prawn — go-ruby-prawn

A pure-Go (no cgo), MRI-faithful reimplementation of Ruby's prawn PDF-generation gem. It mirrors prawn's document DSL — text, fonts (Core-14 and embedded/subset TrueType), colors (RGB and CMYK), vector graphics, images, transformations, a grid, bounding boxes, repeaters/page numbering, a table, plus the Prawn::Errors tree — and writes the PDF with its own native pure-Go PDF object model and content-stream writer. The emitted content-stream operators match Ruby prawn / PDF::Core operator-for-operator, so the output is validated against the real gem with a PDF::Inspector-style differential oracle. No C PDF library, no Ruby runtime, and no third-party PDF generator: the module has zero non-stdlib runtime dependencies and builds with CGO disabled on every supported 64-bit target (and to WebAssembly).

It is a PDF backend for go-embedded-ruby, but is a standalone, reusable module — a sibling of go-ruby-rqrcode, go-ruby-regexp and go-ruby-yaml.

What it is — and isn't. Emitting a PDF (page layout, text placement, vector graphics, image embedding) is deterministic and needs no interpreter, so it lives here as pure Go. Binding Prawn::Document to live Ruby objects is the host's job; this library hands back a plain, well-formed PDF byte stream.

Ruby → Go

Prawn's block-form generator

Prawn::Document.generate("hello.pdf") do |pdf|
  pdf.text "Hello World", size: 24, style: :bold
  pdf.move_down 20
  pdf.stroke_rectangle [0, pdf.cursor], 200, 100
end

becomes

prawn.Generate("hello.pdf", func(pdf *prawn.Document) error {
    pdf.Text("Hello World", &prawn.TextOptions{Size: 24, Style: prawn.StyleBold, StyleSet: true})
    pdf.MoveDown(20)
    pdf.StrokeRectangle(0, pdf.Cursor(), 200, 100)
    return nil
})

Ruby keyword-argument hashes become option structs (a nil selects prawn's defaults); Ruby symbols become typed Go constants (Style*, Align*, page-size and layout strings). Coordinates are PDF points (1/72 inch) with prawn's origin: the lower-left corner of the margin box (bounds).

Features

Faithful port of the frequently used prawn DSL, verified by generating documents and parsing them back:

• Document & pages — New / Generate / GenerateTo / GenerateWith, Render, RenderFile, StartNewPage, Cursor, MoveCursorTo, Bounds, MoveDown / MoveUp, Pad / PadTop / PadBottom, PageCount. Page sizes (LETTER … A0–A10, B0–B6, C0–C6, custom) and portrait / landscape layout, with prawn's 36pt default margins (uniform or per-side).
• Text — Text (flowing, wrapping, auto-paginating), DrawText (absolute), TextBox (positioned box with :truncate / :expand / :error overflow), Font / FontSize / Leading, alignment (left / center / right / justify).
• Fonts — the 14 standard AFM fonts (Font/FontSize/Leading, kerning), plus TrueType embedding with subsetting (RegisterFontTTF): glyf/loca/hmtx subset following composite references, written as a Type0/CIDFontType2 font with Identity-H, a FontFile2 stream, a /W width array and a /ToUnicode CMap.
• Formatted text — FormattedText (styled runs) and TextInline (<b>/<i>/<color> markup).
• Color — FillColor / StrokeColor (hex "RRGGBB") and CMYK (FillColorCMYK / StrokeColorCMYK), emitted via prawn's cs/scn, CS/SCN operators.
• Graphics — MoveTo/LineTo/CurveTo, Rectangle, Line, Polygon, Circle/Ellipse, Stroke/Fill/FillAndStroke/CloseAndStroke, StrokeBounds, LineWidth, CapStyle/JoinStyle, Dash/Undash.
• Layout — BoundingBox, the column/row Grid, Repeat / NumberPages, and affine transforms Rotate / Scale / Translate (with origin), TransformationMatrix, SaveGraphicsState/RestoreGraphicsState, Transparency.
• Images — Image (file) / ImageReader (io) for PNG (alpha → SMask) and JPEG (DCTDecode passthrough), with at, width, height and fit.
• Table — a basic grid (Table): explicit or automatic column widths, optional bold header row, cell padding and borders, positioning.
• Errors — the Prawn::Errors tree (ErrCannotFit, ErrUnknownFont, ErrInvalidPageLayout, ErrUnsupportedImageType, ErrEmptyGraphicStateStack, ErrIncompatibleStringEncoding, …).

CGO-free, 100% test coverage, gofmt + go vet clean, race-clean, and green across the six 64-bit Go targets (amd64, arm64, riscv64, loong64, ppc64le, s390x), two WebAssembly targets and three OSes.

Differential oracle

The output is validated against the real Ruby prawn gem the way prawn validates itself — with a PDF::Inspector-style parse of the content stream, not raw byte-equality (PDFs carry timestamps and ids). For each scenario, the PDF operators this library emits (BT/Td/Tf/kerned TJ, re/l/m/c, S/f, cs/scn, CS/SCN, cm, Do) are compared operator-for-operator against the gem's for the same script. The gem's operator streams are captured into testdata/oracle/*.content and committed, so the oracle runs in CI without Ruby; a skip-gated test re-verifies them against a live gem when one is installed. See prawn_diff_test.go / prawn_gem_test.go.

Install

go get github.com/go-ruby-prawn/prawn

Usage

package main

import (
	"log"

	"github.com/go-ruby-prawn/prawn"
)

func main() {
	err := prawn.Generate("report.pdf", func(pdf *prawn.Document) error {
		pdf.Font("Times", prawn.StyleBold)
		pdf.Text("Quarterly Report", &prawn.TextOptions{Size: 24, Align: prawn.AlignCenter})
		pdf.MoveDown(12)

		pdf.FillColor("333333")
		pdf.Text("Generated with pure-Go prawn.", nil)

		pdf.Table([][]string{
			{"Item", "Qty", "Price"},
			{"Widget", "3", "9.99"},
			{"Gadget", "1", "19.99"},
		}, prawn.TableOptions{Header: true})

		pdf.StrokeColor("CC0000")
		pdf.StrokeRectangle(0, pdf.Cursor(), pdf.Bounds().Width, 40)
		return nil
	})
	if err != nil {
		log.Fatal(err)
	}
}

Determinism

The PDF /CreationDate comes from a package clock seam, not the wall clock, so output is reproducible and timezone independent — pin it with SetClock:

defer prawn.SetClock(prawn.SetClock(func() time.Time {
	return time.Date(2026, 1, 1, 0, 0, 0, 0, time.UTC)
}))

PDF is a byte-oriented format and every dependency is pure Go, so the bytes are identical on little- and big-endian architectures alike.

Tests & coverage

The suite is self-contained: it generates PDFs in memory and parses them back with the pure-Go rsc.io/pdf reader, asserting that each document is a well-formed PDF (header, xref, trailer, %%EOF), that the expected text appears on the right page with the right font and size, that images are embedded as image XObjects, and that table cells and vector graphics are drawn. It also runs the committed-fixture differential operator oracle (see above) comparing the emitted operators to the real prawn gem's. No Ruby runtime and no network are needed in CI; the live-gem re-verification skips when Ruby is absent. 100% statement coverage is enforced.

COVERPKG=$(go list ./... | paste -sd, -)
go test -race -coverpkg="$COVERPKG" -coverprofile=cover.out ./...
go tool cover -func=cover.out | tail -1   # 100.0%

Scope

Covered faithfully: document + page management, text (flowing / absolute / box), formatted/inline text, Core-14 AFM fonts and subset-embedded TrueType, color (RGB + CMYK), vector graphics, bounding boxes, grid, transformations, repeaters/page numbering, PNG/JPEG images and a basic table.

Font embedding also has a go-opentype-backed backend (RegisterFontOTF) built on the pure-Go github.com/go-opentype/opentype

• .../shape stack. On top of the glyf/TrueType path it adds:

• CFF/OpenType (.otf, "OTTO") embedding as a CIDFontType0 descendant with a FontFile3 (/Subtype /OpenType) program;
• an opt-in shaped-text path (OTFOptions{Shape: true}) so Arabic joining, Indic reordering, CJK and Latin ligatures/kerning (GSUB + GPOS) render with the correct glyphs and spacing, emitted as a positioned TJ array;
• variable-font instance selection (OTFOptions{Variation: {"wght": 700}}), so measured widths and the per-CID /W advances follow the chosen axis.

The default Prawn text API (text, formatted_text, font, width_of) is unchanged; shaping and variation are opt-in, so default output stays Prawn-compatible.

Deferred (named in doc.go, not implemented): advanced prawn-table features (row/column spanning, per-cell style callbacks, automatic table pagination), GPOS mark-attachment vertical placement in the PDF (substitution + horizontal advances are applied), glyf/CFF subsetting for the OTF backend (the whole font program is embedded), CJK/soft-hyphen line breaking, and SVG.

License

BSD-3-Clause — see LICENSE. Copyright the go-ruby-prawn/prawn authors.

WebAssembly

Being pure Go (CGO=0), this library also compiles to WebAssembly — both GOOS=js GOARCH=wasm (browser / Node.js) and GOOS=wasip1 GOARCH=wasm (WASI). CI builds both targets on every push, alongside the six 64-bit native/qemu arches.

GOOS=js     GOARCH=wasm go build ./...   # browser / Node
GOOS=wasip1 GOARCH=wasm go build ./...   # WASI (wasmtime, wasmer, wasmedge, …)
