaBoard app — it bridges a running instance into Home Assistant.

1. Add the repository in HACS

1. HACS → Integrations → ⋮ → Custom repositories
2. Repository: https://github.com/element-software/CasaBoard
3. Category: Integration
4. Download CasaBoard, then restart Home Assistant

2. Add the integration

Or: Settings → Devices & services → Add integration → CasaBoard

Enter the base URL of your CasaBoard app, for example:

• http://homeassistant.local:3000
• http://casaboard:3000 (same Docker network as HA)
• http://192.168.x.x:3000

What the integration provides

Entity / feature	Meaning
Sidebar CasaBoard panel	Opens the app in an iframe (title/icon configurable in options)
binary_sensor.casaboard_online	CasaBoard /api/health is reachable
sensor.casaboard_pages	Total pages
sensor.casaboard_ha_connection	connected / disconnected (stored HA credentials in the app)
casaboard.refresh	Service to re-poll health (optional entry_id)

Manual install (without HACS)

Copy custom_components/casaboard into <config>/custom_components/casaboard, restart Home Assistant, then add the integration from the UI.

Sidebar only (no sensors)

If you only want an iframe and no custom component:

# configuration.yaml
panel_iframe:
  casaboard:
    title: CasaBoard
    icon: mdi:view-dashboard
    url: http://homeassistant.local:3000

Viewing dashboards

Open any page in the CasaBoard app at /dashboard/<slug> (for example http://<host>:3000/dashboard/upstairs). Wall tablets and bookmarks should point at that URL.

Environment variables

Variable	Default (Docker)	Purpose
DATA_DIR	/data	JSON store (pages, sidebars, themes, HA connection)
PORT	3000	HTTP port

Privacy

No analytics or tracking in the app or the marketing site. No cookie consent banner — there is nothing to consent to. Your Home Assistant credentials and dashboard JSON never leave the server you run.

Support

• Docs: casaboard.dev/docs
• Issues: GitHub Issues
• Email: support@casaboard.dev

---

Development

Requirements: Node 18+, npm 10+. From the repo root:

npm install
npm run dev

• App: http://localhost:3000
• Public site: http://localhost:3001

npm run build        # all apps/packages
npm run lint
npm run check-types

Repository layout

Path	Role
apps/app	Dashboard builder (Next.js) — what the Docker image runs
apps/public	Documentation / marketing site (casaboard.dev)
packages/ui	Shared UI (HeroUI, icons, Puck editor)
packages/lib	Actions, services, flat-JSON persistence
packages/ha	Home Assistant websocket helpers (@casaboard/ha)
custom_components/casaboard	HACS integration (panel + sensors); brand assets in brand/

Integration-focused notes: hacs-panel/README.md.

License

MIT © CasaBoard
