go-webengine / browserproxy

A pure-Go, CGO_ENABLED=0 remote-browser service. It renders web pages server-side with the pure-Go go-webengine/engine and streams frames (plus a hyperlink hit-map) to a thin client, forwarding the client's clicks, scrolls and keys back as navigation. No Chromium, no cgo, no host web view.

The wire protocol is gRPC carried over grpc-transports/websocket: a single bidirectional Session stream per tab. Because that transport ships a zero-dependency syscall/js client, the same client compiles to GOOS=js/GOARCH=wasm and runs in the browser with no sidecar proxy — the full gRPC feature set (client- and bidi-streaming), which plain grpc-web cannot do.

Because rendering happens on the server:

• any site can be shown — including pages that set X-Frame-Options: DENY or a restrictive frame-ancestors CSP, which an <iframe> embed could never load;
• the client page can stay under COEP: require-corp (needed for SharedArrayBuffer) — a WebSocket is exempt from COEP/CORS.

It is the server half of the wasmdesk clients/browser in-desktop browser. See wasmclient/ for a worked GOOS=js/wasm client.

Run it locally

$ go run ./cmd/browserproxy -addr :8090
browserproxy: listening on :8090 (gRPC/WebSocket path /ws)

Then dial the browserproxy.v1.Browser gRPC service over the WebSocket transport at ws://localhost:8090/ws (native or GOOS=js/wasm):

opt, _ := wstransport.DialOption("ws://localhost:8090/ws", wstransport.ClientConfig{})
cc, _ := grpc.NewClient("passthrough:///browserproxy",
    grpc.WithTransportCredentials(insecure.NewCredentials()), opt)
stream, _ := browserpb.NewBrowserClient(cc).Session(ctx)

Flags:

flag	default	meaning
-addr	:8090	listen address
-origins	"" (any)	comma-separated WebSocket Origin allowlist (* = any)
-max-concurrent	4	global cap on concurrent page renders
-min-nav-interval	250ms	per-session minimum time between navigations
-width / -height	1024 / 768	default viewport size
-render-timeout	35s	per-navigation render timeout

Protocol

One gRPC bidirectional Session stream per tab (proto/browser.proto). Client → server ClientMsg: navigate, click, scroll, key, resize, back, forward. Server → client ServerMsg: frame (png,w,h,offset_y — raw PNG bytes, no base64), state (url,title,loading,can_back, can_forward), error. Full spec: docs/protocol.md.

Security (SSRF guard)

Every fetch — the top navigation and every subresource, redirect and DNS-rebinding attempt — passes an SSRF guard before the socket connects:

• non-http(s) schemes rejected (file:, data:, javascript:, …);
• cloud metadata 169.254.169.254, loopback, RFC1918 private, link-local, IPv6 ULA (fc00::/7), CGNAT (100.64.0.0/10), unspecified and multicast addresses blocked at dial time (post-DNS);
• internal namespaces (localhost, *.internal, *.local, *.lan, *.home.arpa) blocked by name.

Plus a per-session navigation rate limit, a global concurrent-render cap, and a configurable WebSocket Origin allowlist.

Testing

$ go test -short ./...     # unit tests only (no network); root package at 100%
$ go test ./...            # also runs the live example.com integration test

Three layers of end-to-end proof, all over the real gRPC-over-WebSocket wire:

• TestIntegration_StubbedTransport — a real gRPC client drives a stub-rendered server (hermetic, no network);
• TestWasmClientE2E — compiles wasmclient/ to js/wasm and runs it under Node against a live server, asserting a full bidirectional Session — proof a pure-Go browser client actually runs;
• TestIntegration_ExampleCom (non--short) — the same client and transport drive a real engine-backed server against https://example.com, asserting a non-blank frame and the page title.

License

BSD-3-Clause — see LICENSE.
