synctex — go-synctex

A pure-Go (no cgo) parser for TeX's SyncTeX output — the .synctex.gz file pdflatex/xelatex/lualatex emit to link a .tex source line to the exact spot on the PDF page, in both directions.

It answers the two queries an editor/viewer needs:

• Forward — (source file, line) → (page, x, y): jump the PDF viewer to where a source line was typeset.
• Backward — (page, x, y) → (source file, line): click a glyph in the PDF and jump back to the source that produced it.

Zero external dependencies — standard library only. It cross-compiles and embeds anywhere, is hardened against hostile input (a decompression-size cap guards against zip-bomb .synctex.gz files), and can scope Input: paths to a project root so absolute host paths never leak back to a client.

Install

go get github.com/go-synctex/synctex

Usage

package main

import (
	"fmt"

	"github.com/go-synctex/synctex"
)

func main() {
	// Parse the .synctex.gz the TeX engine wrote next to the PDF.
	f, err := synctex.Parse("main.synctex.gz")
	if err != nil {
		panic(err)
	}

	// Forward: source → PDF. "main.tex" line 42 lands here:
	if r, ok := f.Forward("main.tex", 42); ok {
		fmt.Printf("page %d at (%d, %d) sp\n", r.Page, r.X, r.Y)
	}

	// Backward: PDF → source. A click at (x, y) sp on page 2:
	if src, line, ok := f.Backward(2, 32_000_000, 45_000_000); ok {
		fmt.Printf("%s:%d\n", src, line)
	}
}

Coordinates are SyncTeX scaled points (sp); PDF points are sp / 65536. The raw sp are exposed so callers can apply their own DPI/point scaling (PDF.js, for instance, wants PDF points).

Scoping untrusted paths to a project root

Input: entries in a .synctex.gz are absolute paths under the compile workdir. When the file is untrusted or its paths would be echoed to a client, pass WithProjectRoot — paths outside the root are dropped and paths inside are rewritten relative-to-root:

f, err := synctex.Parse("build/main.synctex.gz",
	synctex.WithProjectRoot("/srv/projects/thesis"))

API

// Parse reads a .synctex.gz (or plain .synctex) file from disk.
func Parse(path string, opts ...Option) (*File, error)

// WithProjectRoot scopes Input: paths to root: outside paths are dropped,
// inside paths are rewritten relative-to-root.
func WithProjectRoot(root string) Option

// Forward: (source file, line) → nearest Record (page + x/y in sp).
func (f *File) Forward(sourceFile string, line int) (Record, bool)

// Backward: (page, x, y in sp) → (source file, line) closest to the point.
func (f *File) Backward(page, x, y int) (sourceFile string, line int, ok bool)

// ResolveSource maps an editor-side path to the absolute path SyncTeX recorded.
func (f *File) ResolveSource(rel string) (string, bool)

type Record struct {
	FileTag    int // Input: tag
	Line       int // 1-based source line
	Page       int // 1-based PDF page
	X, Y       int // anchor, in SyncTeX scaled points (sp)
}

Tests & coverage

Pure standard-library logic — the same suite runs identically on every platform, so there is no interpreter or external oracle to install.

COVERPKG=$(go list ./... | paste -sd, -)
go test -race -coverpkg="$COVERPKG" -coverprofile=cover.out ./...
go tool cover -func=cover.out | tail -1   # 100.0%

100% test coverage (including every error and malformed-record branch), gofmt + go vet clean, and green across the six 64-bit Go targets — amd64, arm64, riscv64, loong64, ppc64le, s390x.

License

BSD-3-Clause — see LICENSE. Copyright the go-synctex/synctex authors.
