LaDyS (Latent Dynamical Systems) Package

PyTorch benchmark scaffolding for latent variable models of neural dynamics.

The first API pass standardizes model construction, training/reporting contracts, and synthetic Lorenz/chaotic-RNN datasets. Models accept (batch, time, neurons) tensors in forward.

Initial Examples

• ladys.models.bgpfa: Bayesian GPFA using the vendored mgplvm-pytorch implementation with a differentiable variational ELBO and full-batch gradient strategy.
• ladys.models.cassm: thin adapter around the compact sparse CASSM filtering core in ladys.models.
• ladys.models.gpfa: Gaussian-observation GPFA with FA initialization and a differentiable exact marginal negative log likelihood. It trains with the standard PyTorch gradient strategy by default; the older EM adapter remains available through config.
• ladys.models.ilqr_vae: PyTorch iLQR-VAE adapter with posterior-control inference for pretrained MC_Maze checkpoints and ELBO training for new spike-count datasets.
• ladys.models.kalman: dense Kalman filter baseline adapted from the CASSM filtering code, exposed with per-trial rate predictions for benchmark metrics.
• ladys.models.langevin_flow: sequential VAE adapter for LangevinFlow with a GRU encoder, Langevin latent position/velocity dynamics, a locally coupled oscillator potential, and a one-layer Transformer rate decoder. The LaDyS NLB path trains a direct held-in plus held-out readout and scores the held-out slice.
• ladys.models.mint: inference-only Mesh of Idealized Neural Trajectories decoder. MINT builds a trajectory library once, then decodes by Poisson likelihood recursion and interpolation; Lorenz defaults to spike-derived smoothed libraries, while lorenz_library_source: true_rates is reserved for oracle/debug checks.
• ladys.models.ndt: masked-count NeuralDataTransformer (NDT) adapter with native LaDyS config, training, prediction, and metrics contracts.
• ladys.models.psth: peri-stimulus time histogram baseline. On NLB H5 files with condition indices, it smooths training held-out spikes, averages them by condition, and maps those condition averages onto eval trials without using target-side PSTH evaluation metadata.
• ladys.models.smoothing: Gaussian spike-smoothing baseline. For NLB co-smoothing, it mirrors the public NLB smoothing baseline by fitting a Poisson readout from log-smoothed held-in counts to training held-out counts.

Public Experiment API

LaDyS is organized around three public pieces:

• ladys.models: model configs build PyTorch nn.Module instances and carry their optimization settings.
• ladys.data.DataModule: creates PyTorch train/validation datasets and dataloaders.
• ladys.Experiment: gathers data, model, training, evaluation metrics, and artifacts into one inspectable run folder.

Run the canonical CLI path with a dataset and model:

ladys run -d lorenz -m cassm

The run folder includes config.json, history.csv, metrics.json, predictions.npz, model.pt, and report.md. The CLI also accepts full YAML experiment configs:

ladys run -c configs/experiment/synthetic/lorenz/bgpfa/bgpfa_lorenz.yaml
ladys run -c configs/experiment/synthetic/lorenz/gpfa/gpfa_lorenz.yaml
ladys run -c configs/experiment/synthetic/lorenz/langevin_flow/langevin_flow_lorenz.yaml
ladys run -c configs/experiment/synthetic/lorenz/ndt/ndt_lorenz.yaml
ladys list datasets
ladys list models

Synthetic and real-data tasks share the same CLI, but use task-specific evaluation adapters under the hood. Synthetic datasets such as Lorenz and chaotic RNN expose true rates and latents, so the default adapter reports ground-truth rate and latent metrics. NLB datasets expose held-in spikes and held-out targets, so the NLB co-smoothing adapter reports held-out bits/spike; models can override evaluation_adapter(task) when they need a method-specific readout, such as GPFA fitting a PyTorch linear or Poisson readout from inferred features to held-out neurons.

Neural Latents Benchmark Data

LaDyS can prepare the four core NLB'21 datasets, area2_bump, mc_maze, mc_rtt, and dmfc_rsg, as held-in/held-out co-smoothing H5 files in data/real/nlb. With --download, the command fetches the public NLB target H5 and the required DANDI NWB files before building LaDyS-ready tensors:

PYTHONPATH=src python3 scripts/prepare_nlb_data.py \
  --datasets area2_bump mc_maze mc_rtt dmfc_rsg \
  --splits test \
  --bin-sizes-ms 5 20 \
  --download

If NWB files are already present in a DANDI-style directory, omit --download and pass --nwb-root or repeated --search-root values. If the public target H5 is already local, pass --target-h5. Dataset configs for the 5 ms and 20 ms NLB test files live under configs/dataset/.

After a LaDyS run writes predictions.npz, score held-out count predictions with the NLB co-smoothing bits/spike metric:

ladys run -c configs/experiment/real/mc_maze/ilqr_vae/ilqr_vae_mc_maze_nlb_5ms.yaml
ladys score-nlb --run-dir runs/ilqr_vae_mc_maze_nlb_5ms

GPFA uses the same real-data path with its NLB adapter:

ladys run -c configs/experiment/real/mc_maze/gpfa/gpfa_mc_maze_nlb_5ms.yaml
ladys score-nlb --run-dir runs/gpfa_mc_maze_nlb_5ms

The lightweight NLB baselines are available through the same experiment API:

ladys run -c configs/experiment/real/mc_maze/psth/psth_mc_maze_nlb_5ms.yaml
ladys run -c configs/experiment/real/mc_maze/smoothing/smoothing_mc_maze_nlb_5ms.yaml
ladys score-nlb --run-dir runs/psth_mc_maze_nlb_5ms
ladys score-nlb --run-dir runs/smoothing_mc_maze_nlb_5ms

LangevinFlow configs are included for all four NLB datasets at 5 ms and 20 ms:

ladys run -c configs/experiment/real/mc_maze/langevin_flow/langevin_flow_mc_maze_nlb_5ms.yaml
ladys run -c configs/experiment/real/area2_bump/langevin_flow/langevin_flow_area2_bump_nlb_5ms.yaml
ladys run -c configs/experiment/real/mc_rtt/langevin_flow/langevin_flow_mc_rtt_nlb_5ms.yaml
ladys run -c configs/experiment/real/dmfc_rsg/langevin_flow/langevin_flow_dmfc_rsg_nlb_5ms.yaml

Note: LangevinFlow should be run with longer training budgets for meaningful results. The NLB YAMLs use released-scale epoch counts, and short runs such as 20 epochs are only diagnostics to confirm that optimization is moving.

Synthetic Lorenz configs are also included:

ladys run -c configs/experiment/synthetic/lorenz/langevin_flow/langevin_flow_lorenz.yaml
ladys run -c configs/experiment/synthetic/lorenz/psth/psth_lorenz.yaml
ladys run -c configs/experiment/synthetic/lorenz/smoothing/smoothing_lorenz.yaml

For methods that emit a full EvalAI-style submission H5, the same command can delegate to the nlb_tools evaluator:

ladys score-nlb --submission-h5 path/to/submission.h5 \
  --target-h5 data/real/nlb/eval_data_test.h5

Scaling Benchmark

Install the plotting extra before running benchmark artifact scripts in a clean environment:

pip install -e ".[benchmarks]"

Benchmark figures use a shared LaDyS plotting style backed by TUEplots when it is available. On Python versions where TUEplots cannot be installed, LaDyS uses a local Matplotlib fallback with the same figure sizing, color, grid, legend, and export defaults.

PYTHONPATH=src python3 scripts/benchmark_lorenz_scaling.py \
  --models cassm gpfa kalman ndt \
  --neurons 10 100 1000 \
  --seeds 1

The script writes a grouped run under runs/lorenz_scaling/, including summary.csv, summary.npy, summary.md, and plots/time_vs_neurons.png.

Loss-Curve Benchmark

PYTHONPATH=src python3 scripts/benchmark_lorenz_loss_curves.py \
  --models bgpfa cassm gpfa ilqr_vae kalman lfads mint ndt \
  --neurons 100 \
  --epochs 50

The script writes a grouped run under runs/lorenz_loss_curves/, including top-level summary.csv/summary.md, comparison plots under plots/, and per-model outputs under models/<model>/.

MINT appears in these curves as a horizontal inference-only baseline. Its default Lorenz adapter estimates trajectory-library rates from smoothed training spikes and repeated-trial averages. Passing --mint-lorenz-library-source true_rates switches to an oracle sanity check and should not be used for fair method ordering.

Preprocessing

Experiment YAML files can include a preprocessing block. The benchmark scripts apply this to dataset observations before models see them, while leaving Lorenz ground-truth rates unchanged for MSE metrics.

preprocessing:
  observations:
    name: smooth_firing_rate
    sampling_precision: 20.0
    kern_sd_ms: 50.0

configs/experiment/synthetic/lorenz/cassm/cassm_lorenz.yaml and configs/experiment/synthetic/lorenz/kalman/kalman_lorenz.yaml enable this CASSM-style spike smoothing. configs/experiment/synthetic/lorenz/gpfa/gpfa_lorenz.yaml leaves observations raw.

See website/docs/model_output_contract.md for the forward-output convention. See website/docs/optimizer_contract.md for the benchmark epoch definition.

Documentation Site

The website workspace lives under website/. LaDyS docs source lives under website/docs/, theme overrides live under website/overrides/, and MkDocs builds generated output into website/site/. The standalone zkunkworks homepage source lives under website/home/.

Model pages under website/docs/models/ are generated from model class docstrings and config defaults. Images referenced from model docstrings should live under website/docs/assets/ and can be linked as assets/<filename>:

python scripts/generate_model_docs.py
python scripts/generate_model_docs.py --check

Install the docs extra and serve the site locally:

pip install -e ".[docs]"
mkdocs serve
